光学空间模式控制器

观测芯片的输出波导数目，为通道数目；用任意波形产生器对芯片调制方波信号，通过示波器测得上升/下降沿10%-90%这一区间对应的时间，得到空间模式控制速度、相邻通道输出光谱的峰值的频率差为光谱分辨率。同时，文件中包含了芯片的仿真代码。The number of channels is determined by counting the output waveguides of the chip under test. Square-wave signals were modulated onto the chip using an arbitrary waveform generator, and the time corresponding to the 10%–90% interval of the rising/falling edge was measured with an oscilloscope to obtain the spatial mode control speed. The frequency difference between the peak frequencies of the output spectra of adjacent channels is defined as the spectral resolution. Additionally, the simulation code for the chip is included in the dataset files.

搜集汇总

背景与挑战

背景概述

该数据集围绕光学空间模式控制器展开，主要包含薄膜铌酸锂空间控制芯片的测量数据，如输出波导数目、空间模式控制速度及光谱分辨率，并附有相关仿真代码。数据集由清华大学发布，属于国家重点研发计划项目的一部分，旨在支持宽带微波光子信号调控核心器件与技术的研究。
