唐家山堰塞体综合物探数据集

为开展堰塞体快速探测物探仪器开发研究需要，在唐家山堰塞体上开展了综合物探测量，包括：（1）CSAMT试验采集，设备采用自主研发的大地电磁系统，主要采集了该区域14个测点的CSAMT数据，用于测试大地电磁系统的探测范围、探测精度及仪器工作可靠性。（2）地质雷达数据采集，设备采用瑞典ImpulseRadar公司的CO1760型地质雷达，布置了5条测线（测线1全长103.25米，测线2全长48.8米，测线3全长53.5米，测线4全长57米，测线5全长95.3米），用于测试地质雷达的探测范围、探测精度及仪器工作可靠性。（3）高密度电阻率数据采集，设备采用重庆顶峰公司的EDJD-3多功能数字直流电法仪，采用温纳装置和偶极装置，布设了168个电极，电极距2米，测线长334米，共采集得到了4519个数据，用于测试高密度电法的探测范围、探测精度及仪器工作可靠性。（4）瞬变电磁数据采集，设备采用重庆顶峰公司的EATEM-2瞬变电磁仪，使用自研的可变匝数收发一体瞬变电磁线圈，布置了211个测点（L1线有测点56个，L2线有测点79个，L3线有测点76个），用于测试自研瞬变电磁线圈的探测范围、探测精度及仪器工作可靠性。（5）天然源面波数据采集，设备采用重庆顶峰公司的SDZ-24\48A数字工程地震仪，布设了6个测点，形成了1条剖面，用于测试天然源面波法的探测范围、探测精度及仪器工作可靠性。

To support the development of rapid geophysical detection instruments for barrier deposits, a comprehensive geophysical survey was conducted on the Tangjiashan barrier deposit, including the following contents:
(1) CSAMT test data acquisition: A self-developed magnetotelluric system was employed, and CSAMT data from 14 measuring points within this area were collected, which was used to test the detection range, detection accuracy and operating reliability of the magnetotelluric system.
(2) Ground Penetrating Radar (GPR) data acquisition: A CO1760-type GPR from ImpulseRadar of Sweden was adopted. Five survey lines were arranged (Survey Line 1: 103.25 m in total length, Survey Line 2: 48.8 m, Survey Line 3: 53.5 m, Survey Line 4: 57 m, Survey Line 5: 95.3 m), which was used to test the detection range, detection accuracy and operating reliability of the GPR.
(3) High-density resistivity data acquisition: An EDJD-3 multi-functional digital DC resistivity instrument from Chongqing Dingfeng Company was used. The Wenner array and dipole-dipole array were applied, with 168 electrodes arranged at an electrode spacing of 2 m, and the total length of the survey line was 334 m. A total of 4519 datasets were collected, which was used to test the detection range, detection accuracy and operating reliability of the high-density resistivity method.
(4) Transient Electromagnetic Method (TEM) data acquisition: An EATEM-2 transient electromagnetic instrument from Chongqing Dingfeng Company was utilized, paired with a self-developed variable-turns transceiver-integrated TEM coil. 211 measuring points were arranged (56 points on Line L1, 79 points on Line L2, 76 points on Line L3), which was used to test the detection range, detection accuracy and operating reliability of the self-developed TEM coil.
(5) Natural-source surface wave data acquisition: A SDZ-2448A digital engineering seismograph from Chongqing Dingfeng Company was employed. 6 measuring points were arranged to form one survey profile, which was used to test the detection range, detection accuracy and operating reliability of the natural-source surface wave method.

搜集汇总

背景与挑战

背景概述

该数据集包含唐家山堰塞体上进行的多种物探测量数据，包括CSAMT、地质雷达、高密度电阻率、瞬变电磁和天然源面波等方法的采集数据，用于测试不同仪器的探测范围、精度和可靠性。数据集由218.54MB的458个文件组成，涵盖了多个测点和测线的详细测量结果。
