# InternData-A1

<div style="display: flex; justify-content: center; align-items: center; margin: 20px 0;">
<img src="https://huggingface.co/spaces/xushicd/InternData_Media/resolve/main/teaser.png" alt="Teaser Image" style="max-width: 100%; border-radius: 10px; box-shadow: 0 4px 8px rgba(0, 0, 0, 0.1);">
</div>

<div align="center" style="margin: 24px 0;">
<a href="https://arxiv.org/abs/2511.16651" style="text-decoration:none;">
<img src="https://img.shields.io/badge/arXiv-2511.16651-red.svg?logo=arxiv&logoColor=white" alt="arXiv Paper: 2511.16651" style="vertical-align: middle; margin-right: 24px; height: 25px;">
</a>
<a href="https://internrobotics.github.io/interndata-a1.github.io/" style="text-decoration:none;">
<img src="https://img.shields.io/badge/Project%20Page-interndata--a1.github.io-1976d2?logo=githubpages&logoColor=white" alt="Project Homepage" style="vertical-align: middle; margin-right: 24px; height: 25px;">
</a>
<a href="https://github.com/InternRobotics" style="text-decoration:none;">
<img src="https://img.shields.io/badge/Code-GitHub-181717?logo=github&logoColor=white" alt="Code Repository" style="vertical-align: middle; height: 25px;">
</a>
</div>

<strong>InternData-A1</strong> is a hybrid synthetic-real manipulation dataset containing over 630k trajectories and 7,433 hours across 4 embodiments, 18 skills, 70 tasks, and 227 scenes, covering rigid, articulated, deformable, and fluid-object manipulation.

<div style="display: flex; justify-content: center; align-items: center; margin: 20px 0;">
<img src="https://huggingface.co/spaces/xushicd/InternData_Media/resolve/main/stats.png" alt="Stats Image" style="max-width: 100%; border-radius: 10px; box-shadow: 0 4px 8px rgba(0, 0, 0, 0.1);">
</div>

<div style="display: flex; flex-direction: column; align-items: center; gap: 10px;">
<!-- First Row -->
<div style="display: flex; justify-content: center; align-items: center; gap: 10px;">
<video controls autoplay loop muted width="50%" style="border-radius: 10px; box-shadow: 0 4px 8px rgba(0, 0, 0, 0.1);">
<source src="https://huggingface.co/spaces/xushicd/InternData_Media/resolve/main/dynamic_pick.mp4" type="video/mp4">
Your browser does not support the video tag.
</video>
<video controls autoplay loop muted width="50%" style="border-radius: 10px; box-shadow: 0 4px 8px rgba(0, 0, 0, 0.1);">
<source src="https://huggingface.co/spaces/xushicd/InternData_Media/resolve/main/stack_sandwich.mp4" type="video/mp4">
Your browser does not support the video tag.
</video>
</div>
<!-- Second Row -->
<div style="display: flex; justify-content: center; align-items: center; gap: 10px;">
<video controls autoplay loop muted width="50%" style="border-radius: 10px; box-shadow: 0 4px 8px rgba(0, 0, 0, 0.1);">
<source src="https://huggingface.co/spaces/xushicd/InternData_Media/resolve/main/fold_shirts.mp4" type="video/mp4">
Your browser does not support the video tag.
</video>
<video controls autoplay loop muted width="50%" style="border-radius: 10px; box-shadow: 0 4px 8px rgba(0, 0, 0, 0.1);">
<source src="https://huggingface.co/spaces/xushicd/InternData_Media/resolve/main/pour_baijiu.mp4" type="video/mp4">
Your browser does not support the video tag.
</video>
</div>
<!-- Third Row -->
<div style="display: flex; justify-content: center; align-items: center; gap: 10px;">
<video controls autoplay loop muted width="50%" style="border-radius: 10px; box-shadow: 0 4px 8px rgba(0, 0, 0, 0.1);">
<source src="https://huggingface.co/spaces/xushicd/InternData_Media/resolve/main/flip_package.mp4" type="video/mp4">
Your browser does not support the video tag.
</video>
<video controls autoplay loop muted width="50%" style="border-radius: 10px; box-shadow: 0 4px 8px rgba(0, 0, 0, 0.1);">
<source src="https://huggingface.co/spaces/xushicd/InternData_Media/resolve/main/shelf_pick.mp4" type="video/mp4">
Your browser does not support the video tag.
</video>
</div>
</div>

