机床主轴轴承应力、变形和温度仿真数据集

该数据集基于Ansys软件建立了建立机床主轴轴承仿真分析模型。计算了计算了轴承整体变形分布、温度分布、开槽前不同测点应力分布、开槽后不同测点应力分布和开槽前后不同测点的变形分布。

This dataset establishes a simulation analysis model for machine tool spindle bearings based on Ansys software. The calculated results include the overall deformation distribution and temperature distribution of the bearing, the stress distribution at different measuring points before and after slotting, as well as the deformation distribution at different measuring points before and after slotting.

搜集汇总

背景与挑战

背景概述

该数据集由重庆大学创建，基于Ansys软件仿真机床主轴轴承的应力、变形和温度分布，重点关注开槽前后的测点变化。数据来源于国家重点研发计划项目，适用于数字控制机床领域，涉及智能轴承和结构强度分析，具有1.65MB大小和3个文件，为轴承性能优化提供基础仿真数据。
