超长循环人造石墨负极材料GLD-2产品型号技术标准数据

基于多种检测设备的检测数据，根据技术指标分析而成。如，按照粒度（单位：μm ）划分为Dv10≥3.5、Dv50（11.0±2.0）、Dv90≤35.0、Dv99 ≤55.0四个粒度范围，通过马尔文激光粒度仪检测确定粒度分布；通过百特振实密度仪检测振实密度是否符合≥1.05g/cm³要求 ；通过比表面测试仪测出比表面积是否为（1.6±0.5）m2/g ；通过马弗炉检测出灰分是否≤0.1%；通过水分测定仪检测出水分是否≤0.1%；通过ICP-OES 电感耦合等离子体发射光谱仪检测磁性物质是否≤3.0ppm 和确认杂质元素含量在以下元素含量划分“Fe≤50ppm ”“Cu≤10ppm” 的范围。通过半电池/PVDF Half cell test/PVDF检测比容量是否符合≥340.0mAh/g、首次效率是否满足≥91.0%标准数据。

This dataset is compiled based on detection data from multiple testing devices, with analysis conducted per technical specifications. For example, the particle size distribution is divided into four ranges based on particle size (unit: μm): Dv10≥3.5, Dv50 (11.0±2.0), Dv90≤35.0, and Dv99 ≤55.0, which is determined using a Malvern laser particle size analyzer. The tap density is tested via a Bettersize tap density tester to verify whether it meets the requirement of ≥1.05 g/cm³. The specific surface area is measured by a specific surface area analyzer to confirm that it is (1.6±0.5) m²/g. The ash content is detected using a muffle furnace to check if it is ≤0.1%. The moisture content is measured by a moisture analyzer to ensure it is ≤0.1%. Inductively Coupled Plasma Optical Emission Spectrometer (ICP-OES) is employed to detect whether the magnetic substance content is ≤3.0 ppm, and to confirm that the contents of impurity elements fall within the ranges of "Fe≤50 ppm" and "Cu≤10 ppm". Additionally, the specific capacity and first-cycle efficiency are tested via the half-cell/PVDF Half cell test/PVDF assay, to verify whether the specific capacity meets the standard of ≥340.0 mAh/g and the first-cycle efficiency satisfies the standard of ≥91.0%.

搜集汇总

背景与挑战

背景概述

该数据集是晖阳（贵州）新能源材料有限公司申请的超长循环人造石墨负极材料GLD-2产品的技术标准数据，用于质量控制。数据集包含通过马弗炉、激光粒度仪等设备检测的粒度分布、振实密度、比表面积、灰分、水分、磁性物质、杂质元素含量、比容量和首次效率等指标，并规定了各项指标的具体合格标准，如粒度Dv50为（11.0±2.0）μm、振实密度≥1.05g/cm³、比容量≥340.0mAh/g等。数据规模为18KB，更新周期为年，主要应用于储能领域的人造石墨负极材料产品检测。
