SynCamVideo-Dataset

[Github](https://github.com/KwaiVGI/SynCamMaster)

[Project Page](https://jianhongbai.github.io/SynCamMaster/)

[Paper](https://arxiv.org/abs/2412.07760)

## 📷 Dataset: SynCamVideo Dataset

- __[2025.04.15]__: Release a new version of the SynCamVideo Dataset with improved quality and greater diversity.
- __[2025.04.15]__: Please also check our [MultiCamVideo](https://huggingface.co/datasets/KwaiVGI/MultiCamVideo-Dataset) Dataset.
### 1. Dataset Introduction

**TL;DR:** The SynCamVideo Dataset is a multi-camera synchronized video dataset rendered using Unreal Engine 5. It includes synchronized multi-camera videos and their corresponding camera poses. The SynCamVideo Dataset can be valuable in fields such as camera-controlled video generation, synchronized video production, and 3D/4D reconstruction. The camera is stationary in the SynCamVideo Dataset. If you require footage with moving cameras rather than stationary ones, please explore our [MultiCamVideo](https://huggingface.co/datasets/KwaiVGI/MultiCamVideo-Dataset) Dataset.

<div align="center">
<video controls autoplay style="width: 70%;" src="https://cdn-uploads.huggingface.co/production/uploads/6530bf50f145530101ec03a2/qEUQstpMa3-6UjbG_0ytq.mp4"></video>
</div>

The SynCamVideo Dataset is a multi-camera synchronized video dataset rendered using Unreal Engine 5. It includes synchronized multi-camera videos and their corresponding camera poses.
It consists of 3.4K different dynamic scenes, each captured by 10 cameras, resulting in a total of 34K videos. Each dynamic scene is composed of four elements: {3D environment, character, animation, camera}. Specifically, we use animation to drive the character
and position the animated character within the 3D environment. Then, Time-synchronized cameras are set up to render the multi-camera video data.
<p align="center">
<img src="https://github.com/user-attachments/assets/107c9607-e99b-4493-b715-3e194fcb3933" alt="Example Image" width="70%">
</p>

**3D Environment:** We collect 37 high-quality 3D environments assets from [Fab](https://www.fab.com). To minimize the domain gap between rendered data and real-world videos, we primarily select visually realistic 3D scenes, while choosing a few stylized or surreal 3D scenes as a supplement. To ensure data diversity, the selected scenes cover a variety of indoor and outdoor settings, such as city streets, shopping malls, cafes, office rooms, and the countryside.

**Character:** We collect 66 different human 3D models as characters from [Fab](https://www.fab.com) and [Mixamo](https://www.mixamo.com).

**Animation:** We collect 93 different animations from [Fab](https://www.fab.com) and [Mixamo](https://www.mixamo.com), including common actions such as waving, dancing, and cheering. We use these animations to drive the collected characters and create diverse datasets through various combinations.

**Camera:** To enhance the diversity of the dataset, each camera is randomly sampled on a hemispherical surface centered around the character.

### 2. Statistics and Configurations

Dataset Statistics:

| Number of Dynamic Scenes | Camera per Scene | Total Videos |
|:------------------------:|:----------------:|:------------:|
| 3400 | 10 | 34,000 |

Video Configurations:

| Resolution | Frame Number | FPS |
|:-----------:|:------------:|:------------------------:|
| 1280x1280 | 81 | 15 |

Note: You can use 'center crop' to adjust the video's aspect ratio to fit your video generation model, such as 16:9, 9:16, 4:3, or 3:4.

Camera Configurations:

| Focal Length | Aperture | Sensor Height | Sensor Width |
|:-----------------------:|:------------------:|:-------------:|:------------:|
| 24mm | 5.0 | 23.76mm | 23.76mm |

### 3. File Structure
```
SynCamVideo-Dataset
├── train
│ └── f24_aperture5
│ ├── scene1 # one dynamic scene
│ │ ├── videos
│ │ │ ├── cam01.mp4 # synchronized 81-frame videos at 1280x1280 resolution
│ │ │ ├── cam02.mp4
│ │ │ ├── ...
│ │ │ └── cam10.mp4
│ │ └── cameras
│ │ └── camera_extrinsics.json # 81-frame camera extrinsics of the 10 cameras
│ ├── ...
│ └── scene3400
└── val
└── basic
├── videos
│ ├── cam01.mp4 # example videos corresponding to the validation cameras
│ ├── cam02.mp4
│ ├── ...
│ └── cam10.mp4
└── cameras
└── camera_extrinsics.json # 10 cameras for validation
```

### 3. Useful scripts
- Data Extraction
```bash
tar -xzvf SynCamVideo-Dataset.tar.gz
```
- Camera Visualization
```python
python vis_cam.py
```

<p align="center">
<img src="https://cdn-uploads.huggingface.co/production/uploads/6530bf50f145530101ec03a2/3WCWS0Axlnu5MyOBqMoVC.png" alt="Example Image" width="40%">
</p>

## Acknowledgments
We thank Jinwen Cao, Yisong Guo, Haowen Ji, Jichao Wang, and Yi Wang from Kuaishou Technology for their invaluable help in constructing the SynCamVideo-Dataset.

