刀具设计平台考虑磨损的刀具几何模型

对本数据集中考虑磨损的刀具几何模型来源于复杂刀具“形-性-用”一体化设计平台，为了得到刀具的寿命，采用Python语言对Siemens NX进行二次开发，Siemens NX所选用的版本为1904。通过Siemens NX快速建立不同参数的刀具模型，其中包括11把刀具的考虑磨损的刀具几何模型。数据主要包括11类刀具的刀具几何模型以及其衍生的相关数据，包括prt，sat类型的文件。

The wear-aware tool geometric models in this dataset are derived from the integrated "shape-property-application" design platform for complex cutting tools. To acquire tool life data, secondary development of Siemens NX (version 1904) was conducted using the Python programming language. Tool models with various parameters were rapidly built via Siemens NX, including 11 wear-aware tool geometric models. The dataset primarily comprises the tool geometric models of 11 categories of cutting tools and their derived related data, including files in PRT and SAT formats.

搜集汇总

背景与挑战

背景概述

该数据集包含11把考虑磨损的刀具几何模型，来源于复杂刀具一体化设计平台，通过Python对Siemens NX进行二次开发生成。数据包括prt和sat格式文件，总数据量596.52MB，属于机械工程学科，由哈尔滨理工大学在国家重点研发计划项目支持下创建。
