增速齿轮箱批量制造零件检测数据集

重庆齿轮箱有限责任公司FLR5000HB型风力发电机组齿轮箱齿轮精度和内轨道精度。采集方案：对重庆齿轮箱有限责任公司FLR5000HB型风力发电机组齿轮箱的齿廓偏差、螺旋线偏差、单个齿距偏差和齿距积累总偏差记录，对其内轨道精度进行检测，检测包括轨道母线形状、内孔波纹度等项目检测记录。采集地点：重庆齿轮箱有限责任公司采集时间：2021年5月、6月设备情况：MMZ-G404030三坐标测量机，P300齿轮测量中心

This dataset focuses on the gear accuracy and inner raceway accuracy of the FLR5000HB wind turbine gearbox produced by Chongqing Gearbox Co., Ltd. Collection Plan: Record the tooth profile deviation, helix deviation, individual pitch deviation and cumulative pitch deviation of the FLR5000HB wind turbine gearbox, and detect its inner raceway accuracy, with the detection covering items such as raceway generatrix shape and inner bore waviness along with corresponding detection records. Collection Location: Chongqing Gearbox Co., Ltd. Collection Time: May and June 2021 Equipment: MMZ-G404030 coordinate measuring machine, P300 gear measuring center

搜集汇总

背景与挑战

背景概述

该数据集包含重庆齿轮箱有限责任公司FLR5000HB型风力发电机组齿轮箱的齿廓偏差、螺旋线偏差等精度检测数据，以及内轨道精度的检测记录。数据采集于2021年5月和6月，使用MMZ-G404030三坐标测量机和P300齿轮测量中心设备，数据格式为xlsx、pdf和docx，总大小为4.6MB。
