车门C柱密封条拉伸质量评价数据

任何橡胶制品都是在一定外力条件下使用，因而要求密封条橡胶应有一定的物理机械性能， 而性能中最为明显为拉伸性能，在进行成品质量检查、设计胶料配方、确定工艺条件时，一般均需通过拉伸性能予以鉴定。拉伸性能常用拉伸强度和断裂伸长率来体现，在动夹持器或滑轮恒速移动的拉力试验机上，将哑铃状标准试样进行拉伸。按要求记录试样在不断拉伸过程中和当其断裂时所需的力和伸长率的值，根据公式变形量÷标准基线的宽度×100%=应变（%）、力值÷（厚度×宽度）=应力（MPa）进行计算得出拉伸强度、断裂伸长率等性能结果。将算出的性能结果与国家标准或客户技术要求进行对比判断，确定该样品拉伸性能是否合格，用于作出是否需要改进生产工艺、生产配方和该产品是否符合客户要求的判定依据。1、样品采集：根据GB/T 528-2009的技术要求取I型哑铃状试样，用测厚仪和游标卡尺分别测出待测样条的厚度和宽度，并画出两条间隔25mm±0.5mm的标准基线； 2、样品测试：将试样对称地夹在拉力试验机的上、下夹持器上，使拉力均匀地分布在待测样条的横截面上，拉伸速度设置为500±50mm/min，点击触控面板上的"开始"按钮进行测试 ； 3．数据采集：每组样品测试完成之后导出变形量（mm）和力值（N）；4、数据计算：变形量÷标准基线的宽度×100%=应变（%）；力值÷（厚度×宽度）=应力（MPa）；5、根据该样品的技术要求，最大的应力最大值≥6MPa，且应变最大值≥150%即记为合格品，任一参数不满足技术要求即记为不合格品，用于作出是否需要改进生产工艺或生产配方的判定依据。All rubber products are used under specific external force conditions, so rubber sealing strips must possess certain physical and mechanical properties, among which tensile performance is the most prominent. Tensile properties are commonly used for evaluation in finished product quality inspection, rubber compound formulation design, and process parameter determination. Tensile performance is typically characterized by tensile strength and elongation at break. A dumbbell-shaped standard specimen is subjected to stretching on a constant-speed tensile testing machine equipped with moving grips or a pulley. Record the force and elongation values during the continuous stretching process and at the moment of specimen fracture, then calculate performance indicators such as tensile strength and elongation at break using the following formulas: deformation ÷ standard baseline width × 100% = strain (%), and force ÷ (thickness × width) = stress (MPa). Compare the calculated performance results with national standards or customer technical requirements to determine whether the sample’s tensile performance is qualified, which serves as the basis for decisions on whether to improve production processes, rubber compound formulations, and whether the product meets customer requirements. 1. Sample Collection: Prepare Type I dumbbell specimens in accordance with the technical requirements of GB/T 528-2009. Use a thickness gauge and vernier caliper to measure the thickness and width of the test strip respectively, and draw two standard baselines with an interval of 25mm±0.5mm. 2. Sample Testing: Clamp the specimen symmetrically on the upper and lower grips of the tensile testing machine to ensure uniform force distribution across the cross-section of the test strip. Set the tensile speed to 500±50mm/min, and click the "Start" button on the touch panel to conduct the test. 3. Data Collection: Export the deformation (mm) and force (N) values after each set of samples completes testing. 4. Data Calculation: Deformation ÷ standard baseline width × 100% = strain (%); Force ÷ (thickness × width) = stress (MPa). 5. Qualification Judgment: Per the technical requirements of the sample, the specimen is deemed qualified if the maximum stress ≥6MPa and the maximum strain ≥150%; otherwise, it is deemed unqualified. This result is used as the basis for deciding whether to improve production processes or formulations.

搜集汇总

数据集介绍

特点

该数据集包含199条车门C柱密封条拉伸质量评价数据，每月更新，用于评价密封条橡胶的拉伸性能是否合格，应用场景包括质量检查、配方设计和工艺条件确定。