## 🌟 Citation

Please cite our paper if you find our dataset helpful.
```
@misc{bai2024syncammaster,
title={SynCamMaster: Synchronizing Multi-Camera Video Generation from Diverse Viewpoints},
author={Jianhong Bai and Menghan Xia and Xintao Wang and Ziyang Yuan and Xiao Fu and Zuozhu Liu and Haoji Hu and Pengfei Wan and Di Zhang},
year={2024},
eprint={2412.07760},
archivePrefix={arXiv},
primaryClass={cs.CV},
url={https://arxiv.org/abs/2412.07760},
}
```

## Contact

[Jianhong Bai](https://jianhongbai.github.io/)

[Github](https://github.com/KwaiVGI/SynCamMaster)

[项目主页](https://jianhongbai.github.io/SynCamMaster/)

[论文](https://arxiv.org/abs/2412.07760)

## 📷 数据集：SynCamVideo 数据集（SynCamVideo Dataset）

- __[2025.04.15]__: 发布SynCamVideo 数据集的新版本，画质优化且多样性进一步提升。
- __[2025.04.15]__: 请同时查阅我们的MultiCamVideo 数据集（MultiCamVideo Dataset）。
### 1. 数据集简介

**TL;DR:** SynCamVideo 数据集是基于虚幻引擎5（Unreal Engine 5）渲染的多相机同步视频数据集，包含同步多相机视频及其对应的相机位姿。该数据集可应用于相机可控视频生成、同步视频制作以及3D/4D重建等领域。本数据集中相机均为静止状态，若需要包含运动相机的镜头素材，请参考我们的MultiCamVideo 数据集（MultiCamVideo Dataset）。

<div align="center">
<video controls autoplay style="width: 70%;" src="https://cdn-uploads.huggingface.co/production/uploads/6530bf50f145530101ec03a2/qEUQstpMa3-6UjbG_0ytq.mp4"></video>
</div>

SynCamVideo 数据集是基于虚幻引擎5（Unreal Engine 5）渲染的多相机同步视频数据集，包含同步多相机视频及其对应的相机位姿。
该数据集包含3400个不同的动态场景，每个场景由10台相机采集，总计生成34000段视频。每个动态场景由四大要素构成：{3D环境、角色、动画、相机}。具体而言，我们通过动画驱动角色，并将该动画角色放置于3D环境中。随后，设置时间同步的多台相机以渲染多相机视频数据。
<p align="center">
<img src="https://github.com/user-attachments/assets/107c9607-e99b-4493-b715-3e194fcb3933" alt="示例图像" width="70%">
</p>

**3D环境：** 我们从[Fab](https://www.fab.com)平台收集了37个高质量3D环境资产。为缩小渲染数据与真实世界视频的域间隙，我们优先选择视觉效果写实的3D场景，同时辅以少量风格化或超现实3D场景作为补充。为保证数据多样性，所选场景覆盖多种室内外场景，包括城市街道、购物中心、咖啡馆、办公室以及乡村场景等。

**角色：** 我们从[Fab](https://www.fab.com)和[Mixamo](https://www.mixamo.com)平台收集了66个不同的人类3D模型作为角色。

**动画：** 我们从[Fab](https://www.fab.com)和[Mixamo](https://www.mixamo.com)平台收集了93种不同的动画，包括挥手、跳舞、欢呼等常见动作。我们使用这些动画驱动收集到的角色，并通过多种组合方式构建多样化数据集。

**相机：** 为增强数据集的多样性，每个相机均在以角色为中心的半球面上随机采样得到。

### 2. 统计信息与配置参数
数据集统计：

| 动态场景数量 | 单场景相机数 | 总视频数 |
|:------------------------:|:----------------:|:------------:|
| 3400 | 10 | 34,000 |

视频配置：

| 分辨率 | 帧数 | 帧率 |
|:-----------:|:------------:|:------------------------:|
| 1280x1280 | 81 | 15 |

注：您可通过**中心裁剪（center crop）**调整视频宽高比，以适配各类视频生成模型，例如16:9、9:16、4:3或3:4。

相机配置：

| 焦距 | 光圈 | 传感器高度 | 传感器宽度 |
|:-----------------------:|:------------------:|:-------------:|:------------:|
| 24mm | 5.0 | 23.76mm | 23.76mm |

### 3. 文件结构

SynCamVideo-Dataset
├── train
│ └── f24_aperture5
│ ├── scene1 # 单个动态场景
│ │ ├── videos
│ │ │ ├── cam01.mp4 # 分辨率1280x1280、含81帧的同步视频
│ │ │ ├── cam02.mp4
│ │ │ ├── ...
│ │ │ └── cam10.mp4
│ │ └── cameras
│ │ └── camera_extrinsics.json # 10台相机的81帧相机外参
│ ├── ...
│ └── scene3400
└── val
└── basic
├── videos
│ ├── cam01.mp4 # 验证相机对应的示例视频
│ ├── cam02.mp4
│ ├── ...
│ └── cam10.mp4
└── cameras
└── camera_extrinsics.json # 用于验证的10台相机

### 3. 实用脚本
- 数据解压
bash
tar -xzvf SynCamVideo-Dataset.tar.gz

- 相机可视化
python
python vis_cam.py

<p align="center">
<img src="https://cdn-uploads.huggingface.co/production/uploads/6530bf50f145530101ec03a2/3WCWS0Axlnu5MyOBqMoVC.png" alt="示例图像" width="40%">
</p>

## 致谢
感谢来自快手科技（Kuaishou Technology）的曹晋文、郭义松、纪浩文、王吉超以及王毅在构建SynCamVideo 数据集过程中提供的宝贵帮助。

## 🌟 引用
若您认为本数据集对您的研究有所帮助，请引用我们的论文：

@misc{bai2024syncammaster,
title={SynCamMaster: Synchronizing Multi-Camera Video Generation from Diverse Viewpoints},
author={Jianhong Bai and Menghan Xia and Xintao Wang and Ziyang Yuan and Xiao Fu and Zuozhu Liu and Haoji Hu and Pengfei Wan and Di Zhang},
year={2024},
eprint={2412.07760},
archivePrefix={arXiv},
primaryClass={cs.CV},
url={https://arxiv.org/abs/2412.07760},
}

## 联系方式

[白建宏](https://jianhongbai.github.io/)
