miracl-vision

# MIRACL-VISION

MIRACL-VISION is a multilingual visual retrieval dataset for 18 different languages. It is an extension of MIRACL, a popular text-only multilingual retrieval dataset. The dataset contains user questions, images of Wikipedia articles and annotations, which article can answer a user question. There are 7898 questions and 338734 images. More details can be found in the paper [MIRACL-VISION: A Large, multilingual, visual document retrieval benchmark](https://arxiv.org/abs/2505.11651).

This dataset is ready for commercial usage for evaluation of the multilingual, multimodal retriever pipelines.

### Correspondence to
Benedikt Schifferer ([e-mail])

### Dataset Creation Date:
31st January 2025

### License/Terms of Use:
This dataset is licensed under Creative Commons Attribution-ShareAlike 4.0 International. Additional Information: Apache License 2.0.

### Intended Usage:
Users can evaluate multilingual, multimodal retriever pipelines.

### Dataset Characterization
Dataset Collection Method: Automated
Labelling Method: Human

### Dataset Format
The images are stored Pillow (PIL) Images in HuggingFace Dataset format
The questions, corpus, questions-corpus pairs are stored in parquet/BEIR format

### Reference(s):
```
@misc{osmulsk2025miraclvisionlargemultilingualvisual,
title={MIRACL-VISION: A Large, multilingual, visual document retrieval benchmark},
author={Radek Osmulsk and Gabriel de Souza P. Moreira and Ronay Ak and Mengyao Xu and Benedikt Schifferer and Even Oldridge},
year={2025},
eprint={2505.11651},
archivePrefix={arXiv},
primaryClass={cs.IR},
url={https://arxiv.org/abs/2505.11651},
}
```

### Ethical Considerations:
NVIDIA believes Trustworthy AI is a shared responsibility and we have established policies and practices to enable development for a wide array of AI applications. When downloaded or used in accordance with our terms of service, developers should work with their internal model team to ensure this model meets requirements for the relevant industry and use case and addresses unforeseen product misuse.

Please report security vulnerabilities or NVIDIA AI Concerns [here](https://www.nvidia.com/en-us/support/submit-security-vulnerability/).

### Example

The requirements are
```
pip install qwen_vl_utils beir==2.0.0
```

The dataset contains an [eval_example](https://huggingface.co/datasets/nvidia/miracl-vision/tree/main/eval_example) using [MrLight/dse-qwen2-2b-mrl-v1](https://huggingface.co/MrLight/dse-qwen2-2b-mrl-v1)​​

```bash
python embedding_eval.py --dataset nvidia/miracl-vision --language en
```

### Loading the Dataset

```python
from datasets import load_dataset

def hf_beir_queries(queries):
queries_beir = {}
for query in queries:
queries_beir[query['_id']] = query['text']
return(queries_beir)

def hf_beir_corpus(corpus):
corpus_beir = {}
for doc in corpus:
corpus_beir[doc['_id']] = doc
return(corpus_beir)

def hf_beir_qrels(qrels):
qrels_beir = {}
for el in qrels:
if str(el['query-id']) in qrels_beir:
qrels_beir[str(el['query-id'])][str(el['corpus-id'])] = el['score']
else:
qrels_beir[str(el['query-id'])] = {str(el['corpus-id']): el['score']}
return(qrels_beir)

def load_data(
path,
lang
):
queries = load_dataset(path, 'queries-' + str(lang), split='default')
queries = hf_beir_queries(queries)
corpus = load_dataset(path, 'corpus-' + str(lang), split='default')
corpus = hf_beir_corpus(corpus)
qrels = load_dataset(path, 'qrels-' + str(lang), split='default')
qrels = hf_beir_qrels(qrels)
images = load_dataset(path, 'images-' + str(lang), split='default')
return(queries, corpus, qrels, images)

queries, corpus, qrels, images = load_data('nvidia/miracl-vision', 'en')
```

