# 🌲 AGBD: A Global-scale Biomass Dataset 🌳

Authors: Ghjulia Sialelli ([[e-mail]](mailto:[e-mail])), Torben Peters, Jan Wegner, Konrad Schindler

Paper: https://huggingface.co/papers/2406.04928

## 🆕 Updates
* The dataset was last modified on **Feb. 26th, 2025**
* See the [changelog](changelog.md) for more information about what was updated!

## 🚀 Quickstart

To get started quickly with this dataset, use the following code snippet:

⚠️ HuggingFace does not support loading scripts anymore. We are in the process of migrating to a new supported format. Thank you for your patience. In the meantime, please reach out to [e-mail] for dataset access.

```python
# Install the datasets library if you haven't already
!pip install datasets

# Import necessary modules
from datasets import load_dataset

# Load the dataset
dataset = load_dataset('prs-eth/AGBD', trust_remote_code=True, streaming=True)["train"] # Options: "train", "validation", "test"

# Iterate over the dataset
for sample in dataset:
features, label = sample['input'], sample['label']

```

This code will load the dataset as an `IterableDataset`. You can find more information on how to work with `IterableDataset` objects in the [Hugging Face documentation](https://huggingface.co/docs/datasets/access#iterabledataset).

---

## 📊 Dataset Overview

Each sample in the dataset contains a **pair of pre-cropped images** along with their corresponding **biomass labels**. For additional resources, including links to the preprocessed uncropped data, please visit the [project page on GitHub](https://github.com/ghjuliasialelli/AGBD/).

### ⚙️ Load Dataset Options

The `load_dataset()` function provides the following configuration options:

- **`norm_strat`** (str) : `{'pct', 'mean_std', 'none'}` (default = `'pct'`)
The strategy to apply to process the input features. Valid options are: `'pct'`, which applies min-max scaling with the 1st and 99th percentiles of the data; `'mean_std'` which applies Z-score normalization; and `'none'`, which returns the un-processed data.

- **`encode_strat`** (str) : `{'sin_cos', 'onehot', 'cat2vec', 'none'}` (default = `'sin_cos'`)
The encoding strategy to apply to the land classification (LC) data. Valid options are: `'onehot'`, one-hot encoding; `'sin_cos'`, sine-cosine encoding; `'cat2vec'`, cat2vec transformation based on embeddings pre-computed on the train set.

- **`input_features`** (dict)
The features to be included in the data, the default values being:
```
{'S2_bands': ['B01', 'B02', 'B03', 'B04', 'B05', 'B06', 'B07', 'B08', 'B8A', 'B09','B11', 'B12'],
'S2_dates' : False, 'lat_lon': True, 'GEDI_dates': False, 'ALOS': True, 'CH': True, 'LC': True,
'DEM': True, 'topo': False}
```

- **`additional_features`** (list) (default = `[]`)
A list of additional features the dataset should include. *Refer to the [documentation below](#add-feat-anchor) for more details.* Possible values are:
```
['s2_num_days', 'gedi_num_days', 'lat', 'lon', 'agbd_se', 'elev_lowes', 'leaf_off_f', 'pft_class', 'region_cla', 'rh98', 'sensitivity', 'solar_elev', 'urban_prop']
```
This metadata can later be accessed as such:
```
from datasets import load_dataset

dataset = load_dataset('AGBD.py',trust_remote_code=True,streaming=True)
for sample in dataset['train']:
lat = sample['lat']
break
```

- **`patch_size`** (int) (default =`15`)
The size of the returned patch (in pixels). The maximum value is **25 pixels**, which corresponds to **250 meters**.

---
### 🖼️ Features Details

Each sample consists of a varying number of channels, based on the `input_features` and `encode_strat` options passed to the `load_dataset()` function. The channels are organized as follows:

