# Zero-to-CAD 1M

**One million executable, interpretable CAD construction sequences synthesized entirely without real-world data.**

<p align="center">
<img src="assets/agentic.png" alt="Zero-to-CAD agentic synthesis pipeline" width="800"/>
</p>

> **Zero-to-CAD: Agentic Synthesis of Interpretable CAD Programs at Million-Scale Without Real Data**
>
> [Mohammadmehdi Ataei](https://orcid.org/0000-0002-3399-9696), [Farzaneh Askari](https://orcid.org/0000-0003-0684-1102), [Kamal Rahimi Malekshan](https://orcid.org/0009-0004-1192-4724), [Pradeep Kumar Jayaraman](https://orcid.org/0000-0001-6314-6136)
>
> Autodesk Research

## Related Resources

| Resource | Link |
|----------|------|
| 📄 **Paper** | [Zero-to-CAD: Agentic Synthesis of Interpretable CAD Programs at Million-Scale Without Real Data](https://arxiv.org/abs/2604.24479) |
| 📦 **Zero-to-CAD 1M** (this dataset) | You are here |
| 📦 **Zero-to-CAD 100K** (curated subset) | [ADSKAILab/Zero-To-CAD-100k](https://huggingface.co/datasets/ADSKAILab/Zero-To-CAD-100k) |
| 🤖 **Fine-tuned Model** (Qwen3-VL-2B) | [ADSKAILab/Zero-To-CAD-Qwen3-VL-2B](https://huggingface.co/ADSKAILab/Zero-To-CAD-Qwen3-VL-2B) |
| 🗂️ **Collection** | [ADSKAILab/Zero-To-CAD](https://huggingface.co/collections/ADSKAILab/zero-to-cad) |

## Overview

Zero-to-CAD is a large-scale dataset of **1,000,000 executable CAD construction sequences** generated by an LLM operating inside a feedback-driven CAD environment. Unlike prior datasets limited to sketch-and-extrude workflows, Zero-to-CAD covers a **broad vocabulary of CAD operations** including booleans, fillets, chamfers, shells, lofts, sweeps, and patterns.

Each sample is:
- ✅ **Executable** — valid CadQuery Python code that runs and produces geometry
- ✅ **Interpretable** — named parameters, logical construction order, human-readable code
- ✅ **Geometrically validated** — multi-stage validation (topology, contiguity, complexity, export)

### How It Was Made

We frame CAD synthesis as an **agentic search problem**: an LLM is placed in a loop with a CadQuery execution environment and equipped with three tools:

1. **`execute_and_validate`** — runs code, checks geometric validity, returns structured feedback
2. **`lookup_documentation`** — TF-IDF retrieval over CadQuery API docs
3. **`grep_documentation`** — regex-based precise syntax lookup

The agent iteratively generates, executes, and repairs code across multiple turns until validation succeeds. A two-stage protocol first generates diverse part descriptions (65 categories), then synthesizes executable code for each.

<p align="center">
<img src="assets/samples.png" alt="Sample CAD models from Zero-to-CAD" width="100%"/>
</p>

## Dataset Details

### Generation Statistics

| Metric | Value |
|--------|-------|
| Total sequences | 999,633 |
| Total tokens processed | 60.2B |
| Generated tokens per design (mean / median) | 5,638 / 5,089 |
| Function calls per conversation (mean) | 4.34 |
| Zero-shot success rate | 22.3% |
| Attempts before success (mean / median) | 3.30 / 3 |
| Minimum B-Rep face count | 7 |

### Splits

| Split | Samples |
|-------|---------|
| Train | 979,633 |
| Validation | 10,000 |
| Test | 10,000 |

