# CiteVQA

[English](./README.md) | [简体中文](./README_ZH.md)

**CiteVQA** is a document visual question answering benchmark for **faithful evidence attribution**. Unlike conventional DocVQA datasets that only score the final answer, CiteVQA requires a model to answer a question with evidence grounded in the source document at the **element level**. The benchmark is designed to evaluate whether a system can not only answer correctly, but also cite the right supporting region in long, real-world PDFs.

The dataset contains **1,897 questions** built from **711 PDFs** across **7 macro-domains** and **30 sub-domains**, with an average of **40.6 pages per document**. It covers both **English** and **Chinese** documents, and includes **single-document** as well as **multi-document** settings.

<img src="./readme_img/citevqa_example.png" width="100%">

## Highlights

- **Joint answer-and-evidence evaluation**: CiteVQA is built for evaluating both answer correctness and citation faithfulness.
- **Element-level evidence**: Ground-truth evidence is provided as structured elements with bounding boxes, page indices, and document indices.
- **Long-document setting**: Documents are multi-page PDFs with realistic length and layout complexity.
- **Cross-domain and bilingual**: The benchmark spans **7 domains**, **30 sub-domains**, and two languages (`en`, `zh`).
- **Multi-document reasoning**: In addition to single-document QA, the dataset includes cross-document questions requiring evidence aggregation.

## Pipeline

CiteVQA is built with an automated pipeline that links documents, extracts evidence packages, synthesizes question-answer pairs, and validates crucial evidence for attribution-aware evaluation.

<img src="./readme_img/citevqa_pipeline.png" width="100%">

## Dataset Summary

- **Documents**: 711
- **Questions**: 1,897
- **Languages**: 938 English, 959 Chinese
- **Average / median pages per document**: 40.6 / 30.0
- **Dataset settings**:
- `Single-Doc`: 987
- `Multi (1-Gold)`: 487
- `Multi (N-Gold)`: 423
- **Question types**:
- `Complex Synthesis`: 839
- `Factual Retrieval`: 499
- `Multimodal Parsing`: 352
- `Quantitative Reasoning`: 207
- **Average evidence elements per question**: 2.57
- **Maximum evidence elements per question**: 10

## What Is in the Dataset

The main annotation file is:

- [CiteVQA.json](./data/validation/CiteVQA.json): the benchmark annotations

Each sample contains:

- `index`: unique sample id
- `Question`: the user question
- `Standard_Answer`: gold answer
- `Question_Type`: one of `Complex Synthesis`, `Factual Retrieval`, `Multimodal Parsing`, or `Quantitative Reasoning`
- `dataset_type`: one of `Single-Doc`, `Multi (1-Gold)`, or `Multi (N-Gold)`
- `language`: `en` or `zh`
- `description`: domain / sub-domain description
- `PDF_Source`: list of source PDF paths
- `Evidence`: list of evidence elements

### Evidence Format

Each evidence element uses a unified structure:

```json
{
"type": "equation",
"content": "\\[\n\\Phi (\\kappa) = \\frac {4 \\pi \\left\\langle \\delta n _ {\\mathrm {R I}} ^ {2} \\right\\rangle L _ {0} ^ {2} (\\zeta - 1)}{\\left(1 + \\kappa^ {2} L _ {0} ^ {2}\\right) ^ {\\zeta}}, \\tag {7}\n\\]",
"bbox": [
649,
390,
683,
912
],
"angle": 0,
"necessity": "necessary",
"source_pdf_name": "e5be571f178039fee84e79edbd3ca66c7789348e57b7efa87c03fa91901923f2.pdf",
"source_page_id": 2,
"source_doc_index": 1
}
```

Field meanings:

