# Constellation TLEs — 18 Satellite Constellations

<div align="center">
<img src="banner.jpg" alt="An orbital sunrise illuminates the Earth's atmosphere, seen from the ISS" width="400">
<p><em>Credit: NASA</em></p>
</div>

*Part of the [Orbital Mechanics Datasets](https://huggingface.co/collections/juliensimon/orbital-mechanics-datasets-69c24caca4ab3934c9856994) collection on Hugging Face.*


Daily Two-Line Element (TLE) snapshots for **17** satellite constellations
totaling **1,783** satellites, sourced from [CelesTrak](https://celestrak.org/).
Each constellation is available as a separate config for independent loading.

## Constellations

| Constellation | Operator | Orbit | Satellites |
|---------------|----------|-------|----------:|
| OneWeb | Eutelsat OneWeb | LEO | 651 |
| Kuiper | Amazon | LEO | 239 |
| Qianfan (G60) | Shanghai Spacecom | LEO | 108 |
| Hulianwang (GuoWang) | China SatNet | LEO | 168 |
| Iridium NEXT | Iridium | LEO | 80 |
| Globalstar | Globalstar | LEO | 28 |
| ORBCOMM | ORBCOMM | LEO | 15 |
| Planet Labs | Planet Labs | LEO | 136 |
| Spire Global | Spire Global | LEO | 76 |
| GPS (NAVSTAR) | USSF | MEO | 39 |
| Galileo | EU/ESA | MEO | 50 |
| BeiDou | CNSA | MEO/GEO | 56 |
| SBAS | Various | GEO | 6 |
| SES | SES | GEO | 70 |
| Intelsat | Intelsat | GEO | 27 |
| Eutelsat | Eutelsat | GEO | 29 |
| Telesat | Telesat | GEO/LEO | 5 |

**Total: 1,783 satellites** — 1,501 LEO, 145 MEO, 137 GEO

## Dataset description

Two-Line Element sets (TLEs) are the standard format for representing satellite orbital
elements, developed by NORAD and used universally with the SGP4/SDP4 propagation model.
This dataset provides daily-fresh TLEs for every major non-Starlink constellation in orbit,
organized by operator for easy access.

The collection spans four categories:

**GNSS navigation** (GPS, Galileo, BeiDou, GLONASS, SBAS) — the backbone of global
positioning in MEO/GEO, critical for timing applications, geodesy, and as reference
orbits for propagation model validation.

**LEO broadband** (OneWeb, Kuiper, Qianfan, Hulianwang) — the next wave of
mega-constellations competing with Starlink. OneWeb is fully deployed at 1,200 km;
Amazon's Kuiper and China's Qianfan/Hulianwang are in early deployment phases.

**LEO communications and IoT** (Iridium NEXT, Globalstar, ORBCOMM) — established
mobile satellite service providers operating in low Earth orbit.

**Earth observation** (Planet Labs, Spire Global) — the largest commercial imaging
and weather monitoring fleets, operating in sun-synchronous orbits.

**GEO communications** (SES, Intelsat, Eutelsat, Telesat) — legacy geostationary
operators providing broadcast, broadband, and government services from 35,786 km.

Raw `.tle` files are provided alongside Parquet for maximum compatibility: orbit
propagation libraries like `python-sgp4`, `orekit`, and STK consume the standard
three-line TLE format directly. Because TLE accuracy degrades rapidly (especially
for LEO objects), daily updates are essential for operational applications.

Starlink TLEs are published separately in
[starlink-tle-latest](https://huggingface.co/datasets/juliensimon/starlink-tle-latest)
due to the constellation's size (7,000+ satellites).

## Raw TLE files

For applications that consume standard 3-line TLE format (e.g., SGP4 propagators):

