Vibration, Acoustic, Temperature, and Motor Current Dataset of Rotating Machine Under Varying Load Conditions for Fault Diagnosis

This dataset presents time-series dataset including vibration, acoustic, temperature, and motor current data for rotating machines under varying load conditions. The conditions of the rotating machine include normal, bearing inner race faults, bearing outer race faults, shaft misalignment, and rotor unbalance with three different load conditions. ---- Description of vibration file format ---- Vibration data file contains five columns namely ‘Time Stamp’, ‘x_direction_housing_A’, ‘y_direction_housing_A’, ‘x_direction_housing_B’, and ‘y_direction_housing_B’. The unit of the vibration is ‘gravitational constant (g)’. aaaaNm_bbbb_cccc.mat : This file includes vibration data of the condition of "bbbb" with "cccc" of severity and "aaaa" load condition. ---- Description of acoustic file format ---- Acoustic data file contains two columns namely ‘Time Stamp’, and ‘values’. The unit of the acoustic is ‘Pascal (Pa)’. aaaaNm_bbbb_cccc.mat : This file includes acoustic data of the condition of "bbbb" with "cccc" of severity and "aaaa" load condition. ---- Description of temperature, and motor current file format ---- Temperature and motor current data file contain six columns namely ‘Time Stamp’, ‘Temperature_housing_A’, ‘Temperature_housing_B’, ‘U-phase’, ‘V-phase’, and ‘W-phase’. The unit of the temperature and motor current are ‘Celsius (℃), and ‘ampere (A)’, respectively. aaaaNm_bbbb_cccc.tdms : This file includes temperature and motor current data of the condition of "bbbb" with "cccc" of severity and "aaaa" load condition. For more detailed information about this dataset, please check our article published in "Data in Brief". Title: Vibration, Acoustic, Temperature, and Motor Current Dataset of Rotating Machine Under Varying Operating Conditions for Fault Diagnosis Link: https://www.sciencedirect.com/journal/data-in-brief

本数据集为变负载工况下旋转机械的时序数据集，涵盖振动、声学、温度及电机电流四类数据。旋转机械的工况包含正常状态、轴承内圈故障、轴承外圈故障、轴不对中以及转子不平衡五类，且涵盖三种不同负载工况。

---- 振动数据文件格式说明 ----
振动数据文件共包含五列，依次为「时间戳」、「壳体A X方向分量」、「壳体A Y方向分量」、「壳体B X方向分量」、「壳体B Y方向分量」。振动数据的单位为「重力加速度(g)」。
文件名格式为`aaaaNm_bbbb_cccc.mat`：该文件包含工况为「bbbb」、严重程度为「cccc」、负载为「aaaa」的振动数据。

---- 声学数据文件格式说明 ----
声学数据文件共包含两列，依次为「时间戳」与「声压值」。声学数据的单位为「帕斯卡(Pa)」。
文件名格式为`aaaaNm_bbbb_cccc.mat`：该文件包含工况为「bbbb」、严重程度为「cccc」、负载为「aaaa」的声学数据。

---- 温度与电机电流数据文件格式说明 ----
温度与电机电流数据文件共包含六列，依次为「时间戳」、「壳体A温度」、「壳体B温度」、「U相电流」、「V相电流」、「W相电流」。温度数据的单位为「摄氏度(℃)」，电机电流的单位为「安培(A)」。
文件名格式为`aaaaNm_bbbb_cccc.tdms`：该文件包含工况为「bbbb」、严重程度为「cccc」、负载为「aaaa」的温度与电机电流数据。

如需获取本数据集的更多详细信息，请查阅发表于《Data in Brief》的相关论文，论文标题为《面向故障诊断的变工况旋转机械振动、声学、温度及电机电流数据集》，链接：https://www.sciencedirect.com/journal/data-in-brief

搜集汇总

背景与挑战

背景概述

该数据集是一个用于旋转机械故障诊断的多模态时间序列数据集，包含振动、声学、温度和电机电流数据，覆盖正常状态及多种故障条件（如轴承内圈/外圈故障、轴不对中、转子不平衡），并在三种变负载条件下采集。数据以标准格式组织，总大小约3.96 GB，适用于机器学习或信号处理研究，旨在支持工业设备的健康监测和故障预测。
