25G OLT和ONU光模块PCB版图

25G OLT和ONU光模块PCB版图主要面向单通道25Gb/s的PON OLT和ONU光模块的设计开发与制备技术研究。基于光模块原理图以及结构尺寸要求，通过EDA软件进行PCB设计。PCB版图主要反映了实际元件摆放和连线信息。主要包含了焊盘、过孔、走线、敷铜、阻焊等图层及钻孔设计信息，数据量804KB。

This dataset contains PCB layouts for 25G OLT and ONU optical modules, which are mainly targeted at the research on design, development and manufacturing technologies of single-channel 25Gb/s PON OLT and ONU optical modules. The PCB designs were completed via EDA software based on the schematic diagrams of the optical modules and structural dimension requirements. The PCB layouts primarily reflect actual component placement and routing information, including layer design details such as pads, vias, traces, copper pours, solder masks, as well as drilling design data. The total data volume of the dataset is 804 KB.

搜集汇总

背景与挑战

背景概述

该数据集包含25G OLT和ONU光模块的PCB版图设计文件，用于支持单通道25Gb/s无源光网络（PON）光模块的研发与制备。它基于EDA软件设计，提供了焊盘、过孔、走线等关键图层信息，数据量约825KB，共42个文件，源自国家重点研发计划项目，专注于高速光通信模块的技术研究。
