220-330 GHz太赫兹校准数据集

数据主要面向太赫兹常见建筑材料反射系数数据校准研究，基于基于时域扩频滑动相关原理的信道探测平台校准测量产生，平台包括发射端（Tx）和接收端（Rx）两部分。发射端由信号发生器R&R®SMW200A、射频线缆、变频模块，功率放大器组成，发射端信号发生器产生自相关特性良好的FZC序列作为探测信号，在变频模块与本振信号上变频为太赫兹信号，通过天线向外部辐射。接收端由低噪声放大器、变频模块、频谱分析仪、控制计算机组成。接收端接收信号，经过低噪声放大器进入变频模块与本振信号下变频为中频信号，引入频谱信号分析仪R&S®FSW43。主要记录频谱分析仪实时采集时域IQ两路数据。数据量为3.94 MB。

This dataset is primarily intended for calibration research on reflection coefficients of common terahertz building materials. It is generated via calibrated measurements on a channel detection platform based on the principle of time-domain spread-spectrum sliding correlation. The platform consists of two parts: a transmitter (Tx) and a receiver (Rx). The transmitter comprises a signal generator R&R®SMW200A, RF cables, frequency conversion modules, and a power amplifier. The signal generator of the transmitter generates a FZC sequence with excellent autocorrelation characteristics as the detection signal, which is up-converted to a terahertz signal with a local oscillator signal through the frequency conversion modules, and radiated to the outside via an antenna. The receiver is composed of a low-noise amplifier, frequency conversion modules, a spectrum analyzer, and a control computer. The receiver captures the received signal, which passes through the low-noise amplifier, then is down-converted to an intermediate frequency (IF) signal with a local oscillator signal in the frequency conversion modules, and finally fed into the signal and spectrum analyzer R&S®FSW43. The main recorded data are the real-time collected time-domain in-phase and quadrature (IQ) dual-channel data acquired by the spectrum analyzer. The total data volume is 3.94 MB.

搜集汇总

背景与挑战

背景概述

该数据集面向太赫兹常见建筑材料反射系数校准研究，基于时域扩频滑动相关原理的信道探测平台生成，包含发射端和接收端组件，记录频谱分析仪采集的时域IQ数据。数据集由北京邮电大学创建，属于国家重点研发计划项目'6G网络基础理论与核心技术研究'，数据量为2.65MB，包含9个文件，适用于太赫兹技术校准和信道测量领域。
