# Key Features 🔑
- **1 million+** trajectories from 100 robots, with a total duration of 2976.4 hours.
- **100+ real-world scenarios** across 5 target domains.
- **Cutting-edge hardware:** visual tactile sensors / 6-DoF dexterous hand / mobile dual-arm robots
- **200+ types of tasks:**
- Contact-rich manipulation
- Long-horizon planning
- Multi-robot collaboration
- **87 types of Atomic Skills,** including Tie, OpenJar, Peel, Sweep etc.

<div style="display: flex; justify-content: center; align-items: center; gap: 20px;">
<video controls autoplay loop muted width="150" style="border-radius: 10px; box-shadow: 0 4px 8px rgba(0, 0, 0, 0.1);">
<source src="https://cdn-uploads.huggingface.co/production/uploads/65111094c3b9d8d1eb71329e/RxhpvglFxkqBKp0siHEjd.mp4" type="video/mp4">
Your browser does not support the video tag.
</video>
<video controls autoplay loop muted width="150" style="border-radius: 10px; box-shadow: 0 4px 8px rgba(0, 0, 0, 0.1);">
<source src="https://cdn-uploads.huggingface.co/production/uploads/65111094c3b9d8d1eb71329e/WwTyIz3wJpIL23E6mPrVp.mp4" type="video/mp4">
Your browser does not support the video tag.
</video>
<video controls autoplay loop muted width="150" style="border-radius: 10px; box-shadow: 0 4px 8px rgba(0, 0, 0, 0.1);">
<source src="https://cdn-uploads.huggingface.co/production/uploads/65111094c3b9d8d1eb71329e/WjJ_H4YzAmdZ5ffqG06-Y.mp4" type="video/mp4">
Your browser does not support the video tag.
</video>
</div>

# News 🌍
- **`[2025/3/1]`** AgiBot World Beta released.
- **`[2025/7/21]`** AgiBot World Beta released on ModelScope.

# Table of Contents
- [Key Features 🔑](#key-features-)
- [News 🌍](#news-)
- [Get started 🔥](#get-started-)
- [Download the Dataset](#download-the-dataset)
- [Dataset Structure](#dataset-structure)
- [Explanation of Proprioceptive State](#explanation-of-proprioceptive-state)
- [Dataset Preprocessing](#dataset-preprocessing)
- [License and Citation](#license-and-citation)

# Get started 🔥
## Download the Dataset
To download the full dataset, just click the download button. If you encounter any issues, please refer to the official ModelScope documentation. Git-LFS is also fully supported
```
# Make sure you have git-lfs installed (https://git-lfs.com)
git lfs install
git clone https://www.modelscope.cn/datasets/agibot_world/agibot_world_beta.git

```

To facilitate the inspection of the dataset's internal structure and examples, we also provide a sample dataset, which is approximately 7 GB. Please refer to `sample_dataset.tar`.

## Dataset Preprocessing
Our project relies solely on the [lerobot library](https://github.com/huggingface/lerobot) (dataset `v2.0`), please follow their [installation instructions](https://github.com/huggingface/lerobot?tab=readme-ov-file#installation).
Here, we provide scripts for converting it to the lerobot format. **Note** that you need to replace `/path/to/agibotworld/alpha` and `/path/to/save/lerobot` with the actual path.
```
python scripts/convert_to_lerobot.py --src_path /path/to/agibotworld/alpha --task_id 352 --tgt_path /path/to/save/lerobot
```
We would like to express our gratitude to the developers of lerobot for their outstanding contributions to the open-source community.

## Dataset Structure
### Folder hierarchy
```
data
├── task_info
│ ├── task_327.json
│ ├── task_352.json
│ └── ...
├── observations
│ ├── 327 # This represents the task id.
│ │ ├── 648642 # This represents the episode id.
│ │ │ ├── depth # This is a folder containing depth information saved in PNG format.
│ │ │ ├── videos # This is a folder containing videos from all camera perspectives.
│ │ ├── 648649
│ │ │ └── ...
│ │ └── ...
│ ├── 352
│ │ ├── 648544
│ │ │ ├── depth
│ │ │ ├── videos
│ │ ├── 648564
│ │ │ └── ...
│ └── ...
├── parameters
│ ├── 327
│ │ ├── 648642
│ │ │ ├── camera
│ │ ├── 648649
│ │ │ └── camera
│ │ └── ...
│ └── 352
│ ├── 648544
│ │ ├── camera # This contains all the cameras' intrinsic and extrinsic parameters.
│ └── 648564
│ │ └── camera
| └── ...
├── proprio_stats
│ ├── 327[task_id]
│ │ ├── 648642[episode_id]
│ │ │ ├── proprio_stats.h5 # This file contains all the robot's proprioceptive information.
│ │ ├── 648649
│ │ │ └── proprio_stats.h5
│ │ └── ...
│ ├── 352[task_id]
│ │ ├── 648544[episode_id]
│ │ │ ├── proprio_stats.h5
│ │ └── 648564
│ │ └── proprio_stats.h5
│ └── ...
```
### json file format
In the `task_[id].json` file, we store the basic information of every episode along with the language instructions. Here, we will further explain several specific keywords.
- **action_config**: The content corresponding to this key is a list composed of all **action slices** from the episode. Each action slice includes a start and end time, the corresponding atomic skill, and the language instruction.
- **key_frame**: The content corresponding to this key consists of annotations for keyframes, including the start and end times of the keyframes and detailed descriptions.