### Dataset Statistics

Number of Images: 338734

Number of questions: 7898

Total Data Storage: 95GB

| | | MIRACL (original) | MIRACL (original) | MIRACL-VISION | MIRACL-VISION |
|--------------|-------------------|:-----------------:|:------------------------:|:----------------:|:------------------:|
| **Language** | **Language Code** | **# of queries** | **# of document chunks** | **# of queries** | **# of documents** |
| Arabic | ar | 2896 | 2061414 | 2127 | 75444 |
| Bengali | bn | 411 | 297265 | 229 | 8495 |
| Chinese | zh | 393 | 4934368 | 189 | 8672 |
| English | en | 799 | 32893221 | 447 | 42971 |
| Farsi | fa | 632 | 2207172 | 342 | 15846 |
| Finnish | fi | 1271 | 1883509 | 791 | 33679 |
| French | fr | 343 | 14636953 | 142 | 6990 |
| German | de | 305 | 15866222 | 129 | 6302 |
| Hindi | hi | 350 | 506264 | 184 | 8004 |
| Indonesian | id | 960 | 1446315 | 603 | 23842 |
| Japanese | ja | 860 | 6953614 | 387 | 17909 |
| Korean | ko | 213 | 1486752 | 130 | 5700 |
| Russian | ru | 1252 | 9543918 | 564 | 25201 |
| Spanish | es | 648 | 10373953 | 369 | 17749 |
| Swahili | sw | 482 | 131924 | 239 | 7166 |
| Telugu | te | 828 | 518079 | 480 | 15429 |
| Thai | th | 733 | 542166 | 451 | 16313 |
| Yoruba | yo | 119 | 49043 | 95 | 3022 |
| | | | | | |
| **Avereage** | | **750** | **5907342** | **439** | **18819** |

### Results

| | MIRACL-VISION (Text) | MIRACL-VISION (Text) | MIRACL-VISION (Text) | MIRACL-VISION (Text) | MIRACL-VISION (Image) | MIRACL-VISION (Image) | MIRACL-VISION (Image) | MIRACL-VISION (Image) |
|-------------------------|:-------------------------:|:---------------------------------:|:-------------------------:|:--------------------:|:-----------------------:|:----------------------------:|:---------------------:|:---------------------:|
| | **multilingual-e5-large** | **snowflake-arctic-embed-l-v2.0** | **gte-multilingual-base** | **bge-m3** | **dse-qwen2-2b-mrl-v1** | **gme-Qwen2-VL-2B-Instruct** | **vdr-2b-multi-v1** | **colqwen2-v1.0** |
| LLM Parameters (in M) | 560 | 567 | 305 | 567 | 1543 | 1543 | 1543 | 1543 |
| Language | | | | | | | | |
| Arabic | 0.8557 | 0.8754 | 0.8503 | 0.8883 | 0.3893 | 0.4888 | 0.4379 | 0.4129 |
| Bengali | 0.8421 | 0.8325 | 0.8211 | 0.8585 | 0.2352 | 0.3755 | 0.2473 | 0.2888 |
| Chinese | 0.6900 | 0.7179 | 0.7167 | 0.7458 | 0.5962 | 0.6314 | 0.5963 | 0.4926 |
| English | 0.7029 | 0.7437 | 0.7345 | 0.7348 | 0.6605 | 0.6784 | 0.6784 | 0.6417 |
| Farsi | 0.6793 | 0.7001 | 0.6984 | 0.7297 | 0.2250 | 0.3085 | 0.2398 | 0.2616 |
| Finnish | 0.8974 | 0.9014 | 0.8957 | 0.9071 | 0.4162 | 0.6863 | 0.5283 | 0.6604 |
| French | 0.7208 | 0.8236 | 0.7771 | 0.8158 | 0.7160 | 0.6851 | 0.7194 | 0.6876 |
| German | 0.7622 | 0.7774 | 0.7498 | 0.7695 | 0.6267 | 0.6345 | 0.6205 | 0.5995 |
| Hindi | 0.7595 | 0.7255 | 0.6916 | 0.7581 | 0.1740 | 0.3127 | 0.2058 | 0.2209 |
| Indonesian | 0.6793 | 0.6906 | 0.6757 | 0.7049 | 0.4866 | 0.5416 | 0.5254 | 0.5320 |
| Japanese | 0.8378 | 0.8484 | 0.8442 | 0.8720 | 0.6232 | 0.7305 | 0.6553 | 0.6970 |
| Korean | 0.7327 | 0.7545 | 0.7397 | 0.7934 | 0.4446 | 0.6202 | 0.4952 | 0.4419 |
| Russian | 0.7857 | 0.8242 | 0.8023 | 0.8363 | 0.6505 | 0.7202 | 0.6995 | 0.6811 |
| Spanish | 0.6596 | 0.7250 | 0.7029 | 0.7268 | 0.5927 | 0.6277 | 0.6274 | 0.6224 |
| Swahili | 0.8157 | 0.8089 | 0.7987 | 0.8337 | 0.4156 | 0.5348 | 0.4509 | 0.4931 |
| Telugu | 0.8948 | 0.9201 | 0.9076 | 0.9090 | 0.0274 | 0.0893 | 0.0318 | 0.0264 |
| Thai | 0.8424 | 0.8485 | 0.8509 | 0.8682 | 0.2692 | 0.3563 | 0.3177 | 0.2389 |
| Yoruba | 0.5655 | 0.5332 | 0.5698 | 0.5842 | 0.4178 | 0.4884 | 0.4577 | 0.5120 |
| | | | | | | | | |
| **Average** | **0.7624** | **0.7806** | **0.7682** | **0.7964** | **0.4426** | **0.5283** | **0.4741** | **0.4728** |
| **Average w/o Telugu** | **0.7546** | **0.7724** | **0.7600** | **0.7898** | **0.4670** | **0.5542** | **0.5002** | **0.4991** |

