国产A4打印主控SoC研制

本数据集自主开发了国内首款彩色打印主控SoC，攻克了高速VIDEO控制技术、LVDSAFE技术、DADFShading算法等“卡脖子”技术难题，达到了国际同类先进水平。通过研究多核异构的SoC架构，完成了图像处理和打印操控算法的软硬件协同设计，突破单核或同构多核下算法分配的局限性，解决SoC芯片能效问题；通过结合高性能硬件浮点运算单元以及高精度光学色彩传感器，形成高性能的彩色闭环校正机制，实现了彩色打印机高性能色彩校正；首次使用控制A4DADF扫描仪，通过LVDSAFE的技术解决了A4DADF高速扫描数据量大导致速度慢的技术难题，并基于DADFShading算法，实现了DADF的扫描画像质量输出；国内首家完全自主掌握了彩色引擎控制、色彩校正等核心技术，实现高速彩色打印和复印功能。 项目期内，彩色打印主控SoC搭载至自主A4彩色打印机、A3彩色复印机完成量产导入开发，并通过中试生产及定型检验，均达到稳定的量产水平，且搭载至自主A4彩机实施产业化应用。 对应考核指标：指标1.1：芯片工艺28nm；指标1.2：主CPU时钟频率≥1GHz；指标1.3：主CPU性能≥2500DMIPS；指标1.4：支持USB3.0、PCIe2.0、DDR4等高速接口；指标1.12：支持512KB L2，1MB+512KB SRAM缓存；指标1.13：打印引擎数据接口支持8通道LVDS高速输出；指标1.14：扫描引擎数据接口支持6通道LVDS高速输入；指标1.15：支持USB3.0 Device*1, OTG*2。This dataset is based on the first domestically developed color printing master control SoC independently developed in China. The project has broken through technical bottlenecks including high-speed VIDEO control technology, LVDSAFE technology, and DADFShading algorithm, reaching the international advanced level of its kind. By researching heterogeneous multi-core SoC architecture, we have completed the hardware-software co-design of image processing and printing control algorithms, broken through the limitations of algorithm allocation under single-core or homogeneous multi-core scenarios, and solved the energy efficiency issues of SoC chips. By combining high-performance hardware floating-point arithmetic units and high-precision optical color sensors, a high-performance color closed-loop correction mechanism has been established, realizing high-performance color correction for color printers. For the first time, the control of A4 DADF scanners has been realized. The technical problem of slow speed caused by large data volume in high-speed scanning of A4 DADF has been solved via LVDSAFE technology, and high-quality output of DADF scanned images has been achieved based on the DADFShading algorithm. It is the first domestic entity to fully independently master core technologies including color engine control and color correction, realizing high-speed color printing and copying functions. During the project period, the color printing master control SoC was integrated into self-developed A4 color printers and A3 color copiers for mass production introduction and development. It passed pilot production and finalization inspection, reaching stable mass production levels, and was applied in industrialization on self-developed A4 color printers. Corresponding assessment indicators: Indicator 1.1: Chip process: 28nm Indicator 1.2: Main CPU clock frequency ≥ 1GHz Indicator 1.3: Main CPU performance ≥ 2500 DMIPS Indicator 1.4: Supports high-speed interfaces including USB3.0, PCIe2.0, DDR4, etc. Indicator 1.12: Supports 512KB L2 cache and 1MB + 512KB SRAM cache Indicator 1.13: Print engine data interface supports 8-channel LVDS high-speed output Indicator 1.14: Scan engine data interface supports 6-channel LVDS high-speed input Indicator 1.15: Supports 1 USB3.0 Device and 2 OTG ports

搜集汇总

背景与挑战

背景概述

该数据集聚焦于国内首款彩色打印主控SoC的自主研发，突破了高速VIDEO控制、LVDSAFE技术及DADFShading算法等关键难题，达到国际先进水平。通过多核异构架构和软硬件协同设计，实现了高性能色彩校正与高速扫描处理，并已成功应用于A4彩色打印机等产品的量产。
