# 🎤 Contrastive Semantic Alignment for Speech Referring Expression Comprehension ([CSRef](https://github.com/macrorise-lh/CSRef))



This repository contains the implementation of the approach described in the paper "CSRef: Contrastive Semantic Alignment for Speech Referring Expression Comprehension". 🚀

## 📋 Project Overview

### What is CSRef?

CSRef is a deep learning framework designed to comprehend referring expressions in speech and localize the corresponding objects in images. The framework employs a two-stage training approach:

1. **CSA Stage**: A pretraining stage that learns to align speech and text semantics through contrastive learning. It leverages the structured semantic space of text to guide the representation learning of raw speech.
2. **SREC Stage**: The main training stage that leverages the speech encoder from the CSA stage to perform referring expression comprehension by aligning speech with visual features.

### Key Features and Capabilities

- **Two-stage training approach**: First learns speech-text alignment, then applies it to speech-visual tasks
- **Multi-modal fusion**: Integrates speech and visual modalities effectively
- **Flexible architecture**: Supports various speech encoders and visual backbones

### Potential Applications and Use Cases

- **Human-computer interaction**: Enabling natural language control of computer vision systems
- **Robotic vision**: Allowing robots to understand and locate objects based on verbal descriptions

## 🛠️ Installation Instructions

### Prerequisites

- **Python**: 3.9.23 (tested with this version)
- **CUDA**: 12.6 or higher (for GPU support)
- **PyTorch**: 2.8 or higher
- **Operating System**: Linux (tested on Ubuntu 22.04)

### Step-by-Step Environment Setup

1. **Clone the repository**

```bash
git clone https://github.com/macrorise-lh/CSRef.git
cd CSRef
```

2. **Create a conda virtual environment**

```bash
conda create -n csref python=3.9
conda activate csref
```

3. **Install PyTorch**

```bash
# For CUDA 12.6
pip install torch torchvision --index-url https://download.pytorch.org/whl/cu126
```

4. **Install dependencies from requirements.txt**

```bash
pip install -r requirements.txt
```

## 💾 Data Preparation

Before training, you need to download and prepare the required datasets:

### Speech Referring Expressions Annotations

We provide two methods to obtain the speech referring expressions annotations:

#### Method 1: Automatic Download from [Hugging Face](https://huggingface.co/collections/lihong-huang/speech-referring-expression-comprehension-srec-68a97ed74ea0b45b56dcc4f9)

The simplest way is to use the Hugging Face dataset integration. When you run training with the `_hf` configuration files, the datasets will be automatically downloaded:

```bash
# Example: This will automatically download RefCOCO speech dataset from Hugging Face
CUDA_VISIBLE_DEVICES=0 PORT=23451 bash tools/train_speech.sh configs/csref_refcoco_speech_hf.py 1
```

Available datasets with automatic download:
- `configs/csref_refcoco_speech_hf.py` - RefCOCO_speech dataset
- `configs/csref_refcoco+_speech_hf.py` - RefCOCO+_speech dataset
- `configs/csref_refcocog_speech_hf.py` - RefCOCOg_speech dataset
- `configs/csref_srefface_hf.py` - SRRefFace dataset
- `configs/csref_srefface+_hf.py` - SRRefFace+ dataset
- `configs/csref_sreffaceg_hf.py` - SRRefFaceG dataset

#### Method 2: Manual Download from [ModelScope](https://modelscope.cn/datasets/lihongh/CSRef_data)

Alternatively, you can manually download the complete dataset and pre-trained model weights:

```bash
# Download from ModelScope
# Follow the link: https://modelscope.cn/datasets/lihongh/CSRef_data
# Extract files to the appropriate directories in the data folder following the Project Structure
```

**Advantages of Manual Download:**
- Complete offline access to all datasets
- Faster training startup (no download time)

**Data Organization:** 📁 After manual download, organize the files according to the directory structure shown in the [Project Structure](#-project-structure) section.

### 📦 Additional Required Datasets and Weights

1. **Download [LibriSpeech ASR dataset](https://www.openslr.org/12/) for CSA pre-training**

```bash
# Create directory
mkdir -p data/audios

# Download and extract LibriSpeech
cd data/audios
# train sets - 960 hours
wget https://www.openslr.org/resources/12/train-other-500.tar.gz
wget https://www.openslr.org/resources/12/train-clean-360.tar.gz
wget https://www.openslr.org/resources/12/train-clean-100.tar.gz
# dev sets
wget https://www.openslr.org/resources/12/dev-other.tar.gz
wget https://www.openslr.org/resources/12/dev-clean.tar.gz

tar -xvzf train-other-500.tar.gz
tar -xvzf train-clean-360.tar.gz
tar -xvzf train-clean-100.tar.gz
tar -xvzf dev-other.tar.gz
tar -xvzf dev-clean.tar.gz
cd ../../
```

