时序分析测试寄生参数数据集

时序分析寄生参数数据集主要用于高精度时序仿真分析测试。寄生参数主要记录了数字电路做完物理布局布线以后，通过寄生参数提取工具提取电路中寄生的电阻和电容信息。这些信息用于做后续的电路仿真，以模拟真实的电路情况。数据量为2.97Mbyte。The parasitic parameter dataset for timing analysis is primarily designed for high-precision timing simulation, analysis and testing. It mainly records the parasitic resistance and capacitance information extracted from digital circuits via parasitic parameter extraction tools after the completion of physical layout and routing of the circuits. Such information is utilized for subsequent circuit simulations to mimic realistic circuit operating conditions. The total size of the dataset is 2.97 Mbyte.

搜集汇总

背景与挑战

背景概述

该数据集主要用于高精度时序仿真分析测试，包含从数字电路物理布局布线中提取的寄生电阻和电容参数，以模拟真实电路情况。数据量约为2.97MB，适用于集成电路和计算机辅助设计领域。