- [`data/oneweb.tle`](https://huggingface.co/datasets/juliensimon/constellation-tle-latest/resolve/main/data/oneweb.tle) — OneWeb
- [`data/kuiper.tle`](https://huggingface.co/datasets/juliensimon/constellation-tle-latest/resolve/main/data/kuiper.tle) — Kuiper
- [`data/qianfan.tle`](https://huggingface.co/datasets/juliensimon/constellation-tle-latest/resolve/main/data/qianfan.tle) — Qianfan (G60)
- [`data/hulianwang.tle`](https://huggingface.co/datasets/juliensimon/constellation-tle-latest/resolve/main/data/hulianwang.tle) — Hulianwang (GuoWang)
- [`data/iridium.tle`](https://huggingface.co/datasets/juliensimon/constellation-tle-latest/resolve/main/data/iridium.tle) — Iridium NEXT
- [`data/globalstar.tle`](https://huggingface.co/datasets/juliensimon/constellation-tle-latest/resolve/main/data/globalstar.tle) — Globalstar
- [`data/orbcomm.tle`](https://huggingface.co/datasets/juliensimon/constellation-tle-latest/resolve/main/data/orbcomm.tle) — ORBCOMM
- [`data/planet.tle`](https://huggingface.co/datasets/juliensimon/constellation-tle-latest/resolve/main/data/planet.tle) — Planet Labs
- [`data/spire.tle`](https://huggingface.co/datasets/juliensimon/constellation-tle-latest/resolve/main/data/spire.tle) — Spire Global
- [`data/gps.tle`](https://huggingface.co/datasets/juliensimon/constellation-tle-latest/resolve/main/data/gps.tle) — GPS (NAVSTAR)
- [`data/galileo.tle`](https://huggingface.co/datasets/juliensimon/constellation-tle-latest/resolve/main/data/galileo.tle) — Galileo
- [`data/beidou.tle`](https://huggingface.co/datasets/juliensimon/constellation-tle-latest/resolve/main/data/beidou.tle) — BeiDou
- [`data/sbas.tle`](https://huggingface.co/datasets/juliensimon/constellation-tle-latest/resolve/main/data/sbas.tle) — SBAS
- [`data/ses.tle`](https://huggingface.co/datasets/juliensimon/constellation-tle-latest/resolve/main/data/ses.tle) — SES
- [`data/intelsat.tle`](https://huggingface.co/datasets/juliensimon/constellation-tle-latest/resolve/main/data/intelsat.tle) — Intelsat
- [`data/eutelsat.tle`](https://huggingface.co/datasets/juliensimon/constellation-tle-latest/resolve/main/data/eutelsat.tle) — Eutelsat
- [`data/telesat.tle`](https://huggingface.co/datasets/juliensimon/constellation-tle-latest/resolve/main/data/telesat.tle) — Telesat

## Schema (all configs)

| Column | Type | Description |
|--------|------|-------------|
| `name` | string | Satellite name (e.g., "ONEWEB-0012", "NAVSTAR 78", "GALILEO 27") |
| `line1` | string | TLE line 1: epoch, drag term, BSTAR, element set number |
| `line2` | string | TLE line 2: inclination, RAAN, eccentricity, arg of perigee, mean anomaly, mean motion |

## Quick stats

- **1,783** satellites across **17** constellations
- **1,501** LEO + **145** MEO + **137** GEO
- Snapshot: 2026-04-11 06:37 UTC

## Usage

```python
from datasets import load_dataset

# Load a specific constellation
gps = load_dataset("juliensimon/constellation-tle-latest", "gps", split="train")
oneweb = load_dataset("juliensimon/constellation-tle-latest", "oneweb", split="train")
galileo = load_dataset("juliensimon/constellation-tle-latest", "galileo", split="train")

# Use with sgp4 library for orbit propagation
from sgp4.api import Satrec
sat = Satrec.twoline2rv(gps[0]["line1"], gps[0]["line2"])

# Load all GNSS constellations
import pandas as pd
gnss = pd.concat([
load_dataset("juliensimon/constellation-tle-latest", c, split="train").to_pandas()
for c in ["gps", "galileo", "beidou", "glonass", "sbas"]
])
print(f"{len(gnss)} GNSS satellites")

# Compare constellation sizes
for config in ["oneweb", "iridium", "planet", "spire"]:
ds = load_dataset("juliensimon/constellation-tle-latest", config, split="train")
print(f"{config}: {len(ds)} satellites")
```

## Data source

[CelesTrak](https://celestrak.org/) (Dr. T.S. Kelso), mirroring NORAD/18th Space
Defense Squadron data. No authentication required.

## Update schedule

Daily at 05:30 UTC via [GitHub Actions](https://github.com/juliensimon/space-datasets).

## Related datasets

- [starlink-tle-latest](https://huggingface.co/datasets/juliensimon/starlink-tle-latest) — Daily Starlink + GPS TLEs (dedicated dataset for the largest constellation)
- [space-track-tle-history](https://huggingface.co/datasets/juliensimon/space-track-tle-history) — 238M+ historical TLEs for every cataloged object (1959–present)
- [constellation-census](https://huggingface.co/datasets/juliensimon/constellation-census) — Parsed orbital elements with status classification for all constellations
- [space-track-satcat](https://huggingface.co/datasets/juliensimon/space-track-satcat) — Complete NORAD satellite catalog (68K+ objects)
- [ucs-satellite-database](https://huggingface.co/datasets/juliensimon/ucs-satellite-database) — Active satellites with purpose, operator, and orbit metadata

## Pipeline

Source code: [juliensimon/space-datasets](https://github.com/juliensimon/space-datasets)

## Support

If you find this dataset useful, please give it a ❤️ on the [dataset page](https://huggingface.co/datasets/juliensimon/constellation-tle-latest) and share feedback in the Community tab! Also consider giving a ⭐️ to the [space-datasets](https://github.com/juliensimon/space-datasets) repo.

## Citation

```bibtex
@dataset{constellation_tle_latest,
author = {Simon, Julien},
title = {Constellation TLEs — 18 Satellite Constellations},
year = {2026},
publisher = {Hugging Face},
url = {https://huggingface.co/datasets/juliensimon/constellation-tle-latest},
note = {Based on NORAD data via CelesTrak (Dr. T.S. Kelso)}
}
```

## License

[CC-BY-4.0](https://creativecommons.org/licenses/by/4.0/)
