NSW Survey Mark

NSW Survey MarkPlease NoteWGS 84 = GDA94 serviceThis dataset has a spatial reference of [WGS 84 = GDA94] and can NOT be easily consumed into GDA2020 environments. A similar service with a ‘multiCRS’ suffix is available which can support GDA2020, GDA94 and WGS84 = GDA2020 environments. In due course, and allowing time for user feedback and testing, it is intended that these original services will adopt the new multiCRS functionality.Please note that SCIMS Online is the official option for obtaining state control survey data for cadastral surveys as it offers legal traceability. SCIMS online is accessible via the Spatial portal.Metadata Portal Metadata InformationContent TitleNSW Water Theme multiCRSContent TypeHosted Feature LayerDescriptionThe NSW Survey Marks web service is a dynamic map of permanent survey marks that constitute the state control survey. The positioning data under the NSW Foundation Spatial Data Framework (FSDF) is fed to the web service by the Survey Control Information Management System (SCIMS), the database that contains the single source of truth for all marks within the state control survey network.The web service provides a wealth of data on each mark, including:Mark type (Permanent Mark, State Survey Mark, etc.)Mark numberHorizontal coordinates and their accuracy (class and order)Heights and their accuracy (class and order)Status of the mark (destroyed, restricted access, etc.) The mark type is represented using various shapes and the accuracy of the mark (both vertical and horizontal) is communicated by the colour.This web service allows users to easily integrate survey control mark data from SCIMS into Open Geospatial Consortium (OGC) compliant spatial platforms and applications.Data provided by the NSW Survey Mark web service can be used in a variety of engineering and surveying applications, including but not limited to:Cadastral survey planningFlood studies and hydrographic modellingInfrastructure developmentSite calibration at construction sitesElevation modellingPreservation of survey infrastructureThe NSW Survey Mark web service gives users an alternative method to access state control survey data that can be incorporated into their GIS package without needing to log into SCIMS Online.Please note that SCIMS Online is the official option for obtaining state control survey data for cadastral surveys as it offers legal traceability. SCIMS online is accessible via the Spatial Collaboration Portal.Please note that SCIMS Online is the official option for obtaining state control survey data for cadastral surveys as it offers legal traceability. SCIMS online is accessible via the Spatial portal.Initial Publication Date01/08/2019Data Currency01/01/3000Data Update FrequencyOtherContent SourceData provider filesFile TypeESRI File Geodatabase (*.gdb)Attribution© State of New South Wales (Spatial Services, a business unit of the Department of Customer Service NSW). For current information go to spatial.nsw.gov.auData Theme, Classification or Relationship to other DatasetsNSW Positioning Theme of the Foundation Spatial Data Framework (FSDF)AccuracyThis dataset was captured by utilising the best available source at a variety of scales and accuracies, ranging from 1:500 to 1:250 000 according to the National Mapping Council of Australia, Standards of Map Accuracy (1975). Therefore, the position of the feature instance will be within 0.5mm at map scale for 90% of the well-defined