| Feature | Channels | Included by default?| Description |
| --- | --- | --- | --- |
| **Sentinel-2 bands** | `B01, B02, B03, B04, B05, B06, B07, B08, B8A, B09, B11, B12` | Y | Sentinel-2 bands, in Surface Reflectance values |
| **Sentinel-2 dates** | `s2_num_days, s2_doy_cos, s2_doy_sin` | N | Date of acquisition of the S2 image (in number of days wrt the beginning of the GEDI mission); sine-cosine encoding of the day of year (DOY).|
| **Geographical coordinates** | `lat_cos, lat_sin, lon_cos, lon_sin` | Y | Sine-cosine encoding of the latitude and longitude.|
| **GEDI dates** | `gedi_num_days, gedi_doy_cos, gedi_doy_sin` | N | Date of acquisition of the GEDI footprint (in number of days wrt the beginning of the GEDI mission); sine-cosine encoding of the day of year (DOY).|
| **ALOS PALSAR-2 bands** | `HH,HV` | Y | ALOS PALSAR-2 bands, gamma-naught values in dB.|
| **Canopy Height** | `ch, ch_std`| Y | Canopy height from Lang et al. and associated standard deviation. |
| **Land Cover Information** | `lc_encoding*, lc_prob`| Y | Encoding of the land class, and classification probability (as a percentage between 0 and 1).|
| **Topography** | `slope, aspect_cos, aspect_sin` | N | Slope (percentage between 0 and 1); sine-cosine encoded aspect of the slope.|
| **Digital Elevation Model (DEM)** | `dem` | Y | Elevation (in meters).|

This corresponds to the following value for `input_features` :
```
{'S2_bands': ['B01', 'B02', 'B03', 'B04', 'B05', 'B06', 'B07', 'B08', 'B8A', 'B09','B11', 'B12'],
'S2_dates' : False, 'lat_lon': True, 'GEDI_dates': False, 'ALOS': True, 'CH': True, 'LC': True,
'DEM': True, 'topo': False}
```

Regarding `lc_encoding*`, the number of channels follows this convention:
- `sin_cos` (default) : 2 channels
- `cat2vec` : 5 channels
- `onehot` : 14 channels
- `none` : 1 channel

Should you get stuck, you can debug the number of channels using the `compute_num_features()` function in [AGBD.py](AGBD.py).

In summary, the channels are structured as follows:

```plaintext
(Sentinel-2 bands) | (Sentinel-2 dates) | (Geographical coordinates) | (GEDI dates) | (ALOS PALSAR-2 bands) | (Canopy Height) | (Land Cover Information) | (Topography) | DEM
```

---
### ➕ Additional Features
<a name="add-feat-anchor"></a>

You can include a list of additional features from the options below in your dataset configuration:
- **`"agbd_se"` - AGBD Standard Error**: The uncertainty estimate associated with the aboveground biomass density prediction for each GEDI footprint.
- **`"elev_lowes"` - Elevation**: The height above sea level at the location of the GEDI footprint.
- **`"leaf_off_f"` - Leaf-Off Flag**: Indicates whether the measurement was taken during the leaf-off season, which can impact canopy structure data.
- **`"pft_class"` - Plant Functional Type (PFT) Class**: Categorization of the vegetation type (e.g., deciduous broadleaf, evergreen needleleaf).
- **`"region_cla"` - Region Class**: The geographical area where the footprint is located (e.g., North America, South Asia).
- **`"rh98"` - RH98 (Relative Height at 98%)**: The height at which 98% of the returned laser energy is reflected, a key measure of canopy height.
- **`"sensitivity"` - Sensitivity**: The proportion of laser pulse energy reflected back to the sensor, providing insight into vegetation density and structure.
- **`"solar_elev"` - Solar Elevation**: The angle of the sun above the horizon at the time of measurement, which can affect data quality.
- **`"urban_prop"` - Urban Proportion**: The percentage of the footprint area that is urbanized, helping to filter or adjust biomass estimates in mixed landscapes.
- **`"gedi_num_days"` - Date of GEDI Footprints**: The specific date on which each GEDI footprint was captured, adding temporal context to the measurements.
- **`"s2_num_days"` - Date of Sentinel-2 Image**: The specific date on which each Sentinel-2 image was captured, ensuring temporal alignment with GEDI data.
- **`"lat"` - Latitude**: Latitude of the central pixel.
- **`"lon"` - Longitude**: Longitude of the central pixel.

