重庆川仪站台门控系统通信及运行数据

重庆川仪站台门控系统通信数据是在重庆川仪自动化股份有限公司轨道门控系统测试平台上收集的，该平台由上位机组态软件HMIcfg、PLC、通讯模块、无线轨道门控执行机构组成。分别利用串口监控软件和HMIcfg软件对PLC通讯模块与无线执行器之间传输的数据以及对上位机组态软件HMIcfg和PLC之间的传输数据进行实时采集。其中通信报文类型分别为MODBUS-RTU和MODBUS-TCP。数据量为26.6MB。The communication dataset of the platform screen door control system from Chongqing Chuanyi was collected on the rail door control system test platform of Chongqing Chuanyi Automation Co., Ltd. This platform comprises upper computer configuration software HMIcfg, PLC, communication modules, and wireless rail door control actuators. Real-time data collection was conducted separately via serial port monitoring software and HMIcfg software, for the data transmitted between the PLC communication modules and wireless actuators, as well as the data transmitted between the upper computer configuration software HMIcfg and PLC. The communication message types are MODBUS-RTU and MODBUS-TCP, respectively. The total size of this dataset is 26.6 MB.

搜集汇总

背景与挑战

背景概述

该数据集源自重庆川仪自动化股份有限公司的轨道门控系统测试平台，通过串口监控和组态软件实时采集了PLC与无线执行器之间以及上位机与PLC之间的通信数据，涵盖MODBUS-RTU与MODBUS-TCP两种协议类型，数据总量为26.68MB。
