400G光模块DVT测试数据

本数据是400G 模块的DVT测试数据，包含使用万用表测试各电源在拉偏条件下的输出电压，使用实时示波器测试各电源在拉偏条件下的纹波，使用实时示波器测试各电源的上电时序，使用实时示波器测试各通讯时序，使用实时示波器测试各信号波形，使用光示波器及BERT测试模块光性能，使用功率计测试模块的DDM精度，使用稳压电源及BERT测试模块。This dataset comprises DVT (Design Verification Test) data for 400G modules. The covered test contents include: output voltages of each power supply under bias stress conditions measured by a multimeter; ripple voltages of each power supply under bias stress conditions detected by a real-time oscilloscope; power-on timing sequences of each power supply tested via a real-time oscilloscope; communication timing sequences of the modules tested by a real-time oscilloscope; various signal waveforms of the modules tested by a real-time oscilloscope; optical performance of the modules tested using an optical oscilloscope and BERT (Bit Error Rate Tester) modules; DDM (Digital Diagnostic Monitoring) accuracy of the modules measured by a power meter. All tests were conducted with a regulated power supply and BERT modules.

搜集汇总

背景与挑战

背景概述

该数据集包含400G光模块的设计验证测试数据，涉及电源输出电压、纹波、时序、信号波形、光性能和DDM精度等多方面测试。这些数据通过万用表、实时示波器、光示波器、BERT和功率计等设备采集，用于模块性能评估。
