微小型连接器缺陷图像集

1、数据采集：通过高倍镜获得零件的图像，与标准零件图像进行对比，获取连接器缺陷图像；
2、数据处理：连接器缺陷包括引脚器变形、缺针、镀层损伤等；对图像和缺陷进行归类保存；判断各缺陷的位置、类型和程度，在图像上标识缺陷细节。
3、数据应用：可用于微小型连接器缺陷机器学习，实现对引脚变形、缺针、镀层损伤等缺陷的自动识别与分级，满足高精度、高速度的质量筛查需求。

1. Data Collection: Capture images of components via a high-magnification microscope, and compare them with standard component images to obtain connector defect images.
2. Data Processing: Connector defects include pin deformation, missing pins, plating damage, etc. Classify and store the images and corresponding defects, determine the location, type and severity of each defect, and mark the specific defect details on the images.
3. Data Application: This dataset can be applied to machine learning for micro-miniature connector defects, enabling automatic recognition and grading of defects such as pin deformation, missing pins and plating damage, thus meeting the demands of high-precision and high-speed quality screening.

搜集汇总

背景与挑战

背景概述

该数据集是一个5.64MB的微小型连接器缺陷图像集，用于训练缺陷识别算法，支持高精度连接器生产检测，涵盖引脚变形、缺针等多种缺陷类型。