2. **Download [COCO images](https://cocodataset.org/#download)**

```bash
# Create directory
mkdir -p data/images

# Download and extract COCO train2014 images
cd data/images
wget http://images.cocodataset.org/zips/train2014.zip
unzip train2014.zip
rm train2014.zip
cd ../../
```

3. **Download pre-trained encoders**

```bash
# Create directory
mkdir -p data/weights

# Download BERT and Wav2Vec2 models
cd data/weights
git lfs install
git clone https://huggingface.co/facebook/wav2vec2-base
git clone https://huggingface.co/google-bert/bert-base-uncased
cd ../../

# Download CSA pretrained Speech Encoder
wget https://modelscope.cn/datasets/lihongh/CSRef_data/resolve/master/data/weights/CSA_speech_encoder.pth

# Download pretrained visual backbone CSPDarkNet
# following https://github.com/luogen1996/SimREC/blob/main/DATA_PRE_README.md#pretrained-weights
# or https://modelscope.cn/datasets/lihongh/CSRef_data/resolve/master/data/weights/cspdarknet_coco.pth
```

## 🚀 Usage Examples

### 🏋️ Training

#### 🎯 CSA Stage Training

The CSA stage learns semantic alignment between speech and text modalities:

```bash
# Single GPU training
CUDA_VISIBLE_DEVICES=0 PORT=23450 bash tools/train_CSA.sh configs/csref_CSA_librispeech.py 1

# Multi-GPU training (4 GPUs)
CUDA_VISIBLE_DEVICES=1,2,3,4 PORT=23450 bash tools/train_CSA.sh configs/csref_CSA_librispeech.py 4
```

Key parameters:

- `CUDA_VISIBLE_DEVICES`: Specifies which GPUs to use
- `PORT`: Port number for distributed training
- `configs/csref_CSA_librispeech.py`: Configuration file for CSA stage
- `4`: Number of GPUs to use

#### 🔍 SREC Stage Training

The SREC stage uses the trained speech encoder to perform referring expression comprehension:

```bash
# Single GPU training on RefCOCO+
CUDA_VISIBLE_DEVICES=0 PORT=23451 bash tools/train_speech.sh configs/csref_refcoco_speech.py 1
```

You can also train on other datasets by using different configuration files:

- `configs/csref_refcoco_speech.py` / `configs/csref_refcoco_speech_hf.py`: For RefCOCO_speech dataset
- `configs/csref_refcoco+_speech.py` / `configs/csref_refcoco+_speech_hf.py`: For RefCOCO+_speech dataset
- `configs/csref_refcocog_speech.py` / `configs/csref_refcocog_speech_hf.py`: For RefCOCOg_speech dataset
- `configs/csref_srefface.py` / `configs/csref_srefface_hf.py`: For SRRefFace dataset
- `configs/csref_srefface+.py` / `configs/csref_srefface+_hf.py`: For SRRefFace+ dataset
- `configs/csref_sreffaceg.py` / `configs/csref_sreffaceg_hf.py`: For SRRefFaceG dataset

**Note:** Use configuration files with `_hf` suffix for automatic Hugging Face dataset download, or without `_hf` suffix if you have manually downloaded and organized the data.

### 📊 Evaluation

```bash
# Evaluate SREC model
# Using automatically downloaded Hugging Face datasets
CUDA_VISIBLE_DEVICES=0 PORT=23451 bash tools/eval_speech.sh configs/csref_refcoco_speech_hf.py 1 data/weights/csref_refcoco_speech.pth

# Using manually downloaded datasets
CUDA_VISIBLE_DEVICES=0 PORT=23451 bash tools/eval_speech.sh configs/csref_refcoco_speech.py 1 data/weights/csref_refcoco_speech.pth
```

**Note:** Make sure to use the corresponding configuration file (`_hf` or non-`_hf`) that matches your data preparation method.

