钻井工具方案图集（2018-2020年）

2017-2020年在湖北武汉采用CAD软件设计的钻井工具总图5张，包含PDC钻头、取芯钻头、孕镶钻头、螺杆钻具和涡轮钻具总图。资源时间覆盖范围2018年1月1日至2020年12月30日，资源覆盖地理范围是湖北省武汉市，采用三维绘图软件UG绘制三维模型，生成二维工程图，包含钻头和钻具...

Five sets of general drawings for drilling tools were designed using CAD software in Wuhan, Hubei Province between 2017 and 2020. The drawings cover PDC bits, coring bits, impregnated bits, positive displacement motors (PDMs, screw drilling tools) and turbo drill motors. The dataset has a temporal coverage from January 1, 2018 to December 30, 2020, and its geographic coverage is Wuhan City, Hubei Province. 3D models were developed using the 3D drafting software UG, which were then converted into 2D engineering drawings including the aforementioned drilling bits and tools.

搜集汇总

背景与挑战

背景概述

该数据集是'钻井工具方案图集（2018-2020年）'，包含2018年至2020年在湖北省武汉市使用CAD和UG软件设计的5张钻井工具总图，涵盖PDC钻头、取芯钻头、孕镶钻头、螺杆钻具和涡轮钻具，展示总体结构外观和尺寸。数据以PDF格式提供，质量良好，支持国家重点研发计划'极地冷海钻井关键技术研究'项目，适用于地质学领域的工具设计学习和研究。
