频率编码超构材料测试数据

本数据集为频率编码现场可编程超表面样品在4组编码下、各谐波频点的实测方向图数据。数据集包含4个后缀为.dat的数据文件，分别对应以下四种目标编码对应的方向图数据：
1. +1阶/-1阶谐波频率的波束指向为+30度/-20度；
2. +1阶/-1阶谐波频率的波束指向为+35度/-35度；
3. +1阶/-1阶谐波频率的波束指向为+40度/-40度；
4. +3阶/-2阶谐波频率的波束指向为+40度/-30度。
每个数据文件中记录有实测数据的频点、方位角和对应的S12参数大小（dB值）。

This dataset contains measured radiation pattern data at each harmonic frequency for frequency-coded field-programmable metasurface samples under four coding configurations. The dataset includes 4 data files with the .dat suffix, which correspond to the radiation pattern data of the following four target coding schemes respectively:
1. The beam directions at +1st/-1st harmonic frequencies are +30° and -20° respectively;
2. The beam directions at +1st/-1st harmonic frequencies are +35° and -35° respectively;
3. The beam directions at +1st/-1st harmonic frequencies are +40° and -40° respectively;
4. The beam directions at +3rd/-2nd harmonic frequencies are +40° and -30° respectively.
Each data file records the measured frequency points, azimuth angles, and corresponding S12 parameter values (in dB).

搜集汇总

背景与挑战

背景概述

该数据集提供了频率编码现场可编程超表面样品在四种不同编码配置下的实测方向图数据。数据文件记录了各谐波频点对应的方位角及S12参数大小，适用于微波技术领域的研究与分析。