## 📂 Project Structure

The CSRef project is organized as follows:

```
CSRef/
├── configs/ # Configuration files
│ ├── csref_*.py # Main configuration files for different datasets
│ └── common/ # Common configuration modules
│ ├── dataset_*.py # Dataset configurations
│ ├── optim.py # Optimizer configurations
│ ├── train.py # Training configurations
│ └── models/ # Model configurations
├── csref/ # Core library code
│ ├── config/ # Configuration management
│ ├── datasets/ # Dataset handling
│ ├── layers/ # Neural network layers
│ ├── models/ # Model definitions
│ │ ├── backbones/ # Visual backbones
│ │ ├── heads/ # Detection heads
│ │ ├── losses/ # Loss functions
│ │ ├── speech_encoders/ # Speech encoders
│ │ ├── text_encoder/ # Text encoders
│ │ └── utils/ # Model utilities
│ ├── scheduler/ # Learning rate schedulers
│ └── utils/ # Utility functions
├── tools/ # Training and evaluation scripts
│ ├── train_*.py # Training scripts
│ ├── train_*.sh # Training shell scripts
│ ├── eval_*.py # Evaluation scripts
│ └── eval_*.sh # Evaluation shell scripts
├── data/ # Data directory (to be created by user)
│ ├── audios/ # Audio files
│ │ ├── LibriSpeech/
│ │ ├── refcoco_speech/
│ │ ├── refcoco+_speech/
│ │ └── refcocog_speech/
│ ├── images/ # Image files
│ │ └── train2014/ # COCO train2014 images
│ ├── anns/ # Annotation files
│ │ ├── general_object/ # General object annotations (RefCOCO/RefCOCO+/RefCOCOg)
│ │ └── face_centric/ # Face-centric annotations (SRRefFace series)
│ ├── hf_cache/ # Hugging Face dataset cache (auto-created)
│ └── weights/ # Pre-trained model weights
│ ├── wav2vec2-base/ # Wav2Vec2 base model
│ ├── bert-base-uncased/ # BERT base uncased model
│ ├── CSA_speech_encoder.pth # Pre-trained CSA speech encoder
│ └── csref_*.pth # Trained CSRef model weights (if downloaded manually)
├── requirements.txt # Python dependencies
├── README.md # This file
└── .gitignore # Git ignore rules
```

## License Information

This project is licensed under the Apache-2.0 License - see the [LICENSE](LICENSE) file for details.

## Acknowledgement

Thanks a lot for the nicely organized code from the following repos:

- [SimREC](https://github.com/luogen1996/SimREC)

# 🎤 面向**语音指代表达理解（Speech Referring Expression Comprehension）**的**对比语义对齐（Contrastive Semantic Alignment）**方法（[CSRef](https://github.com/macrorise-lh/CSRef)）



本仓库包含论文《CSRef：面向语音指代表达理解的对比语义对齐方法》中所提方法的实现代码。🚀

## 📋 项目概览

### 何为CSRef？

CSRef是一款深度学习框架，旨在理解语音中的指代表达，并在图像中定位对应的目标物体。该框架采用两阶段训练流程：
1. **CSA阶段**：通过对比学习实现语音与文本语义对齐的预训练阶段，利用文本的结构化语义空间指导原始语音的表征学习。
2. **SREC阶段**：主训练阶段，复用CSA阶段训练得到的语音编码器，通过对齐语音与视觉特征完成指代表达理解任务。

### 关键特性与能力

- **两阶段训练范式**：先学习语音-文本语义对齐，再将其迁移至语音-视觉任务
- **多模态融合**：有效融合语音与视觉模态
- **灵活架构**：支持多种语音编码器与视觉骨干网络

### 潜在应用场景

- **人机交互**：实现计算机视觉系统的自然语言控制
- **机器人视觉**：允许机器人根据口头描述理解并定位目标物体

## 🛠️ 安装指南

### 前置依赖

- **Python**：3.9.23（已在此版本验证）
- **CUDA**：12.6及以上版本（用于GPU加速）
- **PyTorch**：2.8及以上版本
- **操作系统**：Linux（已在Ubuntu 22.04上测试）

### 分步环境搭建

1. **克隆仓库**

bash
git clone https://github.com/macrorise-lh/CSRef.git
cd CSRef

2. **创建Conda虚拟环境**

bash
conda create -n csref python=3.9
conda activate csref

3. **安装PyTorch**

bash
# For CUDA 12.6
pip install torch torchvision --index-url https://download.pytorch.org/whl/cu126

4. **通过requirements.txt安装依赖**

bash
pip install -r requirements.txt

## 💾 数据准备

在启动训练前，您需要下载并准备所需的数据集：

### 语音指代表达标注

我们提供两种方式获取语音指代表达标注：

#### 方式1：从[Hugging Face](https://huggingface.co/collections/lihong-huang/speech-referring-expression-comprehension-srec-68a97ed74ea0b45b56dcc4f9)自动下载

最简单的方式是使用Hugging Face数据集集成功能。当您使用带`_hf`后缀的配置文件运行训练时，数据集将自动下载：

bash
# 示例：该命令将从Hugging Face自动下载RefCOCO speech数据集
CUDA_VISIBLE_DEVICES=0 PORT=23451 bash tools/train_speech.sh configs/csref_refcoco_speech_hf.py 1

