4.23GHz分立SUPSAW滤波器测试数据

4.23GHz分立SUPSAW滤波器主要面向无线通信系统和中高端射频滤波器件的应用需求，本数据集基于网络分析仪和探针台等设备产生，主要记录了包含SUPSAW滤波器中心频率、最小插入损耗、3dB相对带宽、矩形度和带外抑制测试值的测试报告和原始测试数据，数据量约为3.76MB。4.23GHz discrete SUPSAW filters are primarily designed to meet the application demands of wireless communication systems and mid-to-high-end RF filtering devices. This dataset is generated using equipment such as network analyzers and probe stations, and mainly records test reports and raw test data containing the measured values of SUPSAW filters' center frequency, minimum insertion loss, 3dB relative bandwidth, shape factor, and out-of-band rejection. The total data volume is approximately 3.76 MB.

搜集汇总

背景与挑战

背景概述

该数据集针对无线通信系统和中高端射频滤波器件的应用需求，提供了4.23GHz分立SUPSAW滤波器的测试数据，包含中心频率、最小插入损耗、3dB相对带宽、矩形度和带外抑制等关键参数的测试报告和原始数据，数据量约为3.76MB，涵盖4个文件，格式包括JPG、S2P、xlsx和pdf。
