XDE120矿用自卸车轮毂驱动系统载荷谱数据

2020年，开展XDE120矿用自卸车轮毂驱动系统载荷谱测试及构建研究，实现复杂动态工况下XDE120矿用自卸车轮毂驱动系统多点多参数载荷谱信号的同步测试，解决国内大扭矩轮毂驱动系统载荷谱缺失问题。根据载荷谱数据计算信号需求以及矿用自卸车整机信号数据特征，确定通过实时采集整机CAN信号的方式，获取电机、发动机和整车状态等数据信息，具体包括电机转矩、电机转速、实时载货重量、油气悬挂压力、发动机转速、整机行驶状态、电制动状态、前桥制动压力、后桥制动压力和装载制动信号；将载荷谱数据分为装载制动、满载等待、空载等待、机械制动、电制动满载前进、电制动满载后退、电制动空载前进、电制动空载后退、满载前进、满载后退、空载前进和空载后退12种工况类型。依据徐工矿机公司XDE120车辆在国内矿区应用情况，开展该车型在云南锌铟矿和西藏巨龙铜的实际运行工况载荷谱数据测试，形成XDE120矿用自卸车载荷谱测试工况数据。设计载荷数据处理方案，通过载荷谱数据预处理、数据典型工况分类处理、典型工况数据统计计算和载荷谱结果编制步骤，实现载荷谱数据统计处理，输出XDE120矿用自卸车轮毂驱动系统载荷谱结果。
数据量1.54MB

In 2020, research on the load spectrum testing and construction of the XDE120 mining dump truck hub drive system was conducted. Synchronous testing of multi-point and multi-parameter load spectrum signals for the XDE120 mining dump truck hub drive system under complex dynamic working conditions was achieved, addressing the issue of missing load spectra for domestic high-torque hub drive systems. Based on the signal requirements calculated from load spectrum data and the characteristics of the whole-vehicle signal data of mining dump trucks, the method of real-time collection of whole-vehicle CAN bus signals was determined to acquire data information including motor torque, motor speed, real-time cargo weight, hydropneumatic suspension pressure, engine speed, overall vehicle driving status, electric brake status, front axle brake pressure, rear axle brake pressure, and loading brake signal. The load spectrum data was categorized into 12 working condition types: loading brake, full-load waiting, no-load waiting, mechanical braking, electric brake with full-load forward, electric brake with full-load reverse, electric brake with no-load forward, electric brake with no-load reverse, full-load forward, full-load reverse, no-load forward, and no-load reverse. According to the application status of XDE120 vehicles from XCMG Mining Machinery Co., Ltd. in domestic mining areas, tests on the actual operating condition load spectrum data of this model were carried out at Yunnan Zinc and Indium Mine and Tibet Julong Copper Mine, generating the load spectrum test working condition data of the XDE120 mining dump truck. A load data processing scheme was designed; through the steps of load spectrum data preprocessing, typical working condition classification processing of data, statistical calculation of typical working condition data, and compilation of load spectrum results, statistical processing of the load spectrum data was completed, and the load spectrum results of the XDE120 mining dump truck hub drive system were output. The total data volume is 1.54 MB.