支持自动下载的数据集列表：
- `configs/csref_refcoco_speech_hf.py` - RefCOCO_speech数据集
- `configs/csref_refcoco+_speech_hf.py` - RefCOCO+_speech数据集
- `configs/csref_refcocog_speech_hf.py` - RefCOCOg_speech数据集
- `configs/csref_srefface_hf.py` - SRRefFace数据集
- `configs/csref_srefface+_hf.py` - SRRefFace+数据集
- `configs/csref_sreffaceg_hf.py` - SRRefFaceG数据集

#### 方式2：从[ModelScope](https://modelscope.cn/datasets/lihongh/CSRef_data)手动下载

您也可以手动下载完整数据集与预训练模型权重：

bash
# 从ModelScope下载
# 访问链接：https://modelscope.cn/datasets/lihongh/CSRef_data
# 按照项目结构章节中的目录说明，将文件解压至data目录的对应路径

**手动下载优势**：
- 可离线完整访问所有数据集
- 无需等待下载，可更快启动训练

**数据组织说明**：📁 手动下载后，请按照[项目结构](#-project-structure)章节中的目录结构整理文件。

### 📦 额外所需数据集与权重

1. **为CSA预训练下载[LibriSpeech ASR数据集](https://www.openslr.org/12/)**

bash
# 创建目录
mkdir -p data/audios

# 下载并解压LibriSpeech
cd data/audios
# 训练集 - 共960小时
wget https://www.openslr.org/resources/12/train-other-500.tar.gz
wget https://www.openslr.org/resources/12/train-clean-360.tar.gz
wget https://www.openslr.org/resources/12/train-clean-100.tar.gz
# 验证集
wget https://www.openslr.org/resources/12/dev-other.tar.gz
wget https://www.openslr.org/resources/12/dev-clean.tar.gz

tar -xvzf train-other-500.tar.gz
tar -xvzf train-clean-360.tar.gz
tar -xvzf train-clean-100.tar.gz
tar -xvzf dev-other.tar.gz
tar -xvzf dev-clean.tar.gz
cd ../../

2. **下载[COCO图像数据集](https://cocodataset.org/#download)**

bash
# 创建目录
mkdir -p data/images

# 下载并解压COCO train2014图像
cd data/images
wget http://images.cocodataset.org/zips/train2014.zip
unzip train2014.zip
rm train2014.zip
cd ../../

3. **下载预训练编码器**

bash
# 创建目录
mkdir -p data/weights

# 下载BERT与Wav2Vec2模型
cd data/weights
git lfs install
git clone https://huggingface.co/facebook/wav2vec2-base
git clone https://huggingface.co/google-bert/bert-base-uncased
cd ../../

# 下载CSA预训练语音编码器
wget https://modelscope.cn/datasets/lihongh/CSRef_data/resolve/master/data/weights/CSA_speech_encoder.pth

# 下载预训练视觉骨干网络CSPDarkNet
# 参考 https://github.com/luogen1996/SimREC/blob/main/DATA_PRE_README.md#pretrained-weights
# 或从 https://modelscope.cn/datasets/lihongh/CSRef_data/resolve/master/data/weights/cspdarknet_coco.pth 下载

## 🚀 使用示例

### 🏋️ 训练

#### 🎯 CSA阶段训练

CSA阶段用于学习语音与文本模态间的语义对齐：

bash
# 单GPU训练
CUDA_VISIBLE_DEVICES=0 PORT=23450 bash tools/train_CSA.sh configs/csref_CSA_librispeech.py 1

# 多GPU训练（4张GPU）
CUDA_VISIBLE_DEVICES=1,2,3,4 PORT=23450 bash tools/train_CSA.sh configs/csref_CSA_librispeech.py 4

关键参数说明：

- `CUDA_VISIBLE_DEVICES`：指定使用的GPU设备
- `PORT`：分布式训练所用的端口号
- `configs/csref_CSA_librispeech.py`：CSA阶段的配置文件
- `4`：使用的GPU数量

#### 🔍 SREC阶段训练

SREC阶段使用已训练好的语音编码器完成指代表达理解任务：

bash
# 在RefCOCO+数据集上进行单GPU训练
CUDA_VISIBLE_DEVICES=0 PORT=23451 bash tools/train_speech.sh configs/csref_refcoco_speech.py 1