# MIRACL-VISION

MIRACL-VISION是一款面向18种语言的多语言视觉检索数据集，它是热门纯文本多语言检索数据集MIRACL的扩展版本。本数据集包含用户问题、维基百科文章配图以及标注信息（用于指明哪篇文档可解答对应用户问题），共计7898个用户问题与338734张配图。更多详细信息可参阅论文《MIRACL-VISION: A Large, multilingual, visual document retrieval benchmark》（https://arxiv.org/abs/2505.11651）。

本数据集可商用，用于评估多语言多模态检索流水线。

### 联系人
Benedikt Schifferer（邮箱：[e-mail]）

### 数据集创建日期
2025年1月31日

### 许可与使用条款
本数据集采用知识共享署名-相同方式共享4.0国际许可协议（Creative Commons Attribution-ShareAlike 4.0 International）进行授权。补充说明：同时适用Apache License 2.0。

### 预期用途
用户可使用本数据集评估多语言多模态检索流水线。

### 数据集特征
数据集采集方式：自动化采集
标注方式：人工标注

### 数据集格式
图片以Pillow（PIL）图像格式存储，采用HuggingFace Dataset格式组织；问题、文档库、问题-文档库对以parquet/BEIR格式存储。

### 参考文献

@misc{osmulsk2025miraclvisionlargemultilingualvisual,
title={MIRACL-VISION: A Large, multilingual, visual document retrieval benchmark},
author={Radek Osmulsk and Gabriel de Souza P. Moreira and Ronay Ak and Mengyao Xu and Benedikt Schifferer and Even Oldridge},
year={2025},
eprint={2505.11651},
archivePrefix={arXiv},
primaryClass={cs.IR},
url={https://arxiv.org/abs/2505.11651},
}

### 伦理考量
NVIDIA认为可信人工智能是一项共同责任，我们已建立相关政策与实践，以支持各类人工智能应用的开发。开发者在遵循本服务条款的前提下下载或使用本数据集时，应与其内部模型团队协作，确保该模型符合相关行业与应用场景的要求，并应对可能出现的产品误用问题。