# 🌲 AGBD：全球尺度生物量数据集 🌳

作者：Ghjulia Sialelli（[[e-mail]](mailto:[e-mail])）、Torben Peters、Jan Wegner、Konrad Schindler

论文：https://huggingface.co/papers/2406.04928

## 🆕 更新
* 本数据集最后更新于**2025年2月26日**
* 如需了解更新详情，请查阅[更新日志](changelog.md)。

## 🚀 快速上手
如需快速使用本数据集，请参考以下代码片段：

⚠️ HuggingFace现已不再支持脚本加载方式，我们正迁移至新的兼容格式。感谢您的耐心等待。在此期间，请通过[e-mail]联系以获取数据集访问权限。

python
# Install the datasets library if you haven't already
!pip install datasets

# Import necessary modules
from datasets import load_dataset

# Load the dataset
dataset = load_dataset('prs-eth/AGBD', trust_remote_code=True, streaming=True)["train"] # Options: "train", "validation", "test"

# Iterate over the dataset
for sample in dataset:
features, label = sample['input'], sample['label']

此代码将数据集加载为`IterableDataset`（可迭代数据集，IterableDataset）。如需了解更多操作`IterableDataset`对象的方法，请参阅[Hugging Face官方文档](https://huggingface.co/docs/datasets/access#iterabledataset)。

---

## 📊 数据集概览
本数据集的每个样本均包含**一对经过预裁剪的图像**及其对应的**生物量标签**。如需获取包括预处理后未裁剪数据在内的更多资源，请访问GitHub上的[项目主页](https://github.com/ghjuliasialelli/AGBD/)。

### ⚙️ 数据集加载配置项
`load_dataset()` 函数提供以下配置选项：
- **`norm_strat`** (字符串)：可选值为`{'pct', 'mean_std', 'none'}`，默认值为`'pct'`
用于处理输入特征的归一化策略。各选项说明如下：`'pct'`表示基于数据集1%和99%分位数进行最小-最大缩放；`'mean_std'`表示执行Z-score标准化；`'none'`则返回未经过处理的原始数据。

- **`encode_strat`** (字符串)：可选值为`{'sin_cos', 'onehot', 'cat2vec', 'none'}`，默认值为`'sin_cos'`
用于土地分类（Land Classification, LC）数据的编码策略。各选项说明如下：`'onehot'`表示独热编码（one-hot encoding）；`'sin_cos'`表示正弦-余弦编码（sin_cos）；`'cat2vec'`表示基于训练集预计算的嵌入向量执行cat2vec变换；`'none'`表示不进行编码。

- **`input_features`** (字典)
用于指定需包含在数据中的特征，默认配置如下：
python
{'S2_bands': ['B01', 'B02', 'B03', 'B04', 'B05', 'B06', 'B07', 'B08', 'B8A', 'B09','B11', 'B12'],
'S2_dates' : False, 'lat_lon': True, 'GEDI_dates': False, 'ALOS': True, 'CH': True, 'LC': True,
'DEM': True, 'topo': False}

- **`additional_features`** (列表)，默认值为`[]`
用于指定数据集需额外包含的特征列表。*详细说明请参阅下文[附加特征](#add-feat-anchor)部分*。可选特征如下：
python
['s2_num_days', 'gedi_num_days', 'lat', 'lon', 'agbd_se', 'elev_lowes', 'leaf_off_f', 'pft_class', 'region_cla', 'rh98', 'sensitivity', 'solar_elev', 'urban_prop']

可通过如下方式访问该元数据：
python
from datasets import load_dataset

dataset = load_dataset('AGBD.py',trust_remote_code=True,streaming=True)
for sample in dataset['train']:
lat = sample['lat']
break

- **`patch_size`** (整数)，默认值为`15`
返回图像块的尺寸（单位：像素），最大值为**25像素**，对应**250米**的实地范围。

---
### 🖼️ 特征详情
每个样本的通道数会根据`load_dataset()`函数传入的`input_features`和`encode_strat`配置项动态变化，通道组织规则如下：