您也可以通过更换配置文件在其他数据集上训练：

- `configs/csref_refcoco_speech.py` / `configs/csref_refcoco_speech_hf.py`：用于RefCOCO_speech数据集
- `configs/csref_refcoco+_speech.py` / `configs/csref_refcoco+_speech_hf.py`：用于RefCOCO+_speech数据集
- `configs/csref_refcocog_speech.py` / `configs/csref_refcocog_speech_hf.py`：用于RefCOCOg_speech数据集
- `configs/csref_srefface.py` / `configs/csref_srefface_hf.py`：用于SRRefFace数据集
- `configs/csref_srefface+.py` / `configs/csref_srefface+_hf.py`：用于SRRefFace+数据集
- `configs/csref_sreffaceg.py` / `configs/csref_sreffaceg_hf.py`：用于SRRefFaceG数据集

**注意**：若需自动从Hugging Face下载数据集，请使用带`_hf`后缀的配置文件；若已手动下载并整理数据集，则使用无`_hf`后缀的配置文件。

### 📊 评估

bash
# 评估SREC模型
# 使用自动下载的Hugging Face数据集
CUDA_VISIBLE_DEVICES=0 PORT=23451 bash tools/eval_speech.sh configs/csref_refcoco_speech_hf.py 1 data/weights/csref_refcoco_speech.pth

# 使用手动下载的数据集
CUDA_VISIBLE_DEVICES=0 PORT=23451 bash tools/eval_speech.sh configs/csref_refcoco_speech.py 1 data/weights/csref_refcoco_speech.pth

**注意**：请确保使用与数据准备方式匹配的配置文件（带`_hf`后缀或无`_hf`后缀）。

## 📂 项目结构

CSRef项目的目录结构如下：

CSRef/
├── configs/ # 配置文件目录
│ ├── csref_*.py # 适配不同数据集的主配置文件
│ └── common/ # 通用配置模块
│ ├── dataset_*.py # 数据集配置文件
│ ├── optim.py # 优化器配置文件
│ ├── train.py # 训练配置文件
│ └── models/ # 模型配置文件
├── csref/ # 核心库代码
│ ├── config/ # 配置管理模块
│ ├── datasets/ # 数据集处理模块
│ ├── layers/ # 神经网络层模块
│ ├── models/ # 模型定义目录
│ │ ├── backbones/ # 视觉骨干网络
│ │ ├── heads/ # 检测头模块
│ │ ├── losses/ # 损失函数模块
│ │ ├── speech_encoders/ # 语音编码器模块
│ │ ├── text_encoder/ # 文本编码器模块
│ │ └── utils/ # 模型工具函数
│ ├── scheduler/ # 学习率调度器模块
│ └── utils/ # 通用工具函数
├── tools/ # 训练与评估脚本目录
│ ├── train_*.py # 训练Python脚本
│ ├── train_*.sh # 训练Shell脚本
│ ├── eval_*.py # 评估Python脚本
│ └── eval_*.sh # 评估Shell脚本
├── data/ # 数据目录（需用户自行创建）
│ ├── audios/ # 音频文件目录
│ │ ├── LibriSpeech/
│ │ ├── refcoco_speech/
│ │ ├── refcoco+_speech/
│ │ └── refcocog_speech/
│ ├── images/ # 图像文件目录
│ │ └── train2014/ # COCO train2014图像目录
│ ├── anns/ # 标注文件目录
│ │ ├── general_object/ # 通用目标标注（RefCOCO/RefCOCO+/RefCOCOg）
│ │ └── face_centric/ # 以人脸为中心的标注（SRRefFace系列）
│ ├── hf_cache/ # Hugging Face数据集缓存目录（自动创建）
│ └── weights/ # 预训练模型权重目录
│ ├── wav2vec2-base/ # Wav2Vec2 base模型
│ ├── bert-base-uncased/ # BERT base uncased模型
│ ├── CSA_speech_encoder.pth # 预训练CSA语音编码器
│ └── csref_*.pth # 手动下载的训练好的CSRef模型权重
├── requirements.txt # Python依赖声明文件
├── README.md # 本说明文件
└── .gitignore # Git忽略规则文件

## 许可证信息

本项目采用Apache-2.0许可证，详细信息请参见[LICENSE](LICENSE)文件。

## 致谢

非常感谢以下开源仓库提供的优质代码框架：

- [SimREC](https://github.com/luogen1996/SimREC)

搜集汇总

背景与挑战

背景概述

该数据集是CSRef项目的数据文件夹，包含用于语音指代表达理解的多模态框架，该框架采用两阶段训练方法，先对齐语音与文本语义，再应用于语音-视觉任务。它支持多种语音和视觉编码器，适用于人机交互和机器人视觉等场景。
