Digital Terrain Model (Standard ICAO)

In the scope of the International Civil Aviation Organization ([ICAO](https://www.icao.int)) requiring countries and airports to provide electronic Terrain and Obstacle Data ([eTOD](https://skybrary.aero/articles/electronic-terrain-and-obstacle-data-etod)), the Administration de la navigation aérienne has been tasked by the Government to take the steps necessary to comply with this requirement. This Digital Terrain Model (DTM) is the result of a first LIDAR survey flight that has been done in October 2017 and corresponds to the standards required by ICAO. For this reason this DTM also uses the international reference systems WGS84 and EGM2008. The data itself is split up in 4 different areas, which are specified as follows: - Area 1: The entire territory of Luxembourg; - Area 2: Terminal Control Area (this area is larger than the territory of Luxembourg); - Area 3: Aerodrome movement area; - Area 4: Category II or III operations (Runway 24). The different areas come with different numerical requirements, such as data accuracy and resolution. Follow the links in the description or consult metadata for further Information.在国际民用航空组织（International Civil Aviation Organization，ICAO）要求各国及机场提供电子地形与障碍物数据（electronic Terrain and Obstacle Data，eTOD）的合规框架下，卢森堡政府已委托航空导航管理局采取必要措施以满足该项合规要求。 本数字地形模型（Digital Terrain Model，DTM）源自2017年10月完成的首次激光雷达（LIDAR）航测飞行任务，完全符合ICAO规定的相关标准。因此，该DTM采用了国际参考坐标系WGS84与EGM2008。 本次数据集共划分为4个不同区域，具体说明如下： - 区域1：卢森堡全境 - 区域2：终端管制区（该区域范围大于卢森堡国土面积） - 区域3：机场活动区 - 区域4：二类/三类运行区域（24号跑道） 各区域设有差异化的数值指标要求，涵盖数据精度与分辨率等维度。如需获取更多详细信息，请参阅描述中附带的链接或查阅元数据。

搜集汇总

背景与挑战

背景概述

该数据集是卢森堡航空管理局为满足国际民用航空组织电子地形数据要求而创建的标准化数字地形模型，基于2017年10月的LIDAR测量，并采用WGS84和EGM2008国际参考系统。数据集覆盖卢森堡全境及周边航空管制区域，分为四个具有不同精度要求的区域，主要用于航空安全和导航目的。
