兼容C波段和毫米波的共口径天线阵列

兼容C波段和毫米波的共口径天线阵列主要面向5G及下一代移动通信发展和需求，研究共享辐射孔径的兼容C波段和毫米波的双频基站天线。通过兼容和共享口径方式提高设备及空间利用率，节省成本。基于插花模式，实现了6×4C波段天线阵列和4×4毫米波阵列双频共口径天线。基于HFSS仿真软件及矢量网络分析仪、天线测量暗室等仪器及第三方测试机构测试，主要记录了C波段天线阵列在3.3-3.6GHz驻波比，所有相邻单元之间隔离度，波束扫描角度等观测值，数据量98.5MB。

This dataset centers on dual-band base station antennas compatible with both C-band and millimeter-wave that share a common radiating aperture, developed to meet the demands of 5G and next-generation mobile communications. This shared-aperture compatible design enhances equipment and spatial utilization while reducing development costs. By adopting the interleaved configuration, a dual-band shared-aperture antenna integrating a 6×4 C-band antenna array and a 4×4 millimeter-wave array is implemented. Characterization was conducted via HFSS simulation software, vector network analyzers, antenna measurement anechoic chambers, and third-party testing organizations. The dataset primarily records measured data including the voltage standing wave ratio (VSWR) of the C-band antenna array within the 3.3–3.6 GHz frequency range, the isolation between every pair of adjacent elements, and beam scanning angles, with a total data volume of 98.5 MB.

搜集汇总

背景与挑战

背景概述

该数据集专注于5G及下一代移动通信中的双频基站天线技术，通过共口径设计实现了C波段（3.3-3.6GHz）和毫米波频段的兼容，旨在提高设备利用率和节省成本。数据包括仿真和实测结果，如驻波比、隔离度和波束扫描参数，总数据量98.5MB，涵盖多种文件格式，适用于天线设计与通信研究领域。