| 特征名称 | 通道组成 | 默认包含？ | 特征说明 |
| --- | --- | --- | --- |
| **哨兵二号（Sentinel-2）波段** | `B01, B02, B03, B04, B05, B06, B07, B08, B8A, B09, B11, B12` | 是 | 哨兵二号（Sentinel-2）地表反射率波段 |
| **哨兵二号日期信息** | `s2_num_days, s2_doy_cos, s2_doy_sin` | 否 | Sentinel-2图像的采集日期（以GEDI任务启动日为基准的天数）；以及一年中第几日（DOY）的正弦-余弦编码 |
| **地理坐标** | `lat_cos, lat_sin, lon_cos, lon_sin` | 是 | 纬度和经度的正弦-余弦编码 |
| **GEDI（地球科学激光测高卫星）日期信息** | `gedi_num_days, gedi_doy_cos, gedi_doy_sin` | 否 | GEDI足迹的采集日期（以GEDI任务启动日为基准的天数）；以及一年中第几日（DOY）的正弦-余弦编码 |
| **ALOS PALSAR-2 波段** | `HH, HV` | 是 | ALOS PALSAR-2 波段，单位为dB的gamma-naught值 |
| **冠层高度** | `ch, ch_std` | 是 | Lang等人发布的冠层高度数据及其标准差 |
| **土地覆盖信息** | `lc_encoding*, lc_prob` | 是 | 土地类别编码与分类概率（取值范围为0~1的百分比值） |
| **地形特征** | `slope, aspect_cos, aspect_sin` | 否 | 坡度（取值范围为0~1的百分比值）；坡向的正弦-余弦编码 |
| **数字高程模型（DEM）** | `dem` | 是 | 海拔高度（单位：米） |

此处对应默认的`input_features`配置：
python
{'S2_bands': ['B01', 'B02', 'B03', 'B04', 'B05', 'B06', 'B07', 'B08', 'B8A', 'B09','B11', 'B12'],
'S2_dates' : False, 'lat_lon': True, 'GEDI_dates': False, 'ALOS': True, 'CH': True, 'LC': True,
'DEM': True, 'topo': False}

关于`lc_encoding*`，其通道数遵循以下规则：
- `sin_cos`（默认配置）：2个通道
- `cat2vec`：5个通道
- `onehot`：14个通道
- `none`：1个通道

如遇通道数相关问题，可通过[AGBD.py](AGBD.py)中的`compute_num_features()`函数进行调试。

简言之，通道的组织结构如下：
plaintext
(哨兵二号波段) | (哨兵二号日期信息) | (地理坐标) | (GEDI日期信息) | (ALOS PALSAR-2 波段) | (冠层高度) | (土地覆盖信息) | (地形特征) | DEM

---
### ➕ 附加特征
<a name="add-feat-anchor"></a>
您可在数据集配置中加入以下可选的附加特征：
- **`"agbd_se"` - AGBD标准误差**：每个GEDI足迹对应的地上生物量密度预测的不确定性估计值。
- **`"elev_lowes"` - 海拔高度**：GEDI足迹所在位置的海平面以上高度。
- **`"leaf_off_f"` - 落叶季标志**：用于指示测量是否在落叶季进行，该因素会对冠层结构数据产生影响。
- **`"pft_class"` - 植物功能类型（PFT）类别**：植被类型的分类结果（例如落叶阔叶植被、常绿针叶植被）。
- **`"region_cla"` - 区域类别**：足迹所在的地理区域（例如北美、南亚）。
- **`"rh98"` - RH98（98%相对高度）**：反射回传感器的激光能量达到98%时对应的高度，是衡量冠层高度的关键指标。
- **`"sensitivity"` - 激光灵敏度**：反射回传感器的激光脉冲能量占总发射能量的比例，可用于反映植被密度与结构特征。
- **`"solar_elev"` - 太阳高度角**：测量时刻太阳相对于地平线的角度，会对数据质量产生影响。
- **`"urban_prop"` - 城市占比**：足迹范围内城市化区域的百分比，可用于过滤或调整混合景观中的生物量估算结果。
- **`"gedi_num_days"` - GEDI足迹采集日期**：每个GEDI足迹的具体捕获日期，为测量结果提供时间上下文。
- **`"s2_num_days"` - Sentinel-2图像采集日期**：每张Sentinel-2图像的具体拍摄日期，确保与GEDI数据的时间对齐。
- **`"lat"` - 纬度**：中心像素的纬度坐标。
- **`"lon"` - 经度**：中心像素的经度坐标。

搜集汇总

背景与挑战

背景概述

AGBD是一个全球生物量数据集，包含预裁剪的卫星图像和生物量标签，支持多种特征配置和元数据选项，适用于遥感研究和生态分析。
