DFB激光器的时域仿真数据

通过模拟分析静态和调制下DFB激光器的载流子和光场分布，以及前后端面的出光功率和频率啁啾仿真数据，指导优化DML芯片的阈值电流、调制带宽和眼图质量，以确保芯片设计满足50G PAM4要求。数据采集方式为：在Windows系统下，利用自主研发设计的仿真软件，基于耦合波理论，建立DFB激光器的时域仿真模型，完成大电流调制下的时域仿真程序，仿真得到DML激光器的设计参数，例如光栅耦合系数、光场限制因子和端面反射率等，并记录。数据量为490KB。By simulating and analyzing the carrier and optical field distributions of DFB (Distributed Feedback) lasers under static and modulated conditions, as well as the simulation data of output optical power and frequency chirp at the front and rear facets, this dataset guides the optimization of threshold current, modulation bandwidth and eye diagram quality of DML (Directly Modulated) chips, ensuring that the chip design meets the 50G PAM4 requirements. The data collection method is as follows: Under the Windows operating system, using the independently developed simulation software, a time-domain simulation model of DFB lasers is established based on the coupled-mode theory, and the time-domain simulation program under high-current modulation is completed. The design parameters of DML lasers, such as grating coupling coefficient, optical confinement factor, facet reflectivity and other related parameters, are obtained through simulation and recorded. The total data volume is 490 KB.

搜集汇总

背景与挑战

背景概述

该数据集提供了DFB激光器的时域仿真数据，通过建立仿真模型并分析静态和调制下的载流子与光场分布，旨在优化DML芯片的阈值电流、调制带宽等参数，以满足50G PAM4的设计要求。数据基于耦合波理论在Windows环境下使用自主软件生成，包含光栅耦合系数等关键设计参数，总数据量约为490KB。
