焦化工程炼焦系统智能建造数据集

本数据集主要包括了某焦化工程1#焦炉的基本信息指标，1#焦炉炉型为65孔JNX3-70-2型焦炉，按单热式设计，单烧焦炉煤气，该焦炉设置烟道气回配装置，化产脱硫塔尾气与烟道气一起回配入炉。炉体总长102.6米，宽度18.64米，炉体高度14.135米，焦炉基础框架柱175根，机焦两侧分烟道全长220米；耐火砖砖型757个，总量27974吨；护炉铁件等非标设备3161吨，炼焦系统建筑钢结构482吨，炼焦系统工艺钢结构146.37吨，炼焦系统工艺管道239.68吨。

This dataset primarily covers the basic information and indicators of the No.1 coke oven in a coking project. The No.1 coke oven is a 65-hole JNX3-70-2 coke oven, designed as a single-heating type and burning coke oven gas exclusively. It is equipped with a flue gas recirculation device, where the tail gas from the desulfurization tower of the chemical recovery section is recirculated into the furnace together with flue gas. The total length of the coke oven body is 102.6 meters, width 18.64 meters, and height 14.135 meters. There are 175 foundation frame columns for the coke oven, and the total length of the split flues on both the machine side and coke side is 220 meters. There are 757 types of refractory bricks with a total weight of 27,974 tons; non-standard equipment including furnace protection iron components weighs 3,161 tons, the architectural steel structure of the coking system is 482 tons, the process steel structure of the coking system is 146.37 tons, and the process pipelines of the coking system total 239.68 tons.

搜集汇总

背景与挑战

背景概述

该数据集记录了65孔JNX3-70-2型焦炉的详细工程参数，包括炉体尺寸（长102.6米/宽18.64米/高14.135米）、烟道配置及各类材料用量（耐火砖27974吨、非标设备3161吨等），适用于焦化工程智能建造研究。
