Data underlying the publication: A Cryo-CMOS Smart Temperature Sensor for the Ultrawide Temperature Range from 5 K to 296 K

Supplementary material for the SSCL publication 'A Cryo-CMOS Smart Temperature Sensor for the Ultrawide Temperature Range from 5 K to 296 K'. This academic project designed and calibrated a temperature sensor from room temperature down to 5K for multiple samples. A helium dewar and PD controlled resistive heater were used to control the temperature of the device under test. For each sample and temperature point, output analog voltage and digital bit stream were measured for multiple sensing elements. In post processing, data was reorganized so that there is a file for each sensing element that contains data for every temperature point and sensing element. The repository contains the data for each sensing element after such post- processing, as well as the cripts that generate the paper plots.Morever, it contains files used to generate the graphical figures (PowerPoint, EPS formats added, Illustrator and Inkscape files are included)本材料为SSCL发表的题为《适用于5 K至296 K超宽温区的低温CMOS（Cryo-CMOS）智能温度传感器》的学术论文的补充资料。本学术项目为多组待测样品设计并校准了一款可覆盖室温至5 K温区的温度传感器。实验采用氦杜瓦瓶与PD控制电阻加热器，用于调控待测器件的工作温度。针对每一组待测样品与每一个温度测点，研究人员对多个传感单元的模拟电压输出与数字比特流开展了测量工作。在后处理阶段，研究人员对原始数据进行重构整理，为每一个传感单元生成专属数据文件，该文件包含该传感单元在所有温度测点下的全部测量数据。本数据集仓库包含上述后处理完成的各传感单元测量数据，以及用于复现论文配图的脚本文件。此外，该仓库还包含用于生成可视化图表的各类源文件：涵盖PowerPoint格式、封装PostScript（EPS）格式文件，同时包含Adobe Illustrator与Inkscape矢量绘图源文件。

搜集汇总

背景与挑战

背景概述

该数据集是出版物《A Cryo-CMOS Smart Temperature Sensor for the Ultrawide Temperature Range from 5 K to 296 K》的支撑数据，包含低温CMOS智能温度传感器在5K至296K超宽温度范围内的设计、校准和测量数据。数据集提供了多个传感元件的输出电压和数字比特流测量结果，以及用于生成论文图表的脚本和图形文件，适用于电气工程、量子物理等领域的研究。