# 📢 News
- **Supplementary information:** We have supplemented the updated dataset with camera intrinsics, extrinsics, end-effector poses, and TCP poses. For lerobot v2.1, the directory is **sim_updated**. For lerobot v3.0, the directory is **sim_updated_lerobotv30**.

# 🔑 Key Features
- **Heterogeneous multi-robot platforms:** ARX Lift-2, AgileX Split Aloha, A2D, Franka
- **Hybrid synthetic-real** manipulation demonstrations with **task-level digital twins**, containing four task categories:
- Articulation tasks
- Basic tasks
- Long-horizon tasks
- Pick and place tasks
- **Diverse scenarios include:**
- Moving Object Manipulation in Conveyor Belt Scenarios
- Rigid, articulated, deformable, and fluid-object manipulation
- Multi-robot / multi-arm collaboration
- Human-robot interaction

# 📋 Table of Contents
- [Get started 🔥](#get-started-)
- [Download the Dataset](#download-the-dataset)
- [Dataset Structure](#dataset-structure)
- [📅 TODO List ](#todo-list)
- [License and Citation](#license-and-citation)

# Get started 🔥
## Download the Dataset
To download the full dataset, you can use the following code. If you encounter any issues, please refer to the official Hugging Face documentation.
```
# Make sure you have git-lfs installed (https://git-lfs.com)
git lfs install

# When prompted for a password, use an access token with write permissions.
# Generate one from your settings: https://huggingface.co/settings/tokens
git clone https://huggingface.co/datasets/InternRobotics/InternData-A1

# If you want to clone without large files - just their pointers
GIT_LFS_SKIP_SMUDGE=1 git clone https://huggingface.co/datasets/InternRobotics/InternData-A1
```

## Dataset Structure
### Folder hierarchy
```
data
├── sim
│ ├── articulation_tasks
│ │ └── ...
│ ├── basic_tasks
│ │ └── ...
│ ├── long_horizon_tasks # category
│ │ ├── franka # robot
│ │ │ └── ...
│ │ ├── lift2
│ │ │ ├── sort_the_rubbish # task
│ │ │ │ ├── data
│ │ │ │ │ ├── chunk-000
│ │ │ │ │ │ ├── episode_000000.parquet
│ │ │ │ │ │ ├── episode_000001.parquet
│ │ │ │ │ │ ├── episode_000002.parquet
│ │ │ │ │ │ ├── ...
│ │ │ │ │ ├── chunk-001
│ │ │ │ │ │ ├── ...
│ │ │ │ │ ├── ...
│ │ │ │ ├── meta
│ │ │ │ │ ├── episodes.jsonl
│ │ │ │ │ ├── episodes_stats.jsonl
│ │ │ │ │ ├── info.json
│ │ │ │ │ ├── modality.json
│ │ │ │ │ ├── stats.json
│ │ │ │ │ ├── tasks.jsonl
│ │ │ │ ├── videos
│ │ │ │ │ ├── chunk-000
│ │ │ │ │ │ ├── images.rgb.head
│ │ │ │ │ │ │ ├── episode_000000.mp4
│ │ │ │ │ │ │ ├── episode_000001.mp4
│ │ │ │ │ │ │ ├── ...
│ │ │ │ │ │ ├── ...
│ │ │ │ │ ├── chunk-001
│ │ │ │ │ │ ├── ...
│ │ │ │ │ ├── ...
│ │ │ ├──...
│ │ ├── split_aloha
│ │ │ └── ...
│ │ ├── ...
│ ├── pick_and_place_tasks
│ │ └── ...
│ ├── ...
├── real
│ ├── ...
```

This subdataset(such as `sort_the_rubbish`) was created using [LeRobot](https://github.com/huggingface/lerobot) (dataset v2.1).