请通过[此链接](https://www.nvidia.com/en-us/support/submit-security-vulnerability/)提交安全漏洞或NVIDIA人工智能相关问题。

### 示例
环境依赖安装命令：

pip install qwen_vl_utils beir==2.0.0

本数据集包含一个基于[MrLight/dse-qwen2-2b-mrl-v1](https://huggingface.co/MrLight/dse-qwen2-2b-mrl-v1)的[eval_example](https://huggingface.co/datasets/nvidia/miracl-vision/tree/main/eval_example)。

运行示例命令：
bash
python embedding_eval.py --dataset nvidia/miracl-vision --language en

### 数据集加载方法
python
from datasets import load_dataset

def hf_beir_queries(queries):
queries_beir = {}
for query in queries:
queries_beir[query['_id']] = query['text']
return(queries_beir)

def hf_beir_corpus(corpus):
corpus_beir = {}
for doc in corpus:
corpus_beir[doc['_id']] = doc
return(corpus_beir)

def hf_beir_qrels(qrels):
qrels_beir = {}
for el in qrels:
if str(el['query-id']) in qrels_beir:
qrels_beir[str(el['query-id'])][str(el['corpus-id'])] = el['score']
else:
qrels_beir[str(el['query-id'])] = {str(el['corpus-id']): el['score']}
return(qrels_beir)

def load_data(
path,
lang
):
queries = load_dataset(path, 'queries-' + str(lang), split='default')
queries = hf_beir_queries(queries)
corpus = load_dataset(path, 'corpus-' + str(lang), split='default')
corpus = hf_beir_corpus(corpus)
qrels = load_dataset(path, 'qrels-' + str(lang), split='default')
qrels = hf_beir_qrels(qrels)
images = load_dataset(path, 'images-' + str(lang), split='default')
return(queries, corpus, qrels, images)

queries, corpus, qrels, images = load_data('nvidia/miracl-vision', 'en')

### 数据集统计信息
图片总数：338734
用户问题总数：7898
总存储容量：95GB

| | | MIRACL（原版） | MIRACL（原版） | MIRACL-VISION | MIRACL-VISION |
|--------------|-------------------|:-----------------:|:------------------------:|:----------------:|:------------------:|
| **语言** | **语言代码** | **查询数量** | **文档块数量** | **查询数量** | **文档数量** |
| Arabic | ar | 2896 | 2061414 | 2127 | 75444 |
| Bengali | bn | 411 | 297265 | 229 | 8495 |
| Chinese | zh | 393 | 4934368 | 189 | 8672 |
| English | en | 799 | 32893221 | 447 | 42971 |
| Farsi | fa | 632 | 2207172 | 342 | 15846 |
| Finnish | fi | 1271 | 1883509 | 791 | 33679 |
| French | fr | 343 | 14636953 | 142 | 6990 |
| German | de | 305 | 15866222 | 129 | 6302 |
| Hindi | hi | 350 | 506264 | 184 | 8004 |
| Indonesian | id | 960 | 1446315 | 603 | 23842 |
| Japanese | ja | 860 | 6953614 | 387 | 17909 |
| Korean | ko | 213 | 1486752 | 130 | 5700 |
| Russian | ru | 1252 | 9543918 | 564 | 25201 |
| Spanish | es | 648 | 10373953 | 369 | 17749 |
| Swahili | sw | 482 | 131924 | 239 | 7166 |
| Telugu | te | 828 | 518079 | 480 | 15429 |
| Thai | th | 733 | 542166 | 451 | 16313 |
| Yoruba | yo | 119 | 49043 | 95 | 3022 |
| | | | | | |
| **平均** | | **750** | **5907342** | **439** | **18819** |