### Data Fields

Each sample contains:

| Field | Type | Description |
|-------|------|-------------|
| `uuid` | `string` | Unique identifier (deterministic, derived from content hash) |
| `cadquery_file` | `string` | Executable CadQuery Python source code |
| `num_faces` | `int` | Number of B-Rep faces in the final solid |
| `face_latency_ms` | `float` | Time to compute face count (ms) |
| `cadquery_ops_json` | `string` | JSON list of CAD operations used (e.g., extrude, fillet, chamfer) |
| `cadquery_ops_count` | `int` | Number of CAD operations in the construction sequence |
| `ops_latency_ms` | `float` | Time to extract operations (ms) |
| `num_renders` | `int` | Number of rendered views |
| `image_0` – `image_7` | `image` | 8 rendered views (256×256, 4 front + 4 rear) |
| `stl_file` | `bytes` | Exported STL mesh |
| `step_file` | `bytes` | Exported STEP file |

### CAD Operations Coverage

The dataset covers a broad set of operations far beyond sketch-and-extrude:

- **Sketch primitives**: rect, circle, polygon, arc, spline, slot
- **3D operations**: extrude, cut, revolve, loft, sweep
- **Modifications**: fillet, chamfer, shell, offset
- **Booleans**: union, cut, intersect
- **Patterns**: linear patterns, polar patterns, mirror
- **Features**: holes (through, blind, countersink), threads, ribs

### Part Categories

65 categories spanning structural components (brackets, gusset plates), rotational elements (pulleys, flywheels), enclosures (housings, covers), fastening hardware (clamps, spacers), and more.

## Comparison with Existing Datasets

| Dataset | Year | Size | Replayable | Readable | Operations |
|---------|------|------|------------|----------|------------|
| DeepCAD | 2021 | 178K | ✅ | ✅ | Sketch, Extrude |
| Fusion 360 Gallery | 2021 | 8.6K | ✅ | ✅ | Sketch, Extrude |
| CC3D-Ops | 2022 | 37K+ | ❌ | ❌ | Extrude/Cut, Revolve, Fillet, Chamfer (labels only) |
| CAD-Recode | 2025 | 1M | ✅ | ❌ | Sketch, Extrude |
| **Zero-to-CAD (ours)** | **2026** | **1M** | **✅** | **✅** | **Broad** (booleans, fillets, chamfers, lofts, sweeps, shells, etc.) |

## Quick Start

### Load the dataset

The train split contains ~1M rows, so use streaming to avoid downloading the entire dataset at once:

```python
from datasets import load_dataset

# Streaming mode — rows are fetched on demand
ds = load_dataset("ADSKAILab/Zero-To-CAD-1m", split="train", streaming=True)
sample = next(iter(ds))

# Get a single sample
sample = next(iter(ds))

# Display the reconstructed script
cad_code = bytes(sample["cadquery_file"]).decode("utf-8")
print(cad_code)
```

To load a smaller split entirely into memory:

```python
ds = load_dataset("ADSKAILab/Zero-To-CAD-1m", split="test")
sample = ds[0]
```

### Execute a sample

```python
import cadquery as cq

# Streaming mode — rows are fetched on demand
ds = load_dataset("ADSKAILab/Zero-To-CAD-1m", split="train", streaming=True)
sample = next(iter(ds))

# Execute the code from a sample
code = bytes(sample["cadquery_file"]).decode("utf-8")
exec(code)

# Display generated CadQuery solid
from IPython.display import display
display(result)
```

### Visualize renders

```python
for i in range(8):
img = sample[f"image_{i}"]
img.save(f"view_{i}.png")
```

## Embeddings & FAISS Index

Precomputed DINOv3 visual embeddings and a FAISS IVF-PQ index are provided for nearest-neighbor search over the full dataset. Each embedding is the mean-pooled DINOv3 feature across 8 rendered views of a CAD model.