(`action_text` and `description` *are not available now, to be released by mid-January.*)
```
[ {"episode_id": 649078,
"task_id": 327,
"task_name": "Picking items in Supermarket",
"init_scene_text": "The robot is in front of the fruit shelf in the supermarket.",
"lable_info":{
"action_config":[
{"start_frame": 0,
"end_frame": 435,
"action_text": "Pick up onion from the shelf."
"skill": "Pick"
},
{"start_frame": 435,
"end_frame": 619,
"action_text": "Place onion into the plastic bag in the shopping cart."
"skill": "Place"
},
...
]
"key_frame": [
{"start": 0,
"end": 435,
"comment": "Failure recovery"
}
]
},
...
]
```
### h5 file format
In the `proprio_stats.h5` file, we store all the robot's proprioceptive data. For more detailed information, please refer to the [explanation of proprioceptive state](#explanation-of-proprioceptive-state).

```
|-- timestamp
|-- state
|-- effector
|-- force
|-- position
|-- end
|-- angular
|-- orientation
|-- position
|-- velocity
|-- wrench
|-- head
|-- effort
|-- position
|-- velocity
|-- joint
|-- current_value
|-- effort
|-- position
|-- velocity
|-- robot
|-- orientation
|-- orientation_drift
|-- position
|-- position_drift
|-- waist
|-- effort
|-- position
|-- velocity
|-- action
|-- effector
|-- force
|-- index
|-- position
|-- end
|-- orientation
|-- position
|-- head
|-- effort
|-- position
|-- velocity
|-- joint
|-- effort
|-- index
|-- position
|-- velocity
|-- robot
|-- index
|-- orientation
|-- position
|-- velocity
|-- waist
|-- effort
|-- position
|-- velocity
```
## Explanation of Proprioceptive State
### Terminology
*The definitions and data ranges in this section may change with software and hardware version. Stay tuned.*

**State and action**
1. State
State refers to the monitoring information of different sensors and actuators.
2. Action
Action refers to the instructions sent to the hardware abstraction layer, where controller would respond to these instructions. Therefore, there is a difference between the issued instructions and the actual executed state.

**Actuators**
1. ***Effector:*** refers to the end effector, for example dexterous hands or grippers.
2. ***End:*** refers to the 6DoF end pose on the robot flange.
3. ***Head:*** refers to the robot's head perspective，which has two degrees of freedom (pitch and yaw).
4. ***Joint:*** refers to the joints of the robot's dual arms, with 14 degrees of freedom (7 DoF each).
5. ***Robot:*** refers to the robot's pose in its surrouding environment. The orientation and position refer to the robot's relative pose in the odometry coordinate system, where the origin is set since the robot is powered on.
6. ***Waist:*** refers to the joints of the robot's waist, which has two degrees of freedom (pitch and lift).

### Common fields
1. Position: Spatial position, encoder position, angle, etc.
2. Velocity: Speed
3. Angular: Angular velocity
4. Effort: Torque of the motor. Not available for now.
5. Wrench: Six-dimensional force, force in the xyz directions, and torque. Not available for now.

### Value shapes and ranges
| Group | Shape | Meaning |
| --- | :---- | :---- |
| /timestamp | [N] | timestamp in nanoseconds |
| /state/effector/position (gripper) | [N, 2] | left `[:, 0]`, right `[:, 1]`, gripper open range in mm |
| /state/effector/position (dexhand) | [N, 12] | left `[:, :6]`, right `[:, 6:]`, joint angle in rad |
| /state/end/orientation | [N, 2, 4] | left `[:, 0, :]`, right `[:, 1, :]`, flange quaternion with xyzw |
| /state/end/position | [N, 2, 3] | left `[:, 0, :]`, right `[:, 1, :]`, flange xyz in meters |
| /state/head/position | [N, 2] | yaw `[:, 0]`, pitch `[:, 1]`, rad |
| /state/joint/current_value | [N, 14] | left arm `[:, :7]`, right arm `[:, 7:]` |
| /state/joint/position | [N, 14] | left arm `[:, :7]`, right arm `[:, 7:]`, rad |
| /state/robot/orientation | [N, 4] | quaternion in xyzw, yaw only |
| /state/robot/position | [N, 3] | xyz position, where z is always 0 in meters |
| /state/waist/position | [N, 2] | pitch `[:, 0]` in rad, lift `[:, 1]`in meters |
| /action/*/index | [M] | actions indexes refer to when the control source is actually sending signals |
| /action/effector/position (gripper) | [N, 2] | left `[:, 0]`, right `[:, 1]`, 0 for full open and 1 for full close |
| /action/effector/position (dexhand) | [N, 12] | same as /state/effector/position
| /action/effector/index | [M_1] | index when the control source for end effector is sending control signals |
| /action/end/orientation | [N, 2, 4] | same as /state/end/orientation |
| /action/end/position | [N, 2, 3] | same as /state/end/position |
| /action/end/index | [M_2] | same as other indexes |
| /action/head/position | [N, 2] | same as /state/head/position |
| /action/head/index | [M_3] | same as other indexes |
| /action/joint/position | [N, 14] | same as /state/joint/position |
| /action/joint/index | [M_4] | same as other indexes |
| /action/robot/velocity | [N, 2] | vel along x axis `[:, 0]`, yaw rate `[:, 1]` |
| /action/robot/index | [M_5] | same as other indexes |
| /action/waist/position | [N, 2] | same as /state/waist/position |
| /action/waist/index | [M_6] | same as other indexes |

# License and Citation
All the data and code within this repo are under [CC BY-NC-SA 4.0](https://creativecommons.org/licenses/by-nc-sa/4.0/). Please consider citing our project if it helps your research.

```BibTeX
@misc{contributors2024agibotworldrepo,
title={AgiBot World Colosseum},
author={AgiBot World Colosseum contributors},
howpublished={\url{https://github.com/OpenDriveLab/AgiBot-World}},
year={2024}
}
```