- `type`: evidence type, such as `text`, `title`, `table`, `image`, or `equation`
- `content`: textual/structural content of the evidence; for tables, this may be HTML-like serialized table content; for images, it can be `null`
- `bbox`: bounding box in the source page
- `angle`: rotation angle
- `necessity`: whether the element is marked as `necessary` or `non_necessary`
- `source_pdf_name`: source PDF filename
- `source_page_id`: 0-based or dataset-defined page index in the source PDF
- `source_doc_index`: index of the source document within `PDF_Source`

<details>
<summary>Observed evidence element types</summary>

- `text`
- `title`
- `table`
- `image`
- `image_caption`
- `table_caption`
- `equation`
- `header`
- `footer`
- `list`
- `ref_text`
- `page_footnote`
- `table_footnote`
- `image_footnote`
- `code`
- `page_number`
- `aside_text`
</details>

## Example Sample

<details>
<summary>Show example sample</summary>

```json
{
"index": "ffb14537-fb4c-5aa4-b363-d8191f9bd61a_0",
"Question_Type": "Multimodal Parsing",
"Standard_Answer": "below",
"Question": "On page 39, is the sentence specifying that the deal stays in effect until March 31, 2019, positioned above or below the section header for Article 32?",
"Evidence": [
{
"type": "text",
"content": "32.01 This agreement shall be binding and continue in force and effect until the 31st day of March, 2019. (Amended, 2010, 2013, 2016)",
"bbox": [
465,
135,
501,
881
],
"angle": 0,
"necessity": "necessary",
"source_pdf_name": "ffb14537-fb4c-5aa4-b363-d8191f9bd61a.pdf",
"source_page_id": 39,
"source_doc_index": 1
},
{
"type": "title",
"content": "ARTICLE 32 TERM OF AGREEMENT, NOTICE TO BARGAIN AND RETROACTIVITY",
"bbox": [
431,
135,
448,
831
],
"angle": 0,
"necessity": "necessary",
"source_pdf_name": "ffb14537-fb4c-5aa4-b363-d8191f9bd61a.pdf",
"source_page_id": 39,
"source_doc_index": 1
}
],
"dataset_type": "Single-Doc",
"description": "Laws & Regulations, Gov & Legal",
"language": "en",
"PDF_Source": [
"data/pdf/ffb14537-fb4c-5aa4-b363-d8191f9bd61a.pdf"
]
}
```

</details>

## Download the PDFs

The annotation file stores the referenced PDF paths, while the actual PDFs can be downloaded with the provided script and source table.

Files:

- [data/download/download_pdfs.py](./data/download/download_pdfs.py)
- [data/download/pdf_source.csv](./data/download/pdf_source.csv)

From the repository root, run:

```bash
python data/download/download_pdfs.py --workers 16 --out data/pdf --csv data/download/pdf_source.csv
```

This will download the PDFs into `data/pdf/`, matching the paths used in `PDF_Source`.

## Usage

Load the JSON file:

```python
import json

with open("./data/validation/CiteVQA.json", "r", encoding="utf-8") as f:
data = json.load(f)

print(len(data))
print(data[0].keys())
```

Basic iteration:

```python
sample = data[0]
question = sample["Question"]
answer = sample["Standard_Answer"]
pdfs = sample["PDF_Source"]
evidence = sample["Evidence"]
```

## 🏆 Evaluation Result

We evaluated 20 state-of-the-art MLLMs on CiteVQA using a unified prompt template. The results show that faithful evidence attribution remains substantially harder than answer-only scoring.

- **Best overall SAA**: `Gemini-3.1-Pro-Preview` reaches **76.0** SAA with **86.1** answer score.
- **Best answer accuracy**: `GPT-5.4` reaches **87.1** answer score, but its SAA drops to **59.0**.
- **Best open-source model**: `Qwen3-VL-235B-A22B` reaches **22.5** SAA with **72.3** answer score.
- **Key finding**: a large gap between `Ans.` and `SAA` appears across models, highlighting the benchmark's `Attribution Hallucination` challenge.

