紧固件数字库-GB5784六角螺栓编码管理数据

本数据有助于紧固件GB5784六角螺栓产品属性管理及产品唯一简化编码生成和管理，实现产品的唯一性匹配。十二角螺钉产品属性繁多有如：产品类目、产品标准名称、产品标准代号、产品规格（由直径、长度、牙距、牙型组成）、材质、强度、材料、表面处理等12个属性构成，本数据通过将产品12个属性名称和属性值进行统一规范的管理，产品描述的所有属性值多的长达50个文字以上，很难在后续的ERP、WMS、MES等系统中调用和描述，并且无法进行产品唯一性的匹配和管理，为此将产品的12个属性值通过类似于Base64 的自定义编码（仅包含字母和数字一共33个）的方式转换成12~19位长的产品唯一编码实现产品的唯一性匹配和检索，并且通过产品的唯一性编码生成一个对于的产品二维码，快速的进行扫码识别进行后续系统平台的调用。
1、数据采集： 通过发行的紧固件标准手册、螺纹公差、机械性能、材质手册等，获得紧固件GB5784六角螺栓产品的属性数据和参数，从本单位开发运营的“工业零部件数字库-【紧固件】标准底层系统”上采集紧固件产品的属性数据，包括：标准名称、标准代号、产品规格（细化为直径、长度、牙距、牙型等四项）、材质、强度、材料、材料化学成分、材料机械性能、表面处理等并生成属性对应的ID代号。 2、算法加工方法： 第一步：从工业零部件数字库-紧固件中获取产品数据，包括品类、标准【标准名称和标准代号】、规格（由直径、长度、牙距、牙型组成）以及材质、强度、材料、表色等数据及属性对应的ID代号。 第二步：将获取的品类、标准、规格3个属性的的ID号，使用33位自定义编码（仅含字母和数字：H1VGSCNXQTF6L7MR2UB04ZP89JE5Y3DKWA）转换成特定的短编码。 第三步：将获取的材质、强度、材料、表色属性值字符串通过哈希算法得到哈希值，再将哈希值使用33位自定义编码转换成特定的短编码。 第四部：将步骤二、三转换后获得的，品类、标准、规格及其他属性的自定义短码通过横杠连接在一起形成产品的唯一编码。

This dataset facilitates the attribute management of GB5784 hexagon bolt fastener products, as well as the generation and management of their unique simplified codes, enabling unique product matching. The attributes of twelve-point screw products consist of 12 categories, including product category, standard product name, standard product code, product specifications (composed of diameter, length, pitch, thread form), material, strength grade, material, surface treatment, etc. The attribute values of product descriptions can be as long as more than 50 characters, making it difficult to call and describe in subsequent systems such as ERP, WMS, and MES, and unable to realize unique product matching and management. To solve this problem, the 12 attribute values of the products are converted into a 12~19-digit unique product code via a custom encoding method similar to Base64 (only containing a total of 33 letters and numbers), which enables unique product matching and retrieval. Additionally, a corresponding QR code is generated based on the unique product code for quick scanning and calling by subsequent system platforms.

1. Data Collection: Obtain the attribute data and parameters of GB5784 hexagon bolt fastener products from published fastener standard manuals, thread tolerances, mechanical property manuals, material manuals, etc. Collect attribute data of fastener products from the "Industrial Parts Digital Library - [Fasteners] Standard Underlying System" developed and operated by our institution, including standard name, standard code, product specifications (refined into four items: diameter, length, pitch, thread form), material, strength grade, material, material chemical composition, material mechanical properties, surface treatment, etc., and generate ID codes corresponding to each attribute.

2. Algorithm Processing Method:
Step 1: Obtain product data from the Industrial Parts Digital Library - Fasteners, including category, standard [standard name and standard code], specifications (composed of diameter, length, pitch, thread form), as well as data such as material, strength grade, material, surface color, and the ID codes corresponding to each attribute.
Step 2: Convert the ID numbers of the three attributes of category, standard, and specifications using the 33-bit custom encoding (only containing letters and numbers: H1VGSCNXQTF6L7MR2UB04ZP89JE5Y3DKWA) into specific short codes.
Step 3: Obtain the hash value of the attribute value strings of material, strength grade, material, and surface color via a hash algorithm, then convert the hash value into specific short codes using the 33-bit custom encoding.
Step 4: Connect the custom short codes of category, standard, specifications, and other attributes obtained from Step 2 and Step 3 with hyphens to form the unique product code.

搜集汇总

数据集介绍

特点

该数据集是GB5784六角螺栓的编码管理数据，包含1002条记录，每周更新，用于产品属性管理和唯一编码生成。通过自定义编码和哈希算法实现产品唯一性匹配和检索。
