毫米波分布式天线

毫米波分布式天线数据集主要面向高效率低端毫米波分布式天线研究，基于分布式天线架构和封装天线理论需求建设，HFSS仿真软件及矢量网络分析仪、天线测量暗室等仪器、第三方测试机构测试，得到分布式天线的工作频段和辐射效率等观测值，研究内容包括分布式天线设计方法等。主要数据包括天线S参数、辐射效率等测量值，数据量6.22MB。This millimeter-wave distributed antenna dataset is primarily developed for research on high-efficiency low-end millimeter-wave distributed antennas. It was constructed based on the architectural requirements of distributed antenna systems and the theoretical demands of packaged antennas. Observed metrics of the distributed antennas including operating frequency band and radiation efficiency were obtained through tests conducted with ANSYS HFSS simulation software, vector network analyzers (VNAs), antenna measurement anechoic chambers, other testing instruments, as well as third-party testing institutions. The research contents supported by this dataset include design methods for distributed antennas and other related topics. The core data comprises measured values such as antenna S-parameters and radiation efficiency, with a total data volume of 6.22 MB.

搜集汇总

背景与挑战

背景概述

毫米波分布式天线数据集主要面向高效率低端毫米波分布式天线研究，包含天线S参数、辐射效率等测量值，数据量6.22MB。数据集由华南理工大学廖绍伟团队创建，基于国家重点研发计划项目，采用HFSS仿真软件及多种仪器测试得到。