### [meta/info.json](meta/info.json):
```json
{
"codebase_version": "v2.1",
"robot_type": "piper",
"total_episodes": 1544,
"total_frames": 1477285,
"total_tasks": 1,
"total_videos": 4632,
"total_chunks": 2,
"chunks_size": 1000,
"fps": 30,
"splits": {
"train": "0:1544"
},
"data_path": "data/chunk-{episode_chunk:03d}/episode_{episode_index:06d}.parquet",
"video_path": "videos/chunk-{episode_chunk:03d}/{video_key}/episode_{episode_index:06d}.mp4",
"features": {
"images.rgb.head": {
"dtype": "video",
"shape": [
360,
640,
3
],
"names": [
"height",
"width",
"channel"
],
"info": {
"video.height": 360,
"video.width": 640,
"video.codec": "av1",
"video.pix_fmt": "yuv420p",
"video.is_depth_map": false,
"video.fps": 30,
"video.channels": 3,
"has_audio": false
}
},
"images.rgb.hand_left": {
"dtype": "video",
"shape": [
480,
640,
3
],
"names": [
"height",
"width",
"channel"
],
"info": {
"video.height": 480,
"video.width": 640,
"video.codec": "av1",
"video.pix_fmt": "yuv420p",
"video.is_depth_map": false,
"video.fps": 30,
"video.channels": 3,
"has_audio": false
}
},
"images.rgb.hand_right": {
"dtype": "video",
"shape": [
480,
640,
3
],
"names": [
"height",
"width",
"channel"
],
"info": {
"video.height": 480,
"video.width": 640,
"video.codec": "av1",
"video.pix_fmt": "yuv420p",
"video.is_depth_map": false,
"video.fps": 30,
"video.channels": 3,
"has_audio": false
}
},
"head_camera_intrinsics": {
"dtype": "float32",
"shape": [
4
],
"names": [
"fx",
"fy",
"cx",
"cy"
]
},
"hand_left_camera_intrinsics": {
"dtype": "float32",
"shape": [
4
],
"names": [
"fx",
"fy",
"cx",
"cy"
]
},
"hand_right_camera_intrinsics": {
"dtype": "float32",
"shape": [
4
],
"names": [
"fx",
"fy",
"cx",
"cy"
]
},
"head_camera_to_robot_extrinsics": {
"dtype": "float32",
"shape": [
7
],
"names": [
"position.x",
"position.y",
"position.z",
"quaternion.w",
"quaternion.x",
"quaternion.y",
"quaternion.z"
]
},
"hand_left_camera_to_robot_extrinsics": {
"dtype": "float32",
"shape": [
7
],
"names": [
"position.x",
"position.y",
"position.z",
"quaternion.w",
"quaternion.x",
"quaternion.y",
"quaternion.z"
]
},
"hand_right_camera_to_robot_extrinsics": {
"dtype": "float32",
"shape": [
7
],
"names": [
"position.x",
"position.y",
"position.z",
"quaternion.w",
"quaternion.x",
"quaternion.y",
"quaternion.z"
]
},
"states.left_joint.position": {
"dtype": "float32",
"shape": [
6
],
"names": [
"left_joint_0",
"left_joint_1",
"left_joint_2",
"left_joint_3",
"left_joint_4",
"left_joint_5"
]
},
"states.left_gripper.position": {
"dtype": "float32",
"shape": [
1
],
"names": [
"left_gripper_0"
]
},
"states.left_ee_to_left_armbase_pose": {
"dtype": "float32",
"shape": [
7
],
"names": [
"position.x",
"position.y",
"position.z",
"quaternion.w",
"quaternion.x",
"quaternion.y",
"quaternion.z"
]
},
"states.left_ee_to_robot_pose": {
"dtype": "float32",
"shape": [
7
],
"names": [
"position.x",
"position.y",
"position.z",
"quaternion.w",
"quaternion.x",
"quaternion.y",
"quaternion.z"
]
},
"states.left_tcp_to_left_armbase_pose": {
"dtype": "float32",
"shape": [
7
],
"names": [
"position.x",
"position.y",
"position.z",
"quaternion.w",
"quaternion.x",
"quaternion.y",
"quaternion.z"
]
},
"states.left_tcp_to_robot_pose": {
"dtype": "float32",
"shape": [
7
],
"names": [
"position.x",
"position.y",
"position.z",
"quaternion.w",
"quaternion.x",
"quaternion.y",
"quaternion.z"
]
},
"states.right_joint.position": {
"dtype": "float32",
"shape": [
6
],
"names": [
"right_joint_0",
"right_joint_1",
"right_joint_2",
"right_joint_3",
"right_joint_4",
"right_joint_5"
]
},
"states.right_gripper.position": {
"dtype": "float32",
"shape": [
1
],
"names": [
"right_gripper_0"
]
},
"states.right_ee_to_right_armbase_pose": {
"dtype": "float32",
"shape": [
7
],
"names": [
"position.x",
"position.y",
"position.z",
"quaternion.w",
"quaternion.x",
"quaternion.y",
"quaternion.z"
]
},
"states.right_ee_to_robot_pose": {
"dtype": "float32",
"shape": [
7
],
"names": [
"position.x",
"position.y",
"position.z",
