电吸收调制激光器(EML)调制器部分高频仿真数据

该仿真数据主要来源与电磁仿真软件High Frequency Structure Simulator(HFSS)。所仿真结构为掺铁掩埋结构，仿真频段为0.1-40GHz，从而验证所提出的优化结构的高频性能。通过仿真，确定了所提出掺铁掩埋结构的高频传输性能，为课题高速电吸收调制激光器芯片研究提供了指导。观测数据为模型在0.1-40GHz的传输系数S21和反射系数S11。

This simulation dataset is primarily sourced from the electromagnetic simulation software High Frequency Structure Simulator (HFSS). The simulated structure is an iron-doped buried structure, and the simulation was conducted across the frequency range of 0.1–40 GHz to verify the high-frequency performance of the proposed optimized structure. Through these simulations, the high-frequency transmission performance of the proposed iron-doped buried structure was determined, providing guidance for the research on high-speed electro-absorption modulation laser chips in this study. The observed data consist of the transmission coefficient S21 and reflection coefficient S11 of the model within the 0.1–40 GHz frequency band.

搜集汇总

背景与挑战

背景概述

该数据集包含电吸收调制激光器(EML)调制器的高频仿真数据，通过HFSS软件仿真0.1-40GHz频段的掺铁掩埋结构，验证其高频传输性能，观测数据为传输系数S21和反射系数S11。数据用于指导高速电吸收调制激光器芯片的研究。