points. That is, 1:500 = 0.25m, 1:2000 = 1m, 1:4000 = 2m, 1:25000 = 12.5m, 1:50000 = 25m and 1:100000 = 50m. A program to upgrade the spatial location and accuracy of data is ongoing.Spatial Reference System (dataset)GDA94Spatial Reference System (web service)EPSG:3857WGS84 Equivalent ToGDA94Spatial ExtentFull StateContent LineageFor additional information, please contact us via the Spatial Services Customer HubData ClassificationUnclassifiedData Access PolicyOpenData QualityFor additional information, please contact us via the Spatial Services Customer HubTerms and ConditionsCreative CommonsStandard and SpecificationOpen Geospatial Consortium (OGC) implemented and compatible for consumption by common GIS platforms. Available as either cache or non-cache, depending on client use or requirement. Data CustodianDCS Spatial Services346 Panorama Ave Bathurst NSW 2795Point of ContactPlease contact us via the Spatial Services Customer HubData AggregatorDCS Spatial Services346 Panorama AveBathurst NSW 2795Data DistributorDCS Spatial Services346 Panorama AveBathurst NSW 2795Additional Supporting InformationData DictionariesTRIM NumberNSW 测量标志（NSW Survey Mark）服务说明 请注意：世界大地测量系统1984 = 澳大利亚大地测量基准1994（WGS 84 = GDA94）服务 本数据集的空间参考为[WGS 84 = GDA94]，无法直接适配GDA2020（澳大利亚大地测量基准2020）环境。另有带“multiCRS（多坐标参考系统）”后缀的同类服务，可支持GDA2020、GDA94及WGS84 = GDA2020环境。待收集用户反馈并完成测试后，本原始服务将逐步升级以支持新的多坐标参考系统功能。 请注意，SCIMS Online（测量控制信息管理系统在线平台）是获取地籍测量所需州级控制测量数据的官方渠道，因其具备法律可追溯性。用户可通过空间门户（Spatial portal）访问SCIMS Online。 ## 元数据 门户元数据信息 ### 内容标题 NSW 水主题多坐标参考系统（NSW Water Theme multiCRS） ### 内容类型 托管要素图层（Hosted Feature Layer） ### 描述 NSW 测量标志（NSW Survey Mark）网络服务是一幅展示构成州级控制测量网络的永久测量标志的动态地图。新南威尔士州基础空间数据框架（Foundation Spatial Data Framework, FSDF）下的定位数据由测量控制信息管理系统（Survey Control Information Management System, SCIMS）推送至该网络服务，该数据库存储了州级控制测量网络内所有测量标志的权威单一数据源。 该网络服务提供各测量标志的丰富数据，包括： - 标志类型（永久标志、州级测量标志等） - 标志编号 - 水平坐标及其精度（等级与阶数） - 高程及其精度（等级与阶数） - 标志状态（已损毁、限制通行等） 标志类型通过不同形状表示，标志的垂直与水平精度则通过颜色区分。 本网络服务可帮助用户轻松将SCIMS中的测量控制标志数据集成至符合开放地理空间联盟（Open Geospatial Consortium, OGC）标准的空间平台与应用中。 NSW 测量标志网络服务提供的数据可应用于多种工程与测量场景，包括但不限于： - 地籍测量规划 - 洪水研究与水文地形建模 - 基础设施开发 - 施工现场点位校准 - 高程建模 - 测量基础设施保护 本网络服务为用户提供了一种无需登录SCIMS Online即可获取州级控制测量数据的替代方案，可直接集成至用户的GIS软件中。 请注意，SCIMS Online是获取地籍测量所需州级控制测量数据的官方渠道，因其具备法律可追溯性。用户可通过空间协作门户（Spatial Collaboration Portal）访问SCIMS Online。 请注意，SCIMS Online是获取地籍测量所需州级控制测量数据的官方渠道，因其具备法律可追溯性。用户可通过空间门户（Spatial portal）访问SCIMS Online。 首次发布日期：2019年8月1日 数据时效性：3000年1月1日 数据更新频率：其他 数据来源：数据提供方文件 文件类型：ESRI 文件地理数据库（*.gdb） 归属权声明：© 新南威尔士州政府（空间服务部，新南威尔士州客户服务厅下属业务单元）。最新信息请访问 spatial.nsw.gov.au 数据主题、分类或与其他数据集的关联关系： 属于新南威尔士州基础空间数据框架（FSDF）的定位主题。 ### 精度说明 本数据集依据澳大利亚国家测绘委员会1975年《地图精度标准》，采用各比例尺与精度下的最优数据源进行采集，比例尺范围涵盖1:500至1:250 000。因此，90%的明确点位在对应地图比例尺下的位置误差不超过0.5毫米，即： - 1:500比例尺对应误差0.25米 - 1:2000比例尺对应误差1米 - 1:4000比例尺对应误差2米 - 1:25000比例尺对应误差12.5米 - 1:50000比例尺对应误差25米 - 1:100000比例尺对应误差50米 当前正在实施一项程序，以升级本数据集的空间位置与精度。 ### 空间参考系统（数据集） GDA94（澳大利亚大地测量基准1994） ### 空间参考系统（网络服务） EPSG:3857 ### WGS84 等效基准 GDA94（澳大利亚大地测量基准1994） ### 空间覆盖范围 全州范围 ### 数据谱系 如需更多信息，请通过空间服务客户中心（Spatial Services Customer Hub）联系我们。 ### 数据分类 非保密 ### 数据访问政策 开放访问 ### 数据质量 如需更多信息，请通过空间服务客户中心联系我们。 ### 条款与条件 知识共享（Creative Commons）标准协议 ### 标准与规范 符合开放地理空间联盟（OGC）标准，可兼容主流GIS平台使用。可根据客户端需求选择缓存或非缓存服务。 ### 数据保管方 新南威尔士州客户服务厅空间服务部 地址：346 Panorama Avenue, Bathurst NSW 2795 ### 联系人 如需联系，请通过空间服务客户中心办理。 ### 数据聚合方 新南威尔士州客户服务厅空间服务部 地址：346 Panorama Avenue, Bathurst NSW 2795 ### 数据分发方 新南威尔士州客户服务厅空间服务部 地址：346 Panorama Avenue, Bathurst NSW 2795 ### 附加支持信息 数据字典：TRIM编号