"quaternion.w",
"quaternion.x",
"quaternion.y",
"quaternion.z"
]
},
"states.right_tcp_to_right_armbase_pose": {
"dtype": "float32",
"shape": [
7
],
"names": [
"position.x",
"position.y",
"position.z",
"quaternion.w",
"quaternion.x",
"quaternion.y",
"quaternion.z"
]
},
"states.right_tcp_to_robot_pose": {
"dtype": "float32",
"shape": [
7
],
"names": [
"position.x",
"position.y",
"position.z",
"quaternion.w",
"quaternion.x",
"quaternion.y",
"quaternion.z"
]
},
"states.robot_to_env_pose": {
"dtype": "float32",
"shape": [
7
],
"names": [
"position.x",
"position.y",
"position.z",
"quaternion.w",
"quaternion.x",
"quaternion.y",
"quaternion.z"
]
},
"actions.left_joint.position": {
"dtype": "float32",
"shape": [
6
],
"names": [
"left_joint_0",
"left_joint_1",
"left_joint_2",
"left_joint_3",
"left_joint_4",
"left_joint_5"
]
},
"actions.left_gripper.position": {
"dtype": "float32",
"shape": [
1
],
"names": [
"left_gripper_0"
]
},
"actions.left_ee_to_left_armbase_pose": {
"dtype": "float32",
"shape": [
7
],
"names": [
"position.x",
"position.y",
"position.z",
"quaternion.w",
"quaternion.x",
"quaternion.y",
"quaternion.z"
]
},
"actions.left_ee_to_robot_pose": {
"dtype": "float32",
"shape": [
7
],
"names": [
"position.x",
"position.y",
"position.z",
"quaternion.w",
"quaternion.x",
"quaternion.y",
"quaternion.z"
]
},
"actions.left_tcp_to_left_armbase_pose": {
"dtype": "float32",
"shape": [
7
],
"names": [
"position.x",
"position.y",
"position.z",
"quaternion.w",
"quaternion.x",
"quaternion.y",
"quaternion.z"
]
},
"actions.left_tcp_to_robot_pose": {
"dtype": "float32",
"shape": [
7
],
"names": [
"position.x",
"position.y",
"position.z",
"quaternion.w",
"quaternion.x",
"quaternion.y",
"quaternion.z"
]
},
"actions.right_joint.position": {
"dtype": "float32",
"shape": [
6
],
"names": [
"right_joint_0",
"right_joint_1",
"right_joint_2",
"right_joint_3",
"right_joint_4",
"right_joint_5"
]
},
"actions.right_gripper.position": {
"dtype": "float32",
"shape": [
1
],
"names": [
"right_gripper_0"
]
},
"actions.right_ee_to_right_armbase_pose": {
"dtype": "float32",
"shape": [
7
],
"names": [
"position.x",
"position.y",
"position.z",
"quaternion.w",
"quaternion.x",
"quaternion.y",
"quaternion.z"
]
},
"actions.right_ee_to_robot_pose": {
"dtype": "float32",
"shape": [
7
],
"names": [
"position.x",
"position.y",
"position.z",
"quaternion.w",
"quaternion.x",
"quaternion.y",
"quaternion.z"
]
},
"actions.right_tcp_to_right_armbase_pose": {
"dtype": "float32",
"shape": [
7
],
"names": [
"position.x",
"position.y",
"position.z",
"quaternion.w",
"quaternion.x",
"quaternion.y",
"quaternion.z"
]
},
"actions.right_tcp_to_robot_pose": {
"dtype": "float32",
"shape": [
7
],
"names": [
"position.x",
"position.y",
"position.z",
"quaternion.w",
"quaternion.x",
"quaternion.y",
"quaternion.z"
]
},
"master_actions.left_joint.position": {
"dtype": "float32",
"shape": [
6
],
"names": [
"left_joint_0",
"left_joint_1",
"left_joint_2",
"left_joint_3",
"left_joint_4",
"left_joint_5"
]
},
"master_actions.left_gripper.position": {
"dtype": "float32",
"shape": [
1
],
"names": [
"left_gripper_0"
]
},
"master_actions.left_gripper.openness": {
"dtype": "float32",
"shape": [
1
],
"names": [
"left_gripper_0"
]
},
"master_actions.right_joint.position": {
"dtype": "float32",
"shape": [
6
],
"names": [
"right_joint_0",
"right_joint_1",
"right_joint_2",
"right_joint_3",
"right_joint_4",
"right_joint_5"
]
},
"master_actions.right_gripper.position": {
"dtype": "float32",
"shape": [
1
],
"names": [
"right_gripper_0"
]
},
"master_actions.right_gripper.openness": {
"dtype": "float32",
"shape": [
1
],
"names": [
"right_gripper_0"
]
},
"timestamp": {
"dtype": "float32",
"shape": [
1
],
"names": null
},
"frame_index": {
"dtype": "int64",
"shape": [
1
],
"names": null
},
"episode_index": {
"dtype": "int64",
"shape": [
1
],
"names": null
},
"index": {
"dtype": "int64",
"shape": [
1
],
"names": null
},
"task_index": {
"dtype": "int64",
"shape": [
1
],
"names": null
}
}
}