### 实验结果

| | MIRACL-VISION（文本模态） | MIRACL-VISION（文本模态） | MIRACL-VISION（文本模态） | MIRACL-VISION（文本模态） | MIRACL-VISION（图像模态） | MIRACL-VISION（图像模态） | MIRACL-VISION（图像模态） | MIRACL-VISION（图像模态） |
|-------------------------|:-------------------------:|:---------------------------------:|:-------------------------:|:--------------------:|:-----------------------:|:----------------------------:|:---------------------:|:---------------------:|
| | **multilingual-e5-large** | **snowflake-arctic-embed-l-v2.0** | **gte-multilingual-base** | **bge-m3** | **dse-qwen2-2b-mrl-v1** | **gme-Qwen2-VL-2B-Instruct** | **vdr-2b-multi-v1** | **colqwen2-v1.0** |
| 大语言模型参数量（单位：百万） | 560 | 567 | 305 | 567 | 1543 | 1543 | 1543 | 1543 |
| 语言 | | | | | | | | |
| 阿拉伯语 | 0.8557 | 0.8754 | 0.8503 | 0.8883 | 0.3893 | 0.4888 | 0.4379 | 0.4129 |
| 孟加拉语 | 0.8421 | 0.8325 | 0.8211 | 0.8585 | 0.2352 | 0.3755 | 0.2473 | 0.2888 |
| 中文 | 0.6900 | 0.7179 | 0.7167 | 0.7458 | 0.5962 | 0.6314 | 0.5963 | 0.4926 |
| 英语 | 0.7029 | 0.7437 | 0.7345 | 0.7348 | 0.6605 | 0.6784 | 0.6784 | 0.6417 |
| 波斯语 | 0.6793 | 0.7001 | 0.6984 | 0.7297 | 0.2250 | 0.3085 | 0.2398 | 0.2616 |
| 芬兰语 | 0.8974 | 0.9014 | 0.8957 | 0.9071 | 0.4162 | 0.6863 | 0.5283 | 0.6604 |
| 法语 | 0.7208 | 0.8236 | 0.7771 | 0.8158 | 0.7160 | 0.6851 | 0.7194 | 0.6876 |
| 德语 | 0.7622 | 0.7774 | 0.7498 | 0.7695 | 0.6267 | 0.6345 | 0.6205 | 0.5995 |
| 印地语 | 0.7595 | 0.7255 | 0.6916 | 0.7581 | 0.1740 | 0.3127 | 0.2058 | 0.2209 |
| 印尼语 | 0.6793 | 0.6906 | 0.6757 | 0.7049 | 0.4866 | 0.5416 | 0.5254 | 0.5320 |
| 日语 | 0.8378 | 0.8484 | 0.8442 | 0.8720 | 0.6232 | 0.7305 | 0.6553 | 0.6970 |
| 韩语 | 0.7327 | 0.7545 | 0.7397 | 0.7934 | 0.4446 | 0.6202 | 0.4952 | 0.4419 |
| 俄语 | 0.7857 | 0.8242 | 0.8023 | 0.8363 | 0.6505 | 0.7202 | 0.6995 | 0.6811 |
| 西班牙语 | 0.6596 | 0.7250 | 0.7029 | 0.7268 | 0.5927 | 0.6277 | 0.6274 | 0.6224 |
| 斯瓦希里语 | 0.8157 | 0.8089 | 0.7987 | 0.8337 | 0.4156 | 0.5348 | 0.4509 | 0.4931 |
| 泰卢固语 | 0.8948 | 0.9201 | 0.9076 | 0.9090 | 0.0274 | 0.0893 | 0.0318 | 0.0264 |
| 泰语 | 0.8424 | 0.8485 | 0.8509 | 0.8682 | 0.2692 | 0.3563 | 0.3177 | 0.2389 |
| 约鲁巴语 | 0.5655 | 0.5332 | 0.5698 | 0.5842 | 0.4178 | 0.4884 | 0.4577 | 0.5120 |
| | | | | | | | | |
| **平均** | **0.7624** | **0.7806** | **0.7682** | **0.7964** | **0.4426** | **0.5283** | **0.4741** | **0.4728** |
| **不含泰卢固语的平均** | **0.7546** | **0.7724** | **0.7600** | **0.7898** | **0.4670** | **0.5542** | **0.5002** | **0.4991** |