Full overall results:

| Model | Category | Rec. | Rel. | Ans. | SAA |
| --- | --- | ---: | ---: | ---: | ---: |
| Gemini-3.1-Pro-Preview | Closed-source MLLMs | 66.0 | 83.6 | 86.1 | 76.0 |
| Gemini-3-Flash-Preview | Closed-source MLLMs | 45.4 | 75.7 | 84.5 | 65.4 |
| GPT-5.4 | Closed-source MLLMs | 31.0 | 67.5 | 87.1 | 59.0 |
| Gemini-2.5-Pro | Closed-source MLLMs | 27.4 | 59.8 | 82.2 | 47.0 |
| Seed2.0-Pro | Closed-source MLLMs | 28.5 | 54.9 | 81.3 | 44.1 |
| GPT-5.2 | Closed-source MLLMs | 18.2 | 56.6 | 71.5 | 33.7 |
| Qwen3.6-Plus | Closed-source MLLMs | 7.7 | 25.0 | 85.9 | 17.5 |
| GLM-5V-Turbo | Closed-source MLLMs | 14.9 | 29.2 | 49.6 | 12.8 |
| Qwen3-VL-235B-A22B | Open-source Large MLLMs | 11.3 | 35.3 | 72.3 | 22.5 |
| Gemma-4-31B | Open-source Large MLLMs | 11.6 | 35.0 | 69.8 | 20.2 |
| Kimi-K2.5 | Open-source Large MLLMs | 6.2 | 26.8 | 74.3 | 19.1 |
| Qwen3.5-397B-A17B | Open-source Large MLLMs | 5.4 | 24.6 | 76.5 | 18.3 |
| Qwen3.5-27B | Open-source Large MLLMs | 5.3 | 25.3 | 75.6 | 17.3 |
| Qwen3-VL-32B | Open-source Large MLLMs | 6.6 | 30.5 | 72.3 | 17.3 |
| Qwen3.5-122B-A10B | Open-source Large MLLMs | 3.9 | 19.0 | 73.6 | 14.8 |
| Qwen3.5-9B | Open-source Small MLLMs | 1.6 | 14.7 | 65.0 | 11.1 |
| Qwen3.5-35B-A3B | Open-source Small MLLMs | 1.7 | 13.7 | 76.4 | 10.7 |
| Qwen3-VL-30B-A3B | Open-source Small MLLMs | 3.5 | 14.6 | 62.2 | 8.2 |
| Qwen3-VL-8B | Open-source Small MLLMs | 1.0 | 14.7 | 61.2 | 7.5 |
| Gemma-4-26B-A4B | Open-source Small MLLMs | 3.0 | 17.9 | 48.4 | 6.2 |

## Evaluation Code

Evaluation code and benchmark updates are available in the official repository:

- [https://github.com/opendatalab/CiteVQA](https://github.com/opendatalab/CiteVQA)

## Copyright Notice

The PDF sources in CiteVQA are collected from publicly accessible web resources, primarily via Common Crawl. To respect copyright and redistribution constraints, this project releases structured annotations, metadata, and public download links, rather than redistributing protected PDF contents directly.

CiteVQA is provided for academic research and non-commercial use only. We fully respect the rights of original copyright holders. If any rights holder believes that the inclusion, indexing, or use of any relevant content in this benchmark is inappropriate, please contact `[e-mail]`. We will verify the request and remove or update the relevant content when appropriate.

## Citation

```bibtex
@article{ma2026citevqa,
title={CiteVQA: Benchmarking Evidence Attribution for Trustworthy Document Intelligence},
author={Ma, Dongsheng and Li, Jiayu and Wang, Zhengren and Wang, Yijie and Kong, Jiahao and Zeng, Weijun and Xiao, Jutao and Yang, Jie and Zhang, Wentao and Wang, Bin and He, Conghui},
journal={arXiv preprint arXiv:2605.12882},
year={2026}
}
```
