黑河流域地表过程综合观测网（大沙龙站涡动相关仪-2024）

该数据集包含了2024年1月1日至2024年12月31日的黑河流域地表过程综合观测网上游大沙龙站涡动相关仪观测数据。站点位于青海省祁连县，下垫面是沼泽化高寒草甸。观测点的经纬度是98.9406E，38.8399N，海拔3739 m。涡动相关仪的架高4.5m，采样频率是10Hz，超声朝向是正北向，超声风速温度仪（CSAT3）与CO2/H2O分析仪（Li7500RS）之间的距离是15cm。
涡动相关仪的原始观测数据为10Hz，发布的数据是采用Eddypro软件处理的30分钟数据，其处理的主要步骤包括：野点值剔除，延迟时间校正，坐标旋转（二次坐标旋转），频率响应修正，超声虚温修正和密度（WPL）修正等。同时对各通量值进行质量评价，主要是大气平稳性（Δst）和湍流相似性特征（ITC）的检验。对Eddypro软件输出的30min通量值也进行了筛选：（1）剔除仪器出错时的数据；（2）剔除降水前后1h的数据；（3）剔除10Hz原始数据中每30min内缺失率大于10%的数据。观测数据的平均周期为30分钟，一天48个数据，缺失数据标记为-9999。冬季由于H2O测量值出现负值，出现一些数据缺失。
发布的观测数据包括：日期/时间Date/Time，风向Wdir（°），水平风速Wnd（m/s），侧向风速标准差Std_Uy（m/s），超声虚温Tv（℃），水汽密度H2O（g/m3），二氧化碳浓度CO2（mg/m3），摩擦速度Ustar（m/s），奥布霍夫长度L（m），感热通量Hs（W/m2），潜热通量LE（W/m2），二氧化碳通量Fc（mg/（m2s）），感热通量的质量标识QA_Hs，潜热通量的质量标识QA_LE，二氧化碳通量的质量标识QA_Fc。感热、潜热、二氧化碳通量的质量标识分为九级（质量标识1-3数据质量好，4-6数据质量较好，7-8数据质量较差（较插补数据好）；9数据质量差））。数据时间的含义，如0:30代表0:00-0:30的平均；数据以*.xls格式存储。
黑河流域地表过程综合观测网或站点信息请参考Liu et al. (2018)和Che et al. (2019)。

This dataset contains eddy covariance system observations collected at the Dalongshao Station (upper reaches of the Heihe River Basin Terrestrial Surface Process Comprehensive Observation Network) from January 1, 2024 to December 31, 2024. The station is located in Qilian County, Qinghai Province, with the underlying surface being swampy alpine meadow. The observation site has coordinates of 98.9406°E, 38.8399°N, and an elevation of 3739 m. The eddy covariance system has an installation height of 4.5 m, a sampling frequency of 10 Hz, and the ultrasonic anemometer faces true north. The distance between the ultrasonic anemometer-thermometer (CSAT3) and the CO2/H2O analyzer (Li7500RS) is 15 cm.

The raw observational data from the eddy covariance system is at 10 Hz. The released data are 30-minute averaged data processed using the EddyPro software. The main processing steps include: outlier removal, time lag correction, coordinate rotation (double coordinate rotation), frequency response correction, ultrasonic virtual temperature correction, and density correction (WPL), among others. Quality assessment was conducted for each flux value, primarily via tests of atmospheric stationarity (Δst) and turbulence similarity characteristics (ITC). The 30-minute flux outputs from EddyPro were further screened based on the following criteria: (1) removing data collected during instrument malfunctions; (2) removing data within 1 hour before and after precipitation events; (3) removing data with a missing rate greater than 10% per 30-minute window from the 10 Hz raw data. The average period of the observational data is 30 minutes, resulting in 48 data records per day, with missing values marked as -9999. Some data gaps occurred in winter due to negative H2O measurement values.

The released observational data include: Date/Time, wind direction (Wdir, °), horizontal wind speed (Wnd, m/s), lateral wind speed standard deviation (Std_Uy, m/s), ultrasonic virtual temperature (Tv, ℃), water vapor density (H2O, g/m³), carbon dioxide concentration (CO2, mg/m³), friction velocity (Ustar, m/s), Obukhov length (L, m), sensible heat flux (Hs, W/m²), latent heat flux (LE, W/m²), carbon dioxide flux (Fc, mg/(m²s)), quality flag for sensible heat flux (QA_Hs), quality flag for latent heat flux (QA_LE), and quality flag for carbon dioxide flux (QA_Fc). The quality flags for sensible heat, latent heat, and carbon dioxide fluxes are divided into nine levels: flags 1–3 indicate good data quality, 4–6 indicate fair data quality, 7–8 indicate poor data quality (better than interpolated data), and 9 indicates poor data quality. The meaning of the data timestamp is exemplified as follows: 0:30 represents the average over the period 0:00–0:30. All data are stored in *.xls format.

For information about the Heihe River Basin Terrestrial Surface Process Comprehensive Observation Network or the station, please refer to Liu et al. (2018) and Che et al. (2019).

搜集汇总

背景与挑战

背景概述

该数据集为2024年黑河流域上游大沙龙站的涡动相关仪观测数据，包含多种气象和通量参数，经过严格的质量控制和处理，适用于高寒草甸地表过程研究。