| File | Size | Description |
|------|------|-------------|
| `embeddings/cad_gen_embeddings.npy` | 1.54 GB | DINOv3 embeddings (999,633 × 384, float32) |
| `embeddings/cad_gen_ivfpq.index` | 97.7 MB | FAISS IVF-PQ index for approximate nearest-neighbor search |
| `cad_gen_uuids.txt` | 37 MB | Row-index → item ID mapping (999,632 IDs) |
| `embeddings/cad_gen_neighbors_ivfpq.csv` | 1.73 GB | Precomputed 20 nearest neighbors for every sample |
| `embeddings/cad_gen_diverse_samples.csv` | 7.74 MB | 100K diverse subset selection metadata (cluster assignments) |

### Search for similar models

```python
import faiss
import numpy as np
from huggingface_hub import hf_hub_download

# Download index and ID mapping
index_path = hf_hub_download("ADSKAILab/Zero-To-CAD-1m", "embeddings/cad_gen_ivfpq.index", repo_type="dataset")
ids_path = hf_hub_download("ADSKAILab/Zero-To-CAD-1m", "embeddings/cad_gen_uuids.txt", repo_type="dataset")

index = faiss.read_index(index_path)
item_ids = open(ids_path).read().splitlines()

# Query with your own embedding (384-d float32)
query = np.random.rand(1, 384).astype("float32") # replace with your embedding
distances, indices = index.search(query, k=10)

for rank, (dist, idx) in enumerate(zip(distances[0], indices[0]), 1):
print(f"{rank}. {item_ids[idx]} (distance: {dist:.4f})")
```

### Load precomputed neighbors

```python
import pandas as pd
from huggingface_hub import hf_hub_download

path = hf_hub_download("ADSKAILab/Zero-To-CAD-1m", "embeddings/cad_gen_neighbors_ivfpq.csv", repo_type="dataset")
neighbors = pd.read_csv(path)
# Columns: item_id, neighbor_id, score, rank
```

## Example

```python
import cadquery as cq

plate_length = 60.0
plate_width = 40.0
plate_thickness = 8.0
rib_length = 20.0
rib_width = 6.0
hole_diameter = 8.0
mount_hole_dia = 3.0
fillet_radius = 2.0
chamfer_distance = 1.0
slot_width = 4.0
slot_length = 30.0

base = (
cq.Workplane('XY')
.rect(plate_length, plate_width, centered=True)
.extrude(plate_thickness)
)
base = base.edges("|Z").fillet(fillet_radius)

rib = (
cq.Workplane('XY')
.center(-plate_length/2 + rib_length/2, 0)
.rect(rib_length, rib_width, centered=True)
.extrude(plate_thickness)
)
bracket = base.union(rib)

bracket = bracket.cut(
cq.Workplane('XY').center(0, 0)
.circle(hole_diameter/2).extrude(plate_thickness + 2)
)

bracket = bracket.edges("|Z").chamfer(chamfer_distance)
result = bracket
```

## Intended Uses

- **Training CAD sequence models** — learn to generate parametric construction histories
- **Image-to-CAD reconstruction** — reconstruct editable CAD from multi-view images
- **CAD program understanding** — study the structure and semantics of construction sequences
- **Benchmarking** — evaluate generative CAD models on diverse, validated geometry

## Limitations

- All data is synthetically generated; no real-world CAD files were used
- The LLM may produce locally plausible but globally incoherent designs in some cases
- Scale conventions (max 100 units) may not match specific engineering standards
- Operation distribution reflects LLM priors, not real-world manufacturing frequency

## Citation

If you use this dataset, please cite:

```bibtex
@misc{ataei2026zerotocadagenticsynthesisinterpretable,
title={Zero-to-CAD: Agentic Synthesis of Interpretable CAD Programs at Million-Scale Without Real Data},
author={Mohammadmehdi Ataei and Farzaneh Askari and Kamal Rahimi Malekshan and Pradeep Kumar Jayaraman},
year={2026},
eprint={2604.24479},
archivePrefix={arXiv},
primaryClass={cs.CV},
url={https://arxiv.org/abs/2604.24479}
}
```

## License

This dataset is released under the [Apache License 2.0](https://www.apache.org/licenses/LICENSE-2.0).
