金属线纹尺

金属线纹尺是在金属材料上标刻线纹及数字，金属材料分为不锈钢、弹簧钢、45#钢等。其中，三等金属线纹尺（又称日内瓦尺），是一种带有读数放大镜和温度计的精密刻划金属直尺。全尺刻划长度为1202毫米，尺的两侧，分别有0.2和1毫米的等分划线标度，为了观读方便，尺上带有7/10倍放大镜两只，放大镜能沿着尺的标度用手移动。在测绘作业中常用于检查图廊点、控制点和坐标网点距离，在国家水准测量规范中规定作为标准尺进行检定水准标尺之用。Metal engraved linear scales are engraved with lines and numerical markings on metallic substrates, which include stainless steel, spring steel, 45# steel, and other materials. The Grade 3 metal engraved linear scale, also known as the Geneva scale, is a precision engraved metal straight ruler equipped with two reading magnifiers and a thermometer. Its total engraved length is 1202 mm. The two sides of the ruler are graduated with equally spaced markings of 0.2 mm and 1 mm, respectively. To facilitate reading, the ruler is fitted with two 7/10-power magnifiers that can be manually moved along the scale graduations. It is commonly used in surveying and mapping operations to check the distances between map sheet corner points, control points and coordinate grid points, and is specified as a standard scale for calibrating leveling staffs in national leveling survey specifications.

搜集汇总

背景与挑战

背景概述

该数据集聚焦于金属线纹尺，这是一种在金属材料上标刻线纹及数字的精密测量工具，材料包括不锈钢、弹簧钢等。具体来说，它包含三等金属线纹尺（日内瓦尺），具有1202毫米刻划长度和放大镜功能，主要用于测绘作业中的距离检查和水准标尺检定，体现了计量科学领域的标准化和实用性。数据集由国家计量科学数据中心管理，支持线上完全共享。
