Historical Imagery 1990

Historical Imagery 1990\n\nCurrent and\nhistoric imagery form an important part of the NSW Foundation Spatial Data\nFramework and provide a valuable resource which is widely accessed by\ngovernment and the broader community on a daily basis. As the completeness of\nthis data base continues, its market demand also increases across a broad range\nof applications.\n\nSpatial Services\naerial imagery was originally captured using a variety of cameras including the\nWild RC-5, RC-10 and Leica RC-30 cameras with a variety of lenses with focal\nlengths of 88mm, 153mm and 304mm. Images were captured in monochrome or colour\nduring this period at a range of scales. Capture scales ranged from 1:5 000 to\n1:80 000.\n\nThe Historical Air\nPhoto Enhancement program (HAPE) not only allows the capability to search,\ndiscover and use source imagery, but also provides the delivery and viewing of\nenhanced historic rectified imagery mosaics. This new development means the\ncommunity at large can now access and utilise spatially accurate historic\nimagery:\n\n1.   Through\nthe Historical Imagery Viewer\n\n2.   Directly\nin a wide range for GIS Mapping applications as a Web map Tile Service\n(WMTS). See below for instructions\n\n3.   Order\nthe JP2 Mosaics direct and use locally. Contact us via the Customer Hub.\n\nAccessing the\nWMTS in ARCMAP or ARCPRO\n\nOpen Catalogue\nwindow\n\nClick Catalog\n> GIS Servers > Add WMTS server\n\nSpecify this\nurl:\n\nhttps://portal.spatial.nsw.gov.au/tileservices/Hosted/HistoricalImagery1976/MapServer/WMTS\n\nClick Get Layers\n> Ok\n\nDouble Click the\nHAPE Layer in the catalogue menu under the WMTS.\n\nDrag the HAPE\nlayer onto the map\n\n \n\nMetadata\n\n\n \n \n Content\n Title\n \n \n \n Historical\n Imagery 1990\n \n \n \n \n \n Content\n Type\n \n \n \n Aerial\n Imagery\n \n \n \n \n \n Description\n \n \n \n Historical\n Aerial Photo Enhancement (HAPE) Ortho Mosaic layer for Aerial imagery\n captured in 1990.\n \n \n \n \n \n Initial\n Publication Date\n \n \n \n 00/00/1990\n \n \n \n \n \n Data\n Currency\n \n \n \n 00/00/1990\n \n \n \n \n \n Data\n Update Frequency\n \n \n \n Other\n \n \n \n \n \n Content Source\n \n \n \n Data provider files\n \n \n \n \n \n File Type\n \n \n \n Imagery\n Layer\n \n \n \n \n \n Attribution\n \n \n \n .\n \n \n \n \n \n Data Theme, Classification or Relationship\n to other Datasets\n \n \n \n NSW Imagery Theme of the Foundation Spatial\n Data Framework (FSDF)\n \n \n \n \n \n Accuracy\n \n \n \n Assessment of positional accuracy for each\n mosaic was undertaken using a 5km x 5km grid. An overall accuracy of +/- 20m\n for 95% of the 100k map sheet was targeted.\n The mosaic was assessed for positional\n accuracy at a scale of 1:10,000 using ADS 50cm imagery.\n \n \n \n \n \n Spatial\n Reference System (dataset)\n \n \n \n GDA94\n \n \n \n \n \n Spatial\n Reference System (web service)\n \n \n \n EPSG:4326\n \n \n \n \n \n WGS84\n Equivalent To\n \n \n \n GDA94\n \n \n \n \n \n Spatial Extent\n \n \n \n \n \n \n \n Content Lineage\n \n \n \n \n \n \n \n Data\n Classification\n \n \n \n Unclassified\n \n \

1990年历史影像

当前与历史影像均为新南威尔士州基础空间数据框架（NSW Foundation Spatial Data Framework）的重要组成部分，是政府及广大社会公众每日广泛使用的宝贵资源。随着该数据库的完整性不断提升，其在各类应用场景中的市场需求也持续增长。

空间服务所涉航空影像最初采用多款相机拍摄，包括Wild RC-5、RC-10及徕卡（Leica）RC-30相机，搭配焦距为88mm、153mm与304mm的多种镜头。该时期的影像以单色或彩色模式拍摄，比例尺覆盖1:5000至1:80000区间。

历史航空影像增强（Historical Air Photo Enhancement, HAPE）项目不仅支持搜索、发现与使用原始影像源数据，还可提供增强型历史校正影像镶嵌图的分发与浏览服务。此项新功能使广大社会公众能够获取并使用空间位置精准的历史影像：
1. 通过历史影像浏览器访问
2. 以Web地图切片服务（Web Map Tile Service, WMTS）的形式直接集成至各类GIS制图应用中，具体操作说明详见下文
3. 直接订购JP2格式镶嵌图并本地使用，可通过客户中心（Customer Hub）联系我方。

在ArcMap或ArcGIS Pro中访问WMTS服务
1. 打开目录窗口
2. 点击「目录 > GIS服务器 > 添加WMTS服务器」
3. 指定以下URL：
https://portal.spatial.nsw.gov.au/tileservices/Hosted/HistoricalImagery1976/MapServer/WMTS
4. 点击「获取图层 > 确定」
5. 在目录菜单的WMTS服务下，双击HAPE图层
6. 将HAPE图层拖拽至地图画布中

元数据
内容标题：1990年历史影像
内容类型：航空影像
描述：本图层为1990年拍摄的航空影像所用的历史航空影像增强（HAPE）正射镶嵌图层
首次发布日期：00/00/1990
数据现势性：00/00/1990
数据更新频率：其他
内容来源：数据提供商文件
文件类型：影像图层
署名：无
数据主题、分类及与其他数据集的关联关系：基础空间数据框架（Foundation Spatial Data Framework, FSDF）新南威尔士州影像主题
精度评估：本次评估采用5km×5km网格对每张镶嵌图的位置精度进行核验，目标为10万比例尺地图图幅内95%区域的位置精度达到±20m。该镶嵌图的位置精度以1:10000比例尺为基准，通过ADS 50cm影像完成评估。
空间参考系统（数据集）：GDA94
空间参考系统（Web服务）：EPSG:4326
WGS84等效性：与GDA94等效
空间范围：未标注
内容溯源：未标注
数据分类：未分类