```

### key format in features
Select appropriate keys for features based on characteristics such as ontology, single-arm or bimanual-arm, etc.
```
|-- images
|-- rgb
|-- head
|-- hand_left
|-- hand_right
|-- states
|-- left_joint
|-- position
|-- right_joint
|-- position
|-- left_gripper
|-- position
|-- right_gripper
|-- position
|-- actions
|-- left_joint
|-- position
|-- right_joint
|-- position
|-- left_gripper
|-- position
|-- right_gripper
|-- position

```

# 📅 TODO List
- [x] [2025.11] Released: 632k simulation pretraining data (over 7433 hours). The directory is **sim**.
- [x] [2026.01] Released: 589k simulation pretraining data with full annotations of camera intrinsics, extrinsics, ee pose and tcp pose. For lerobot v2.1, the directory is **sim_updated**. For lerobot v3.0, the directory is **sim_updated_lerobotv30**.
- [ ] To be released: real-world post-training data.

# License and Citation
All the data and code within this repo are under [CC BY-NC-SA 4.0](https://creativecommons.org/licenses/by-nc-sa/4.0/). Please consider citing our project if it helps your research.

```BibTeX
@misc{contributors2025internroboticsrepo,
title={InternData-A1},
author={InternData-A1 contributors},
howpublished={\url{https://github.com/InternRobotics/InternManip}}, year={2025}
}
```
